Allow your users to add their handwritten signature inside an HTML editor with Telerik UI for ASP.NET AJAX.

In today’s world, where digitization has taken over every aspect of our lives, the need for signatures has not been eliminated. However, now instead of physically signing a document, we can use an electronic signature, which is quick, easy and secure.  One popular way of doing this is to use a handwritten signature, which gives the electronic document a personal touch.

Progress Telerik UI for ASP.NET AJAX provides two useful components, RadSignature and RadEditor, that can be integrated to facilitate the inclusion of handwritten signatures to an HTML editor.

The Solution

In this blog post, I will showcase how to build a custom Signature dialog application scenario that integrates RadSignature and RadEditor. The demo allows users to insert a handwritten signature into a content area of the RadEditor.

The WYSIWYG editor control has a custom button called “Insert Handwritten Signature.” When clicked upon, it opens a dialog box that displays a signature pad. The user can leverage the signature pad to draw their signature. Once done, they can click on the “Store on Server as PNG and Insert” button to store the signature on the server as a PNG file and insert the signature image into the editor.

User clicks the pencil icon on the signature spot to sign. This opens an insert signature window that the user draws on, and then presses the store on server as PNG and insert button. Then the signature is inserted in place and can be adjusted for scale.

Let’s take a look at the code that makes this possible.

The default.aspx page contains the RadEditor control with the custom button defined inside the tool groups.

ASPX code snippet (HTML)

<telerik:RadEditor RenderMode="Lightweight" runat="server" ID="RadEditor1" Width="800px">
    <Tools>
        <telerik:EditorToolGroup>
            <telerik:EditorTool Name="InsertSignature" Text="Insert Handwritten Signature"></telerik:EditorTool>
        </telerik:EditorToolGroup>
        <telerik:EditorToolGroup>
            <telerik:EditorTool Name="Bold"></telerik:EditorTool>
            <telerik:EditorTool Name="Italic"></telerik:EditorTool>
            <telerik:EditorTool Name="Underline"></telerik:EditorTool>
        </telerik:EditorToolGroup>
    </Tools>
    <Content>
        To sign up, simply click on the pencil icon above and use your mouse to handwrite your signature and insert it here.
    </Content>
</telerik:RadEditor>
<script>
    // Add custom command to the RadEditor command list
    Telerik.Web.UI.Editor.CommandList['InsertSignature'] = function (commandName, editor, args) {

        // Callback function to handle signature insertion after the dialog is closed
        var myCallbackFunction = function (sender, args) {
            // Insert signature image HTML into the editor
            editor.pasteHtml(String.format('<img src=\'{0}\' border=\'0\' style=\'width:50%;height:50%;\'  /> ', args.src));
        };

        // Show signature dialog as an external dialog
        editor.showExternalDialog(
            'InsertSignature.aspx',
            null,
            540,
            450,
            myCallbackFunction,
            null,
            'Draw and Insert Signature',
            true,
            Telerik.Web.UI.WindowBehaviors.Close + Telerik.Web.UI.WindowBehaviors.Move,
            false,
            true);
    };
</script>

The script placed below the editor declaration adds a custom command to the RadEditor command list. It shows the signature dialog as an external dialog, loads it with the InsertSignature.aspx page, and handles the signature insertion after the dialog is closed.

To style the custom button and visualize a font-icon over it add the following CSS class:

CSS snippet

.reTool.reInsertSignature.reToolIcon:before {
    content: "\e10b";
}
The InsertSignature.aspx page contains a RadSignature control that provides the signature pad functionality. The RadButton1 button stores the signature on the server as a PNG file and inserts the signature image into the editor. The RadAjaxManager1 control handles the AJAX request and updates the RadSignature1 control.
ASPX (InsertSignature.aspx)
        <telerik:RadAjaxManager EnableAJAX="true" ID="RadAjaxManager1" runat="server" OnAjaxRequest="RadAjaxManager1_AjaxRequest">
            <ClientEvents OnResponseEnd="OnResponseEnd" />
            <AjaxSettings>
                <telerik:AjaxSetting AjaxControlID="RadButton1">
                    <UpdatedControls>
                        <telerik:AjaxUpdatedControl ControlID="RadSignature1" />
                    </UpdatedControls>
                </telerik:AjaxSetting>
            </AjaxSettings>
            <ClientEvents OnResponseEnd="insertEmoticon" />
        </telerik:RadAjaxManager>
        <telerik:RadButton runat="server" ID="RadButton1" Text="Store on Server as PNG and Insert" AutoPostBack="false" OnClientClicked="sendToServer" />
        <br />
        <br />

        <telerik:RadSignature runat="server" ID="RadSignature1" Height="270" Width="400">
            <ClientEvents OnLoad="signatureLoad" />
        </telerik:RadSignature>

        <telerik:RadScriptBlock runat="server" ID="RadScriptBlock1">
            <script>
                var signature;
                var fileName = "signature.png";

                function signatureLoad(sender, args) {
                    signature = sender;
                }

                function sendToServer(sender, args) {
                    if (!signature.get_value()) return;
                    var ajaxManager = $find("<%= RadAjaxManager1.ClientID %>");
                    ajaxManager.ajaxRequest(fileName + ";" + signature.get_value());
                }

                //called when the OnResponseEnd of RadAjaxManager fires
                function insertSignatureImage(sender, args) {
                    signature.set_value('');
                    var closeArgument = {};
                    //asign the imageSrc which comes from the server to the src argument
                    closeArgument.src = imageSrc;
                    //closes the dialog and submit the src to the myCallbackFunction function on the main page
                    getRadWindow().close(closeArgument);
                }
            </script>
        </telerik:RadScriptBlock>

In the section below, we continue discussing the code behind the signature dialog, and more specifically the server-side code that handles the AJAX request and saves the signature as a PNG file on the server.

C# (InsertSignature.aspx.cs)

protected void RadAjaxManager1_AjaxRequest(object sender, Telerik.Web.UI.AjaxRequestEventArgs e)
    {
        // Split the argument received into two parts, separated by a semicolon.
        var args = e.Argument.Split(new[] { ';' }, 2);
        // Get the filename from the first part of the argument.
        var fileName = args[0];
        // Get the base64-encoded image data from the second part of the argument and extract the image string
        var base64raw = args[1];
        var base64data = base64raw.Split(',')[1];

        // Check if the size of the received data does not exceed 200KB and is a valid base64 image.
        var isSizeValid = (Encoding.UTF8.GetByteCount(base64raw) < 200000);

        // If the received data is a valid image string, save the image to disk.
        if (isImageString && isSizeValid)
        {
            // Generate a unique filename by appending a GUID to the original filename.
            var fileNameGuid = Guid.NewGuid() + "_" + fileName;

            // Get the full path to the images folder and append the unique filename to it.
            var path = Server.MapPath("~/Editor/Examples/SignatureDialog/Images") + "\\" + fileNameGuid;

            // Convert the base64 data to bytes and write it to the specified path.
            System.IO.File.WriteAllBytes(path, Convert.FromBase64String(base64data));


            // Create a script to be registered with the page that sets the image source to the saved image file.
            string script = string.Format("var imageSrc ='Images/" + fileNameGuid + "';");

            // Register the script with the page so that the imageSrc gets available in the insertEmoticon client function
            ScriptManager.RegisterStartupScript(Page, typeof(Page), "myscript", script, true);
        }
    }

Insert signature window with space for signing and a button to store on server and insert

Let’s go through the code above.

The RadAjaxManager1_AjaxRequest event handler is where the magic happens. This handler is called when the “Store on Server as PNG and Insert” button is clicked. The e.Argument parameter tells us what the purpose of the AJAX request is. In this case, the value will be the image file name and the base64 data coming from the exported signature drawing.

We start by getting the signature image from the RadSignature control as a byte array. We then generate a random file name with a .png extension and save the signature image as a PNG file on the server. Note that we are saving the image to a folder called “Images” in the root of our application. You can change this folder to one of your preference.

Next, we construct a RegisterStartupScript response to return the path for the saved signature image to the main page. We use the ScriptManager.RegisterStartupScript method to add JavaScript code to the callback function on the main page. This code calls the insertSignatureImage function on the main page, passing the path to the saved signature image as a parameter.

The insertSignatureImage is also responsible for inserting the signature image into the RadEditor’s content area at cursor position.

Conclusion

In this blog post, we have showcased how to integrate the RadSignature and RadEditor for Telerik UI fo ASP.NET AJAX components to provide a signature pad dialog that allows users to insert a handwritten signature into a content area of the editor. We have discussed the code for the main page and the signature dialog, as well as the server-side code that handles the AJAX request and saves the signature as a PNG file on the server.

I hope you have found this blog post useful and informative. If you have any questions or feedback, please leave a comment below. Thank you for reading and happy coding!
