[Solved] RadGrid Create spacer between columns (only IE8)

[Patric Forsgard]

Hi.

When implementing RadGrid and set the following properties from c# it will almost work correct.

grid.ClientSettings.Scrolling.AllowScroll = true;

grid.ClientSettings.Scrolling.UseStaticHeaders = true;

IE8 (Withoud compability mode) will render a blank spacer between 2 columns. See attached file and the spacer between columns is in the red rectangle. FF, Safari and Chrome will all render the grid correct.

Can I recalculate the column width, with javascript, to avoid the spacer or any other suggestions?

// Patric

[Dimo]

Hi Patric,

The observed behavior is caused by a browser bug. IE8 has a problem with fixed-layout tables in the case when they are initially displayed in a very small area and then expanded - gaps between the column headers appear. This is usually reproduced when RadGrid is placed inside a RadSplitter with a percentage dimensions. Possible (but not always applicable) workarounds include setting pixel widths for all columns, using an auto layout for the MasterTableView, setting a pixel width to the parent splitter pane, removing RadGrid cell paddings.

Untill we find a better way to resolve the problem, here is a workaround:





1. Set a CSS class to the RadGrid, which will remove all cell paddings and borders:



<telerik:RadGrid  ID="RadGrid1"  CssClass="NoPaddingGrid" />



.NoPaddingGrid td,
.NoPaddingGrid th
{
    padding:0 !important;
    border:0 !important;
}





2. Subscribe to the splitter's ClientLoaded event and restore the RadGrid paddings and borders by removing the additional CSS class. If you are not using a RadSplitter around the RadGrid, then you have to subscribe to some other event, which is fired after the page has loaded.



<telerik:RadSplitter OnClientLoaded="MyClientLoaded" />





<telerik:RadCodeBlock ID="RadCodeBlock1" runat="server">
<script type="text/javascript">

function MyClientLoaded(sender, args)
{
     var gridElement = $get("<%= RadGrid1.ClientID %>");
     gridElement.className = gridElement.className.replace("NoPaddingGrid", "");
}

</script>
</telerik:RadCodeBlock>

Let us know if you need further assistance. You may have to send a runnable demo, so that we can see what your scenario is and how to address the issue.

Best wishes,
Dimo
