Questions on UI for WinForms Forum

1 answer

226 views

radgridview can't display summaryrowsbottom value

I use radgridview control to fill tablea and tableb datasource.
in frmA and frmB I use same mothod
set radgridview property->summaryrowsbottom->sum filedname
in frmA recordset count is 10 ->radgridview summary display ok (sql: select * from table a)
but in frmB recordset count is 300 ->radgridview summary can't display from the gridview bottom (sql:select * from tableb)

if frmB recordset count is 10 ->radgridview summary display ok (sql:select top 10 * from tableb)
how can i display summaryrowsbottom value in a lot of rows?
thanks!

2013.03.28

I use code

private RadGridView radGridView1;

private

GridViewSummaryItem  summaryItem1；



  private void LoadData()

{

	tbladapter.fillbydate(ds.tbla,begindate,enddate);


     summaryItem1 = new GridViewSummaryItem("Id", "Sum of Id: {0}", GridAggregateFunction.Sum);
     var summaryRow1 = new GridViewSummaryRowItem(new[] {summaryItem1});



       //if I add onece the radgridview can't display in 299 recordset

        radGridView1.SummaryRowsBottom.Add(summaryRow1);

       //if I add two same method the radgridview can display summary ok

       radGridView1.SummaryRowsBottom.Add(summaryRow1);


}

GridView

answered on 29 Mar 2013

2 answers

266 views

[Solved] Insert numbered list programmatically

How can a numbered (or bulleted) list be inserted into a rich text box programmatically?

RichTextBox (obsolete as of Q3 2014 SP1)

answered on 29 Mar 2013

4 answers

747 views

[Solved] Group header and Summary Row

Hello,

I have a gridview which display workitemdata. The columns are "The client", "The service contract", "The Employee", "The Date", "Hours", "Description", "price hour" and "Value (price hour * hours). The client, service contract and employee are ID value not string.

I have made a three level grouping on Client, service contract and Employee.

I have added a summary row for displaying the total of Value by group and an Handler on GroupSummaryEvaluate for displaying an human readable string instead of ID.

But I'm stuck on these problems:

I want only to display the subtotal (the summaryRow) on the client group level (last level). The showParentGroupSummaries properties work for each level (true) or the first level (false).
The GroupSummaryEvaluate handler change the display string of my group header AND my summaryRow.
What are the options for formatting my summaryRow (like text alignment, font, ...)
The group sort my values on ID (column value) before grouping. Is there a way to sort on the readable string after the grouping. I could use a numeric enumeration based on my string instead of an ID for grouping. Just asking if there is a kick tip about this :-)

I join two picture (GroupSummaryEvaluate active/not active) and some code.

Imports System.Data.Objects

Imports Telerik.WinControls.UI

Imports Telerik.WinControls.Data

Public Class View_ValorisationTravail

Private _datactx As IconEntities

Public ReadOnly Property InnerDataContext As IconEntities

Get

Return _datactx

End Get

End Property

Private _dataquery As ObjectQuery(Of Travail)

Public Property DataQuery As ObjectQuery(Of Travail)

Get

Return _dataquery

End Get

Set(value As ObjectQuery(Of Travail))

If _dataquery Is Nothing AndAlso value IsNot Nothing Then

_dataquery = value

OnDataqueryChanged()

End If

If Not _dataquery.Equals(value) Then

_dataquery = value

OnDataqueryChanged()

End If

End Set

End Property

Private Sub View_ValorisationTravail_Load(sender As Object, e As System.EventArgs) Handles Me.Load

If Not Me.DesignMode Then

_datactx = New IconEntities(GetConnection())

'Temporaire en attendant les filtres

Me.DataQuery = GenerateDataQuery()

End If

IntitialiseGroupValorisationTravaux(Me.RadGridView1)

Dim summaryItem As New GridViewSummaryItem("Valeur", "{0:N2} CHF", GridAggregateFunction.Sum)

Dim summaryItemLabel As New GridViewSummaryItem("CHFparheure", "TOTAL", GridAggregateFunction.Sum)

Dim summaryRowItem As New GridViewSummaryRowItem()

summaryRowItem.Add(summaryItem)

summaryRowItem.Add(summaryItemLabel)

Me.RadGridView1.SummaryRowsBottom.Add(summaryRowItem)

Me.RadGridView1.MasterTemplate.ShowParentGroupSummaries = True

End Sub

Private Sub OnDataqueryChanged()

Me.RadGridView1.DataSource = DataQuery.Execute(MergeOption.OverwriteChanges).ToList

End Sub

''' <summary>

''' Generating an ObjectQuery for test purpose

''' </summary>

''' <returns></returns>

''' <remarks></remarks>

Private Function GenerateDataQuery() As ObjectQuery(Of Travail)

Dim query = From c In _datactx.Travail

Select c

Return query

End Function

Private GroupClientDescriptor As GroupDescriptor

Private GroupPrestationDescriptor As GroupDescriptor

Private GroupCollaborateurDescriptor As GroupDescriptor

''' <summary>

''' Build the group

''' </summary>

''' <param name="aGridView"></param>

''' <remarks></remarks>

Private Sub IntitialiseGroupValorisationTravaux(aGridView As RadGridView)

aGridView.EnableGrouping = True

aGridView.AutoExpandGroups = True

aGridView.GroupDescriptors.Clear()

Dim SortClientDescriptor As New SortDescriptor("Client", System.ComponentModel.ListSortDirection.Ascending)

GroupClientDescriptor = New GroupDescriptor()

GroupClientDescriptor.GroupNames.AddRange(New Telerik.WinControls.Data.SortDescriptor() {SortClientDescriptor})

Dim SortPrestationDescriptor As New SortDescriptor("Prestation", System.ComponentModel.ListSortDirection.Ascending)

GroupPrestationDescriptor = New GroupDescriptor()

GroupPrestationDescriptor.GroupNames.AddRange(New Telerik.WinControls.Data.SortDescriptor() {SortPrestationDescriptor})

Dim SortCollaborateurDescriptor As New SortDescriptor("Collaborateur", System.ComponentModel.ListSortDirection.Ascending)

GroupCollaborateurDescriptor = New GroupDescriptor()

GroupCollaborateurDescriptor.GroupNames.AddRange(New Telerik.WinControls.Data.SortDescriptor() {SortCollaborateurDescriptor})

aGridView.GroupDescriptors.AddRange(New

Telerik.WinControls.Data.GroupDescriptor() {GroupClientDescriptor, GroupPrestationDescriptor, GroupCollaborateurDescriptor})

End Sub

Private Sub Travaux_GroupSummaryEvaluate(ByVal sender As Object, ByVal e As Telerik.WinControls.UI.GroupSummaryEvaluationEventArgs) Handles RadGridView1.GroupSummaryEvaluate

If e.Group.GroupDescriptor.Equals(GroupClientDescriptor) Then

If e.Group.ItemCount > 0 AndAlso e.Group.Item(0).DataBoundItem IsNot Nothing Then

e.FormatString = CType(e.Group.Item(0).DataBoundItem.Client, Client).Display

End If

ElseIf e.Group.GroupDescriptor.Equals(GroupPrestationDescriptor) Then

If e.Group.ItemCount > 0 AndAlso e.Group.Item(0).DataBoundItem IsNot Nothing Then

e.FormatString = CType(e.Group.Item(0).DataBoundItem.Prestation, Prestation).Display

End If

ElseIf e.Group.GroupDescriptor.Equals(GroupCollaborateurDescriptor) Then

If e.Group.ItemCount > 0 AndAlso e.Group.Item(0).DataBoundItem IsNot Nothing Then

e.FormatString = CType(e.Group.Item(0).DataBoundItem.ContratEngagement.Collaborateur, Collaborateur).DisplayName

End If

End Sub

End Class

GridView

answered on 29 Mar 2013

1 answer

116 views

[Sitefinity 5.0.25] radcombobox not working in IExplorer10

Hello
In my website I have lots of pages using Comboox component
Users browsing with IExplorer 10 have revealed that the combo were empty, even if they are correctly bound to sql database
I do not have IE10; with Chrome, Firefox and former versions of IExplorer all is OK.
How can i fix this 'bug'? Is it just a problem of Sitefinity updates?
Is it possible to force a WebApplication to open in IE10 in compatibility mode?
Thanks in advance
Diego

ComboBox and ListBox (obsolete as of Q2 2010)

answered on 29 Mar 2013

5 answers

303 views

[Solved] Error in *.Designer.cs file

I am getting this error in my designer file.

//

// radPageViewPage_Template

//

// TODO: Code generation for '' failed because of Exception 'Invalid Primitive Type: System.IntPtr. Consider using CodeObjectCreateExpression.'.

this.radPageViewPage_Template.Controls.Add(this.radGridView_PlanTemplates);

this.radPageViewPage_Template.Location = new System.Drawing.Point(10, 37);

this.radPageViewPage_Template.Name = "radPageViewPage_Template";

this.radPageViewPage_Template.Size = new System.Drawing.Size(307, 502);

this.radPageViewPage_Template.Text = "Templates";

PageView

answered on 28 Mar 2013

9 answers

295 views

[Solved] Scheduler Navigator Text

Is there a way to change the Navigation text for the Month view to not show the dates but rather the month as in Outlook

Scheduler and Reminder

answered on 28 Mar 2013

3 answers

207 views

SummaryRowGroupHeaders Propertys

How to set font styles with colors while grouping Grid View Rows??

GridView

answered on 27 Mar 2013

3 answers

817 views

Disable changing cursor in Gridview cell

Hello,

in my DataGridView I have a column for E-Mail adresses. The user clicks on the E-Mail adress and my programm opens a new E-Mail.
When the mouse is over the E-Mail adress I have this CellMouseMove Event to change the Cursor (to Cursor.Hand):

private void dg_CustomerContact_CellMouseMove(object sender, MouseEventArgs e)

{

GridDataCellElement cell = this.dg_CustomerContact.RootElement.ElementTree.GetElementAtPoint(e.Location) as GridDataCellElement;

if (cell != null && ((GridViewDataColumn)cell.ColumnInfo).Name == "dg_TalkedWith_col_Email")

{

originalCursor = this.dg_CustomerContact.Cursor;

this.dg_CustomerContact.Cursor = Cursors.Hand;

}

else

{

if (originalCursor != null)

{

this.dg_CustomerContact.Cursor = originalCursor;

originalCursor = Cursors.Default;

}

But when there is no E-Mail adress the cursor should not change to "Cursor.Hand". Any suggestion how to solve this?

GridView

answered on 27 Mar 2013

5 answers

309 views

[Solved] Custom trackbar editor keeps the value displayed underneath

Using the custom editor code sample for Telerik winforms found on the Telerik website, I override the BaseInputEditor
to provide my propertyGrid with a trackbar editor.

Now, I implemented the onEditorRequired method as explained to replace the basic edition mode for
any int property.

I'm using the RadPropertyStore mechanism to fill my property grid.

I've no problem with having the value displayed as a number when the editor is not activated, but I'm
not willing to have the value being displayed underneath the track bar as I'm editing the value.

Anyway, I would be looking for having the track bar always displayed even if the property is not being
edited as it will be used for an opacity setting.

Thanks in advance,
Antoine

PropertyGrid

answered on 27 Mar 2013

1 answer

193 views

How to toggle resources to view

Hello,

I only want one given resource to be viewed at any point on the scheduler. I have multiple resources, but I cannot seem to find out how to toggle which resource should be viewed. It just shows the first resource I added to the collection, and then at runtime I can't see a way to toggle between those resources:

Also, I forgot to dereference a radscheduler from a navigator, and now I am unable to add a new radschedulenavigator from the toolbox as many exceptions will be thrown:

Scheduler and Reminder

answered on 27 Mar 2013
