Questions on UI for WinForms Forum

0 answers

57 views

How to acces other members value asosociated with a treeView node

I had created a radTree binded with sqldatabase
node creation,deletion etc are working fine
Table is like this
Table 1
CREATE TABLE [dbo].[Node0] (
[Node0ID] INT IDENTITY (1, 1) NOT NULL,
[NodeID] INT NULL,
[Node0Name] TEXT NULL,
[Node0Note] TEXT NULL,
PRIMARY KEY CLUSTERED ([Node0ID] ASC)
);

Table 2
CREATE TABLE [dbo].[Node1] (
[Node1ID] INT IDENTITY (1, 1) NOT NULL,
[Node0ID] INT NULL,
[Node1Name] TEXT NULL,
[Node1Note] TEXT NULL,
PRIMARY KEY CLUSTERED ([Node1ID] ASC)
);
Table 3
CREATE TABLE [dbo].[Node2] (
[Node2ID] INT IDENTITY (1, 1) NOT NULL,
[Node1ID] INT NULL,
[Node2Name] TEXT NULL,
[Node2Note] TEXT NULL,
PRIMARY KEY CLUSTERED ([Node2ID] ASC)
);

i want to access Node2Note (value of Node2Note for the selected node)when i clicked a node corresponding to it.Any way?

Treeview

answered on 26 Dec 2012

2 answers

103 views

How to update a binded radTree

I had binded rad tree with an sql database.it is showing nodes perfectly.Using default context menu i add more nodes to the tree.how to save these newly added nodes back to data base like method provided to update scheduler when it is attached to a databse

Treeview

answered on 26 Dec 2012

1 answer

194 views

RadProgress bar fails to update.

I'm not understanding why it fails to update in another thread correctly if the process is running fast. Example

If I do this, this will freeze the progress bar until its completed. It will get to a certain spot then stop.

radProgressBar2.Maximum = 1500;

for (var i = 1; i < 1500; i++)

{

var p = i;

radProgressBar2.Value1 = p;

Thread.Sleep((int)numericUpDown1.Value);

}

radProgressBar2.Value1 = 0;

radProgressBar2.Text = "Task Completed!";

If i do this

radProgressBar1.Maximum = 1500;

for (var i = 1; i < 1500; i++)

{

var p = i;

radProgressBar1.SafeInvoke(() => radProgressBar1.Value1 = p, false);

Thread.Sleep((int) numericUpDown1.Value);

}

using a custom invoke it works just fine. I dont understand why it doesnt work correctly with the build in feature. This is also happening on the status progress bar as well.. Here is a quick app source.

Also it seems to work with the built in features using Win7 or above, Its freezing on windows xp sp3

Edit: Never mind i can not attach rar, or .zip to this thread.

Uploading a video to demonstrate.

ProgressBar

answered on 25 Dec 2012

3 answers

91 views

Orphaned GridViewTemplate

In my properties window I see two GridViewTemplates:

GridViewTemplate1
GridViewTemplate2

GridViewTemplate2 is not associated with either RadGridView controlsI have on the page. Is there a way to delete this orphaned GridViewTemplate without going into the designer.vb code (I only do that as a last resort)?

Thanks.

GridView

answered on 24 Dec 2012

2 answers

134 views

GridViewComboBoxColumn out of focus when scrolling

Hi,

I'm using Telerik.WinControls.GridView version 2012.1.321.20.
I have a GridView with a GridViewComboBoxColumn, and the problem I have is that when the box is open and I click on the scroll square- than it's like the focus is out and the comboBox is closed (it's like freezing for 2 seconds and than closing...).

Also, I'm using the next definitions, as you recommended before:

public class CustomDropDownListEditor : RadDropDownListEditor

{

protected override RadElement CreateEditorElement()

{

return new CustomDropDownListEditorElement();

}

public class CustomDropDownListEditorElement : RadDropDownListEditorElement

{

protected override RadPopupControlBase CreatePopupForm()

{

this.Popup = new CustomDropDownPopupForm(this);

this.Popup.VerticalAlignmentCorrectionMode = AlignmentCorrectionMode.SnapToOuterEdges;

this.Popup.SizingMode = this.DropDownSizingMode;

this.Popup.Height = this.DropDownHeight;

this.Popup.HorizontalAlignmentCorrectionMode = AlignmentCorrectionMode.Smooth;

this.Popup.RightToLeft = this.RightToLeft ? System.Windows.Forms.RightToLeft.Yes : System.Windows.Forms.RightToLeft.Inherit;

this.WirePopupFormEvents(this.Popup);

return Popup;

}

public class CustomDropDownPopupForm : DropDownPopupForm

{

public CustomDropDownPopupForm(RadDropDownListElement owner): base(owner) {}

public override string ThemeClassName

{

get { return typeof(DropDownPopupForm).FullName; }

set {}

}

public override void ClosePopup(PopupCloseInfo info)

{

base.ClosePopup(info);

if (info.CloseReason == RadPopupCloseReason.Keyboard)

{

((RadGridView)this.OwnerElement.ElementTree.Control).EndEdit();

}

protected override void OnMouseUp(MouseEventArgs e)

{

base.OnMouseUp(e);

((RadGridView)this.OwnerElement.ElementTree.Control).EndEdit();

}

You should handle the EditorRequired event to replace the editor:

void radGridView1_EditorRequired(object sender, EditorRequiredEventArgs e)

{

if (e.EditorType == typeof(RadDropDownListEditor))

{

e.EditorType = typeof(CustomDropDownListEditor);

}

What should I do in order to not loose the focus when click on scrolling? I need the user to scroll up/doun and choose another option from the list.

I'm attaching an image of my comboBox.

Thanks,
Hila.

GridView

answered on 23 Dec 2012

4 answers

266 views

Rad DateTimePicker - Invalid Date Format Exception

Hello,

I use a Rad DateTimePicker in a certain application. What I want to achieve is to get the date that the user selects, along with the time of course, and send those using JScript to an asmx webservice as one of its arguments. What I did was that I sent the datetime as string from the JScript file and in the webservice I tried to parse that string back to datetime format using convert.todatetime method and I tried several other conversion methods but my problem was always one; and that is the string that's being sent is not recognized as a correct "convertible" datetime.

I debugged, and it's always sent as, for example, "2012-12-13-08-02-05" [this corresponds to 13/12/2012 08:02:05]. As you can see, this string really is not in one of the acceptable formats that the parsing methods accept.

I tried to change the input dateformat of the datetimepicker and it does change but only in displaying; it does not change in the string according to what I want [I mean the format I set is reflected on display only and not on save].

I'd really appreciate your help, thank you.

Calendar, DateTimePicker, TimePicker and Clock

answered on 22 Dec 2012

3 answers

102 views

Drag and Drop In two listbox

Hi, i'm trying to do the Drag and Drop like the demo, but my first listbox it's conected with my dataset and when I do the drag and drop, gives me this error:

Data bound items can not be removed. Remove items from the data source instead.

If you can explain to me how to fix this. Thank You.

ComboBox and ListBox (obsolete as of Q2 2010)

answered on 21 Dec 2012

1 answer

148 views

using linq to dynamic create chartview series

For those who might want to use this, I have created a quick sample on how to use linq to create dynamic series for chartview:

Example is created in VS2010 / VB.NET

Make sure you import:
System.Data.DataSetExtensions.dll
to use linq.

Me.RadChartView1.ShowLegend = True

Me.RadChartView1.ShowTitle = True

Me.RadChartView1.Title = "Sold products per country"

Dim graphSeries As New DataTable()

graphSeries.Columns.Add("Category", GetType(String))

graphSeries.Columns.Add("Value", GetType(Integer))

graphSeries.Columns.Add("XValue", GetType(String))

graphSeries.Rows.Add("Netherlands", 10, "2011")

graphSeries.Rows.Add("USA", 12, "2011")

graphSeries.Rows.Add("Germany", 7, "2011")

graphSeries.Rows.Add("Netherlands", 25, "2012")

graphSeries.Rows.Add("USA", 40, "2012")

graphSeries.Rows.Add("Germany", 25, "2012")

Dim productGroups = From p In graphSeries _

Group p By Category = p.Field(Of String)("Category") Into Group _

Select Category, ProductGroup = Group

For Each g In productGroups

Dim barSeries As New Telerik.WinControls.UI.BarSeries("Value", "Category")

barSeries.Name = g.Category

barSeries.ValueMember = "Value"

barSeries.CategoryMember = "XValue"

barSeries.ShowLabels = True

barSeries.LegendTitle = g.Category

Me.RadChartView1.Series.Add(barSeries)

barSeries.CombineMode = Telerik.Charting.ChartSeriesCombineMode.Stack

barSeries.DataSource = g.ProductGroup.CopyToDataTable

Next

ChartView

answered on 21 Dec 2012

1 answer

134 views

Image on commandbar button is not transparent.

I have set bmp images on commandbar buttons on the commandbar strip element. But, the images area not showing transparent..

Please find the attachments

CommandBar

answered on 21 Dec 2012

1 answer

145 views

Paste From Excel into Grid view?

With the standard datagrid view in vs2010, I can highlight several rows in an excel sheet, containing, say title ID numbers, then left click on the datagrid and paste those values into the grid.

Is that even possible with the telerik grid view ?

Thanks.

GridView

answered on 21 Dec 2012
