[Solved] Weird Layout of RadGrid

4 Answers 117 Views

Grid

This is a migrated thread and some comments may be shown as answers.

Duke asked on 12 Aug 2013, 10:58 PM


I created a grid list. However the UI does not display properly in IE 9. It works in Chrome. Can anyone help me?
Page Code:

<%@ Page Title="" Language="C#" MasterPageFile="~/APPmaster.master" AutoEventWireup="true" CodeFile="FacultyAdvisorBulkUpload.aspx.cs" Inherits="Common.Common_FacultyAdvisorBulkUpload" %>

<asp:Content ID="Content1" ContentPlaceHolderID="ContentPlaceHolder1" Runat="Server">

<script type="text/javascript">

function DownloadTemplate() {

var url = '../Common/Templates/FacultyAdvisors.csv';

//location.href = url;

window.open(url, 'Download');

}

</script>

<script type="text/javascript">

// This function helps to make the page tab fit the height of RadGrid

function GridCreated(sender, args) {

//alert(document.getElementById(sender.get_id()).clientHeight);

var gridObj = document.getElementById(sender.get_id());

var tabObj = document.getElementById('<%=RadMultiPage.ClientID %>');

var searchObj = document.getElementById('search-area');

tabObj.style.height = (gridObj.clientHeight + searchObj.clientHeight) + 'px';

}

// When clicking export, disable the AJAX

function onRequestStart(sender, args) {

if (args.get_eventTarget().indexOf("ExportTo") >= 0) {

args.set_enableAjax(false);

}

</script>

<br /><br />

<telerik:RadTabStrip runat="server" ID="RadTabStrip" Skin="Outlook"

SelectedIndex="0" MultiPageID="RadMultiPage">

<Tabs>

<telerik:RadTab Text="Advisor List" ToolTip="View Faculty Advisor Relationship" />

<telerik:RadTab Text="Advisor Bulk Update" ToolTip="Tool to Import Grades to APP." runat="server" />

</Tabs>

</telerik:RadTabStrip>

<telerik:RadMultiPage runat="server" ID="RadMultiPage" SelectedIndex="0" CssClass="pageView">

<telerik:RadPageView runat="server" ID="RadPageView" >

<telerik:RadAjaxLoadingPanel ID="RadAjaxLoadingPanel1" runat="server" Skin="Hay">

</telerik:RadAjaxLoadingPanel>

<div id="search-area" style="padding:10px 0 20px 0;">

<b>Faculty Name:</b> <telerik:RadTextBox ID="FacultyNameCond" runat="server" /> <b>Student Name:</b> <telerik:RadTextBox ID="StudentNameCond" runat="server" /> <b>Class:</b> <telerik:RadComboBox ID="ClassCond" runat="server" ViewStateMode="Enabled" />

<telerik:RadButton ID="SearchButton" runat="server" Text="Search" OnClick="SearchButton_Click" />

<telerik:RadButton ID="ExportButton" runat="server" Text="Export to XLS" OnClick="ExportButton_Click" />

</div>

<telerik:RadAjaxPanel ID="RadAjaxPanel1" runat="server" LoadingPanelID="RadAjaxLoadingPanel1" ClientEvents-OnRequestStart="onRequestStart">

<telerik:RadGrid runat="server" ID="RadGridAdvisorList" Skin="Hay" Width="900px" GridLines="None" OnItemDataBound="RadGridAdvisorList_ItemDataBound"

AutoGenerateColumns="False" AllowPaging="true" AllowSorting="true" AllowFilteringByColumn="false" HeaderStyle-Font-Bold="true" HeaderStyle-Font-Size="Small">

<PagerStyle Mode="NextPrevAndNumeric" />

<MasterTableView DataKeyNames="ID" ClientDataKeyNames="ID" PageSize="10" AllowMultiColumnSorting="true">

<GroupByExpressions>

<telerik:GridGroupByExpression>

<GroupByFields>

<telerik:GridGroupByField FieldName="FacultyName" />

</GroupByFields>

<SelectFields>

<telerik:GridGroupByField FieldName="FacultyName" />

</SelectFields>

</telerik:GridGroupByExpression>

</GroupByExpressions>

<CommandItemSettings ShowAddNewRecordButton="false" />

<Columns>

<telerik:GridBoundColumn DataField="FacultyName" HeaderText="Faculty Name" Display="false" />

<telerik:GridBoundColumn DataField="FacultyID" HeaderText="Faculty Email" Display="false" />

<telerik:GridImageColumn DataType="System.String" DataImageUrlFields="ImageLink"

DataImageUrlFormatString="~/Pics/{0}" AlternateText="Student image" DataAlternateTextField="StudentName"

ImageAlign="Middle" ImageWidth="57px" ImageHeight="72px" AllowFiltering="false" HeaderStyle-Width="64px" />

<telerik:GridBoundColumn DataField="StudentName" HeaderText="Student Name" AllowFiltering="false" HeaderStyle-Width="160px" />

<telerik:GridBoundColumn DataField="StudentID" HeaderText="Student ID" AllowFiltering="false" HeaderStyle-Width="90px" />

<telerik:GridBoundColumn DataField="Email" HeaderText="Email" AllowFiltering="false" HeaderStyle-Width="160px" />

<telerik:GridBoundColumn DataField="Status" HeaderText="Status" AllowFiltering="false" HeaderStyle-Width="160px" />

<telerik:GridBoundColumn DataField="Class" HeaderText="Class" AllowFiltering="false" HeaderStyle-Width="90px" />

<%--

<telerik:GridTemplateColumn>

<ItemTemplate>

<input type="image" src="../Styles/Images/Snapshot.gif" alt="Select" />

</ItemTemplate>

</telerik:GridTemplateColumn>

--%>

</Columns>

</MasterTableView>

<ClientSettings>

<Selecting AllowRowSelect="true" />

<ClientEvents OnGridCreated="GridCreated" />

</ClientSettings>

</telerik:RadGrid>

</telerik:RadAjaxPanel>

</telerik:RadPageView>

<telerik:RadPageView runat="server" ID="BulkUploadView">

<div class="pageTitle"><b>Advisor Bulk Update</b></div>

<div id="ContainerDiv" class="legendBorderStaff" style="Height: 200px;">

<div class="tabWrapper">

<div class="regularLabel">

1. Download Template (if necessary):

<br />

<button id="btnTemplate" onclick="javascript:DownloadTemplate();" title="Download Template" >Download</button

<%--<asp:Button ID="Button1" runat="server" Text="Download" ToolTip="Download the proper template." onclick="BtnTemplate_Click" /> --%>

<br /><br />

2. Select the file:

<telerik:RadUpload ID="RadUpload" runat="server" Skin="Outlook" AllowedFileExtensions="csv" />

<asp:CustomValidator ID="CustomValidator1"

runat="server"

CssClass="errorLabel"

ErrorMessage="Please select at least one CSV file."

OnServerValidate="CustomValidator1_ServerValidate">

</asp:CustomValidator>

<br />

3. Submit your file:

<br />

<asp:Button ID="BtnSumbit" runat="server" Text="Import" ToolTip="Import advisors into APP system." onclick="BtnSumbit_Click" Width="150px" />

</div>

<br />

<div class="errorLabel">

<asp:Image ID="SuccessImg" runat="server" ImageUrl="../Images/success.gif" Visible="false" />

<asp:Image ID="ErrorImg" runat="server" ImageUrl="../Images/error.gif" Visible="false" />

<asp:Label ID="OutputLabel" ForeColor="Red" runat="server" Visible="false" />

</div>

<div class="details" >

<asp:Label ID="lblReport" runat="server" />

</div>

</telerik:RadPageView>

</telerik:RadMultiPage>

</asp:Content>

4 Answers, 1 is accepted

answered on 19 Aug 2013, 04:28 PM

Hi,Kostadin.
I haven't try to build another new grid to test the bug and I am busy on projects.
What I know about this issue:
Suppose you created an 7-column grid with group expression and 3 of them are set to Display="False". When I debugged the project, it works. The group header colspan property will be set to 7. However, I published the project to IIS, our production server. The colspan looks like to be set to 4 so the rest 3 will display as a white space (you can see the attachment I uploaded before), ONLY in IE 9. Chrome does not have this problem.

answered on 22 Aug 2013, 07:30 AM

Hello Duke,

Our developers successfully reproduced the issue and they have already working of fixing this bug. You could track the progress in our Ideas & Feedback portal. Additionally you could use the following JavaScript code in order to workaround the unwanted behaviour.

<script type="text/javascript">

function onGridCreated(sender) {

return;

if ($telerik.isIE7) {

var visibleColumns = 0,

columns = sender.get_masterTableView().get_columns();

for (var i = 0; i < columns.length; i++) {

if (columns[i].get_visible() && columns[i].get_element().className.indexOf("rgGroupCol") == -1)

visibleColumns++;

}

var groupHeaders = $telerik.getElementsByClassName(sender.get_element(), "rgGroupHeader");

for (var i = 0; i < groupHeaders.length; i++) {

groupHeaders[i].getElementsByTagName("td")[1].colSpan = visibleColumns;

}

</script>

Regards,
Kostadin
Telerik
