[Solved] Newbie with RadGrid question on manual insert/update

[David]

Hi,

I am converting a VS2008 application to use Telerik controls, and I am starting with RadGrid. In my test I have made a RadGrid that I populate from a linq query. The grid draws fine, paging works and the edit/insert/delete works from the user interface. When I try to do an insert or update I can't seem to get at the underlying data. I have tried a couple ways to do this (based on the online examples) and I'm stumped. I suspect I am missing something simple.

Here is the aspx:

<%@ Page Title="" Language="vb" AutoEventWireup="false" MasterPageFile="~/main.Master" CodeBehind="adminMetrics.aspx.vb" Inherits="BPS.adminMetrics" %>
<%@ Register src="controls/nav.ascx" tagname="nav" tagprefix="uc1" %>
<%@ Register src="controls/msg.ascx" tagname="msg" tagprefix="uc2" %>
<%@ Register TagPrefix="telerik" Namespace="Telerik.Web.UI" Assembly="Telerik.Web.UI" %>
<asp:Content ID="Content1" ContentPlaceHolderID="head" runat="server">
</asp:Content>
<asp:Content ID="Content2" ContentPlaceHolderID="body" runat="server">
    <uc1:nav ID="nav1" runat="server" />
    <uc2:msg ID="msg1" runat="server" />
    <telerik:RadScriptManager runat="server" ID="RadScriptManager1" />
    <telerik:RadSkinManager ID="QsfSkinManager" runat="server" ShowChooser="false" />
    <telerik:RadFormDecorator ID="QsfFromDecorator" runat="server" DecoratedControls="All" EnableRoundedCorners="false" />


    <telerik:RadCodeBlock ID="RadCodeBlock1" runat="server">
        <script type="text/javascript">
            function rowDblClick(sender, eventArgs)
            {
                sender.get_masterTableView().editItem(eventArgs.get_itemIndexHierarchical());
            }
        </script>
    </telerik:RadCodeBlock>

    <telerik:RadAjaxManager ID="RadAjaxManager1" DefaultLoadingPanelID="RadAjaxLoadingPanel1" runat="server">
        <AjaxSettings>
            <telerik:AjaxSetting AjaxControlID="rgMetrics">
                <UpdatedControls>
                    <telerik:AjaxUpdatedControl ControlID="rgMetrics"></telerik:AjaxUpdatedControl>
                    <telerik:AjaxUpdatedControl ControlID="RadWindowManager1" />
                    <telerik:AjaxUpdatedControl ControlID="RadInputManager1" />
                </UpdatedControls>
            </telerik:AjaxSetting>

        </AjaxSettings>
    </telerik:RadAjaxManager>

    <telerik:RadAjaxLoadingPanel ID="RadAjaxLoadingPanel1" runat="server">
    </telerik:RadAjaxLoadingPanel>

    <telerik:RadGrid ID="rgMetrics" AllowPaging="True" runat="server" AutoGenerateColumns="false" PageSize="10" Width="500px">
        <MasterTableView DataKeyNames="MetricID" CommandItemDisplay="Top" InsertItemPageIndexAction="ShowItemOnCurrentPage"
                AllowPaging="True">
            <Columns>
                <telerik:GridBoundColumn DataField="MetricID" HeaderText="Metric ID" ReadOnly="true" ForceExtractValue="Always" ConvertEmptyStringToNull="true"/>
                <telerik:GridBoundColumn DataField="Name" HeaderText="Name" />
                <telerik:GridDropDownColumn DataSourceID="SqlMetricTypeSource" ListTextField="Name" ListValueField="MetricTypeID" UniqueName="MetricTypeDownDownColumn"
                SortExpression="Name" HeaderText="Metric Type" DropDownControlType="DropDownList" DataField="MetricTypeID"></telerik:GridDropDownColumn>
                <telerik:GridEditCommandColumn ButtonType="ImageButton" />
                <telerik:GridButtonColumn ConfirmText="Delete this metric?" ConfirmDialogType="RadWindow"
                    ConfirmTitle="Delete" ButtonType="ImageButton" CommandName="Delete" />
            </Columns>
            <EditFormSettings>
                <EditColumn ButtonType="ImageButton"/>
            </EditFormSettings>
       </MasterTableView>
       <PagerStyle Mode="NextPrevAndNumeric" />
        <ClientSettings>
            <ClientEvents OnRowDblClick="rowDblClick" />
        </ClientSettings>
    </telerik:RadGrid>

    <telerik:RadInputManager runat="server" ID="RadInputManager1" Enabled="true">
        <telerik:TextBoxSetting BehaviorID="TextBoxSetting1">
        </telerik:TextBoxSetting>

    </telerik:RadInputManager>

    <telerik:RadWindowManager ID="RadWindowManager1" runat="server" />

    <asp:SqlDataSource runat="server" ID="SqlMetricTypeSource" ConnectionString="<%$ ConnectionStrings:BPSConnectionString  %>"
        SelectCommand="SELECT MetricTypeID, name FROM bps_MetricType"></asp:SqlDataSource>

</asp:Content>
<asp:Content ID="Content3" ContentPlaceHolderID="foot" runat="server">
</asp:Content>

Here is the .vb:

Imports Telerik.Web.UI
Imports System.Linq

Partial Public Class adminMetrics
    Inherits BaseWebPage

    Protected Sub Page_Load(ByVal sender As Object, ByVal e As System.EventArgs) Handles Me.Load
        If Not emp.HasPemission("Administer Groups") Then
            Response.Redirect("login.aspx")
        End If

    End Sub

    Private Sub rgMetrics_NeedDataSource(ByVal sender As Object, ByVal e As Telerik.Web.UI.GridNeedDataSourceEventArgs) Handles rgMetrics.NeedDataSource
        Dim m As New metric
        rgMetrics.DataSource = m.GetMetrics
    End Sub

    Private Sub rgMetrics_UpdateCommand(ByVal sender As Object, ByVal e As Telerik.Web.UI.GridCommandEventArgs) Handles rgMetrics.UpdateCommand
        Dim editableItem = (DirectCast(e.Item, GridEditableItem))
        Dim MetricID = DirectCast(editableItem.GetDataKeyValue("MetricID"), Integer)

        Dim x As New metric
        x.LoadMetric(MetricID)

        editableItem.UpdateValues(x.data)

        x.Update()
    End Sub

    Private Sub rgMetrics_DeleteCommand(ByVal sender As Object, ByVal e As Telerik.Web.UI.GridCommandEventArgs) Handles rgMetrics.DeleteCommand
        RadAjaxManager1.ResponseScripts.Add(String.Format("window.radalert(""Sorry, deleting tasks is not supported!"")"))
    End Sub

    Private Sub rgMetrics_InsertCommand(ByVal sender As Object, ByVal e As Telerik.Web.UI.GridCommandEventArgs) Handles rgMetrics.InsertCommand
        Dim editableItem = (DirectCast(e.Item, GridEditableItem))

        Dim o As Object

        ' Tesing to see if I can manually find a control! (Nope, didn't work)
        For Each o In editableItem.Controls
            If TypeOf o Is TextBox Then
                RadAjaxManager1.ResponseScripts.Add(String.Format("window.radalert(""Found a textbox with a value of " & o.text & """)"))
            End If
        Next

        Dim values As New Hashtable()
        editableItem.ExtractValues(values)

        Dim x As New metric
        x.data.name = DirectCast(values("name"), String)
        x.data.MetricTypeID = Integer.Parse(values("MetricTypeID").ToString)
        x.Update()

    End Sub

    Private Sub rgMetrics_ItemCreated(ByVal sender As Object, ByVal e As Telerik.Web.UI.GridItemEventArgs) Handles rgMetrics.ItemCreated
        If TypeOf e.Item Is GridEditableItem AndAlso (e.Item.IsInEditMode) Then
            Dim editableItem As GridEditableItem = DirectCast(e.Item, GridEditableItem)
            SetupInputManager(editableItem)
        End If

    End Sub

    Private Sub SetupInputManager(ByVal editableItem As GridEditableItem)
        ' style and set ProductName column's textbox as required
        Dim textBox = (DirectCast(editableItem.EditManager.GetColumnEditor("Name"), GridTextBoxColumnEditor)).TextBoxControl

        Dim inputSetting As InputSetting = RadInputManager1.GetSettingByBehaviorID("TextBoxSetting1")
        inputSetting.TargetControls.Add(New TargetInput(textBox.UniqueID, True))
        inputSetting.InitializeOnClient = True
        inputSetting.Validation.IsRequired = True

        '' style UnitPrice column's textbox
        'textBox = (DirectCast(editableItem.EditManager.GetColumnEditor("UnitPrice"), GridTextBoxColumnEditor)).TextBoxControl

        'inputSetting = RadInputManager1.GetSettingByBehaviorID("NumericTextBoxSetting1")
        'inputSetting.InitializeOnClient = True
        'inputSetting.TargetControls.Add(New TargetInput(textBox.UniqueID, True))

        '' style UnitsInStock column's textbox
        'textBox = (DirectCast(editableItem.EditManager.GetColumnEditor("UnitsInStock"), GridTextBoxColumnEditor)).TextBoxControl

        'inputSetting = RadInputManager1.GetSettingByBehaviorID("NumericTextBoxSetting2")
        'inputSetting.InitializeOnClient = True
        'inputSetting.TargetControls.Add(New TargetInput(textBox.UniqueID, True))
    End Sub

    Protected Sub rgMetrics_ItemDeleted(ByVal source As Object, ByVal e As Telerik.Web.UI.GridDeletedEventArgs) Handles rgMetrics.ItemDeleted
        If e.Exception IsNot Nothing Then
            e.ExceptionHandled = True
            ShowErrorMessage()
        End If
    End Sub

    Protected Sub rgMetrics_ItemInserted(ByVal source As Object, ByVal e As Telerik.Web.UI.GridInsertedEventArgs) Handles rgMetrics.ItemInserted
        If e.Exception IsNot Nothing Then
            e.ExceptionHandled = True
            ShowErrorMessage()
        End If
    End Sub

    Protected Sub rgMetrics_ItemUpdated(ByVal source As Object, ByVal e As Telerik.Web.UI.GridUpdatedEventArgs) Handles rgMetrics.ItemUpdated
        If e.Exception IsNot Nothing Then
            e.ExceptionHandled = True
            ShowErrorMessage()
        End If
    End Sub

    ''' <summary>
    ''' Shows a <see cref="RadWindow"/> alert if an error occurs
    ''' </summary>
    Protected Sub ShowErrorMessage()
        RadAjaxManager1.ResponseScripts.Add(String.Format("window.radalert(""Please enter valid data!"")"))
    End Sub



    Protected Sub rgMetrics_PreRender(ByVal sender As Object, ByVal e As System.EventArgs) Handles rgMetrics.PreRender
        If (Not IsPostBack AndAlso rgMetrics.MasterTableView.Items.Count > 0) Then
            rgMetrics.MasterTableView.Items(1).Expanded = True
        End If
    End Sub


End Class

Thanks for any help, I'm stumped!

[Vasil]

Hello David,

Check this help topic about accessing controls inside the RadGrid:
http://www.telerik.com/help/aspnet-ajax/grid-accessing-cells-and-rows.html
Also examine the code of this online demo, which shows how to get the values of the controls when handling the UpdateCommand event.
http://demos.telerik.com/aspnet-ajax/grid/examples/dataediting/editmodes/defaultvb.aspx

Regards,
Vasil
the Telerik team
