[Solved] Custom Filter Row - Check Box List

[Vadzim]

Hello

I am implementing Custom Filter Row. The main task is to implement Check Box List in the row filter (multi select).
Could someone please provide information how can I implement Custom Row Filter like Check Box List Filter for Filter menu?



[Hristian Stefanov]

Hi Vadzim,

The easiest way that comes to my mind is to use the TelerikCheckBoxListFilter component we expose and bind the desired collection of values.

I have prepared for you a base example to show the idea and the component usage below. You can use the same approach by configuring it in the FilterCellTemplate for Row Filtering wrapped in a scrollable element.

@using Telerik.DataSource

<TelerikGrid Data=@GridData FilterMode="@GridFilterMode.FilterMenu" FilterMenuType="@FilterMenuType.CheckBoxList"
             Height="400px" Width="600px" Pageable="true">
    <GridColumns>
        <GridColumn Field="Id" Filterable="false" Width="80px" />

        <GridColumn Field="Size" Context="context">
            <FilterMenuTemplate >
                <TelerikCheckBoxListFilter Data="@Sizes"
                                           Field="@(nameof(NameFilterOption.Size))"
                                           @bind-FilterDescriptor="@context.FilterDescriptor">
                </TelerikCheckBoxListFilter>
            </FilterMenuTemplate>
        </GridColumn>

        <GridColumn Field="ProductName" Title="Product" Filterable="false" />
    </GridColumns>
</TelerikGrid>

@code {
    public List<SampleData> GridData { get; set; }

    protected override void OnInitialized()
    {
        GridData = Enumerable.Range(1, 70).Select(x => new SampleData
            {
                Id = x,
                Size = Sizes[x % Sizes.Count].Size,
                ProductName = $"Product {x}",
                TestCheckbox = x % 2 == 0 ? true : false
            }).ToList();
        base.OnInitialized();
    }

    public class SampleData
    {
        public int Id { get; set; }
        public string Size { get; set; }
        public string ProductName { get; set; }
        public bool TestCheckbox { get; set; }
    }

    public List<NameFilterOption> Sizes =
    new List<NameFilterOption>() { new NameFilterOption { Size = "XS" }, new NameFilterOption { Size = "S" }, new NameFilterOption { Size = "M" } };

    public class NameFilterOption
    {
        public string Size { get; set; }
    }
}

I hope that covers the desired result. Let me know if the idea is different or if further information is needed.

Regards,
Hristian Stefanov
Progress Telerik

[Jonathan]

This works in this case because both model's are using the same name for the Field. I tried this today and functionally I found there is a different solution.  This code sample has two models:

SampleData
NameFilterOption

This code references the Filter Option:

<TelerikCheckBoxListFilter Data="@Sizes"
                                           Field="@(nameof(NameFilterOption.Size))"
                                           @bind-FilterDescriptor="@context.FilterDescriptor">
                </TelerikCheckBoxListFilter>

Now when Telerik Grid goes to set the Filters it will set them using FilterDescriptor.Member is coming from the NameFilterOption model, when the Parent Grid is using the FilterDescriptor.Member from the SampleData model. What if the Field name for the Grid and the Field name for the Filter do not match?  Or we don't want to use List<Model> for the Filter we want to use List<string>?

In my case I ended up creating a new Blazor component based upon the example here, passing in the Field name as a Parameter.

Blazor Grid Templates Filter - Telerik UI for Blazor

And...

I had to pass in a different context each time

<GridColumn Field=@nameof(Model.prop1) FilterMenuType="@FilterMenuType.CheckBoxList" Context="context_prop1">

<GridColumn Field=@nameof(Model.prop2) FilterMenuType="@FilterMenuType.CheckBoxList" Context="context_prop2">

<GridColumn Field=@nameof(Model.prop3) FilterMenuType="@FilterMenuType.CheckBoxList" Context="context_prop3">
