Questions on UI for ASP.NET AJAX Forum

4 answers

369 views

Export to Excel not including customized gridtemplatecolumn.

I have a radgrid which includes a customized gridtemplatecolumn. When I export to Excel, it leaves out the customized column. Can someone show me how to export the column? I am attaching my front and backend code and a screenshot. The column name is "Open Items by Age" and includes three data elements. Also, it there a way to clean up the column so it does not have the weird lines showing in the table. I set table border to zero. Thank in advance!

<telerik:RadGrid ID="grdCurrentandPrior" runat="server" AllowSorting="True" AutoGenerateColumns="False"

GridLines="Horizontal" Skin="Web20" Style="margin-right: 0px" Width="897px" Height="252px"

OnNeedDataSource="grdCurrentandPrior_NeedDataSource" OnExcelMLExportRowCreated="grdCurrentandPrior_ExcelMLExportRowCreated"

OnSortCommand="grdCurrentandPrior_SortCommand">

<exportsettings filename="OpenItemsCurrentInventory" ignorepaging="True" openinnewwindow="True"

exportonlydata="true" excel-format="ExcelML">

</exportsettings>

<mastertableview commanditemdisplay="Bottom" allownaturalsort="false" usealldatafields="true">

<CommandItemSettings ShowExportToExcelButton="true" ShowAddNewRecordButton="false"

ShowRefreshButton="false" />

<Columns>

<telerik:GridTemplateColumn DataField="Assignee" HeaderText="Assignee" UniqueName="Assignee"

SortExpression="Assignee">

<HeaderStyle Font-Bold="True" Width="150px" HorizontalAlign="Center" Font-Names="Arial" />

<ItemTemplate>

<asp:Label ID="lbAssignee" runat="server" Text='<%# Eval("Assignee") %>'></asp:Label>

</ItemTemplate>

<FooterStyle HorizontalAlign="Right" Font-Bold="true" />

</telerik:GridTemplateColumn>

<telerik:GridTemplateColumn DataField="State" HeaderText="State" UniqueName="State"

SortExpression="State" Visible="false">

<HeaderStyle Font-Bold="True" Width="150px" HorizontalAlign="Center" Font-Names="Arial" />

<ItemTemplate>

<asp:Label ID="lbState" runat="server" Text='<%# Eval("State") %>'></asp:Label>

</ItemTemplate>

<FooterStyle HorizontalAlign="Right" Font-Bold="true" />

</telerik:GridTemplateColumn>

<telerik:GridTemplateColumn DataField="JurisdictionCount" HeaderText="Jurisdictions"

UniqueName="JurisdictionCount" SortExpression="JurisdictionCount">

<HeaderStyle Font-Bold="True" Width="80px" HorizontalAlign="Center" Font-Names="Arial" />

<ItemTemplate>

<asp:Label ID="lbJurisdiction" runat="server" Text='<%# Eval("JurisdictionCount", "{0:N0}")%>'></asp:Label>

</ItemTemplate>

<ItemStyle HorizontalAlign="Right" ForeColor="Black" />

<FooterStyle HorizontalAlign="Right" Font-Bold="true" />

</telerik:GridTemplateColumn>

<telerik:GridTemplateColumn UniqueName="OpenItemsByAge" >

<HeaderTemplate>

<table id="Table1" cellspacing="0" cellpadding="0" width="300" border="0">

<tr>

<td colspan="3" align="center">

<b>Open Items by Age</b>

</td>

</tr>

<tr>

<td align="center" style="width: 33%">

<asp:LinkButton CssClass="Button" ID="btnPrioOpen" Text="Prior"

CommandName='Sort' CommandArgument='OpenItemsCountPrior' runat="server" /></td>

<td align="center" style="width: 33%">

<asp:LinkButton CssClass="Button" ID="btnLastMonth" Text="Last Month"

CommandName='Sort' CommandArgument='OpenItemsCountLastMonth' runat="server" /></td>

<td align="center" style="width: 34%">

<asp:LinkButton CssClass="Button" ID="btnCurrentOpen" Text="Current"

CommandName='Sort' CommandArgument='OpenItemsCountCurrent' runat="server" /></td>

</tr>

</table>

</HeaderTemplate>

<ItemTemplate >

<table id="Table2" cellspacing="0" cellpadding="0" width="300" border="0">

<tr>

<td align="right" width="33%">

<%# Eval("OpenItemsCountPrior", "{0:N0}") %>

</td>

<td align="right" width="33%">

<%# Eval("OpenItemsCountLastMonth", "{0:N0}")%>

</td>

<td align="right" width="34%">

<%# Eval("OpenItemsCountCurrent", "{0:N0}") %>

</td>

</tr>

</table>

</ItemTemplate>

</telerik:GridTemplateColumn>

<telerik:GridTemplateColumn Visible="False" DataField="OpenItemsCountPrior" HeaderText="Prior Open Items"

UniqueName="OpenItemsCountPrior" SortExpression="OpenItemsCountPrior">

<HeaderStyle Font-Bold="True" Width="80px" HorizontalAlign="Center" Font-Names="Arial" />

<ItemTemplate>

<asp:Label ID="lbPrior" runat="server" Text='<%# Eval("OpenItemsCountPrior", "{0:N0}") %>'></asp:Label>

</ItemTemplate>

<ItemStyle HorizontalAlign="Right" ForeColor="Black" />

<FooterStyle HorizontalAlign="Right" Font-Bold="true" />

</telerik:GridTemplateColumn>

<telerik:GridTemplateColumn Visible="False" DataField="OpenItemsCountLastMonth" HeaderText="Last Month Items"

UniqueName="OpenItemsCountLastMonth" SortExpression="OpenItemsCountLastMonth">

<HeaderStyle Font-Bold="True" Width="80px" HorizontalAlign="Center" Font-Names="Arial" />

<ItemTemplate>

<asp:Label ID="lbLastMonth" runat="server" Text='<%# Eval("OpenItemsCountLastMonth", "{0:N0}") %>'></asp:Label>

</ItemTemplate>

<ItemStyle HorizontalAlign="Right" ForeColor="Black" />

<FooterStyle HorizontalAlign="Right" Font-Bold="true" />

</telerik:GridTemplateColumn>

<telerik:GridTemplateColumn Visible="False" DataField="OpenItemsCountCurrent" HeaderText="Current Open Items"

UniqueName="OpenItemsCountCurrent" SortExpression="OpenItemsCountCurrent">

<HeaderStyle Font-Bold="True" Width="100px" HorizontalAlign="Center" Font-Names="Arial" />

<ItemTemplate>

<asp:Label ID="lbCurrent" runat="server" Text='<%# Eval("OpenItemsCountCurrent", "{0:N0}") %>'></asp:Label>

</ItemTemplate>

<ItemStyle HorizontalAlign="Right" ForeColor="Black" />

<FooterStyle HorizontalAlign="Right" Font-Bold="true" />

</telerik:GridTemplateColumn>

<telerik:GridTemplateColumn DataField="TotalRemainingItems" HeaderText="Items Left to Pay"

UniqueName="TotalRemainingItems" SortExpression="TotalRemainingItems">

<HeaderStyle Font-Bold="True" Width="95px" HorizontalAlign="Center" Font-Names="Arial" />

<ItemTemplate>

<asp:Label ID="lblTotalRemain" runat="server" Text='<%# Eval("TotalRemainingItems", "{0:N0}") %>'></asp:Label>

</ItemTemplate>

<ItemStyle HorizontalAlign="Right" ForeColor="Black" />

<FooterStyle HorizontalAlign="Right" Font-Bold="true" />

</telerik:GridTemplateColumn>

<telerik:GridTemplateColumn DataField="CompleteCount" HeaderText="Complete"

UniqueName="CompleteCount" SortExpression="CompleteCount">

<HeaderStyle Font-Bold="True" Width="80px" HorizontalAlign="Center" Font-Names="Arial" />

<ItemTemplate>

<asp:Label ID="lblCompleteCount" runat="server" Text='<%# Eval("CompleteCount", "{0:N0}") %>'></asp:Label>

</ItemTemplate>

<ItemStyle HorizontalAlign="Right" ForeColor="Black" />

<FooterStyle HorizontalAlign="Right" Font-Bold="true" />

</telerik:GridTemplateColumn>

<telerik:GridTemplateColumn DataField="PercentComplete" HeaderText="% Complete" UniqueName="clmPctComplete"

SortExpression="PercentComplete">

<HeaderStyle Font-Bold="True" Width="85px" HorizontalAlign="Center" Font-Names="Arial" />

<ItemTemplate>

<asp:Label ID="lblPctComplete" runat="server" Text='<%# Eval("PercentComplete", "{0:N2}%")%>'></asp:Label>

</ItemTemplate>

<ItemStyle HorizontalAlign="Right" ForeColor="Black" />

<FooterStyle HorizontalAlign="Right" Font-Bold="true" />

</telerik:GridTemplateColumn>

<telerik:GridBoundColumn DataField="AssigneeEmployeeKey" ReadOnly="True" UniqueName="AssigneeEmployeeKey"

Visible="False">

</telerik:GridBoundColumn>

</Columns>

</mastertableview>

<headerstyle borderstyle="Solid" />

<clientsettings>

<Scrolling AllowScroll="True" UseStaticHeaders="True" />

</clientsettings>

</telerik:RadGrid>

protected void grdCurrentandPrior_ExcelMLExportRowCreated(object source, GridExportExcelMLRowCreatedArgs e)

{

Int32 JurisdictionCount = 0;

Int32 OpenItemsCountPrior = 0;

Int32 OpenItemsCountCurrent = 0;

Int32 TotalRemainingItems = 0;

Int32 LastMonthItemsCount = 0;

Int32 CompleteCount = 0;

foreach (GridDataItem item in grdCurrentandPrior.MasterTableView.Items)

{

Label jc = (Label)item.FindControl("lbJurisdiction");

JurisdictionCount += Int32.Parse(jc.Text.Replace(",", "").Trim());

Label oipc = (Label)item.FindControl("lbPrior");

OpenItemsCountPrior += Int32.Parse(oipc.Text.Replace(",", "").Trim());

Label oicc = (Label)item.FindControl("lbCurrent");

OpenItemsCountCurrent += Int32.Parse(oicc.Text.Replace(",", "").Trim());

Label tr = (Label)item.FindControl("lblTotalRemain");

TotalRemainingItems += Int32.Parse(tr.Text.Replace(",", "").Trim());

Label lc = (Label)item.FindControl("lbLastMonth");

LastMonthItemsCount += Int32.Parse(lc.Text.Replace(",", "").Trim());

Label cc = (Label)item.FindControl("lblCompleteCount");

CompleteCount += Int32.Parse(cc.Text.Replace(",", "").Trim());

}

if (e.Worksheet.Table.Rows.Count == grdCurrentandPrior.Items.Count + 1)

{

RowElement row = new RowElement();

GridFooterItem footer = (source as RadGrid).MasterTableView.GetItems(GridItemType.Footer)[0] as GridFooterItem;

foreach (GridColumn column in (source as RadGrid).MasterTableView.Columns)

{

column.Visible = true;

}

foreach (GridColumn column in (source as RadGrid).MasterTableView.Columns)

{

CellElement cell = new CellElement();

string cellText = "";

if ((column.UniqueName == "Assignee") && (rdoAssignee.Checked == true))

cellText = "Totals";

else

{

if ((column.UniqueName == "State") && (rdoState.Checked == true))

cellText = "Totals";

}

if (column.UniqueName == "JurisdictionCount")

cellText = JurisdictionCount.ToString();

if (column.UniqueName == "OpenItemsCountPrior")

cellText = OpenItemsCountPrior.ToString();

if (column.UniqueName == "OpenItemsCountCurrent")

cellText = OpenItemsCountCurrent.ToString();

if (column.UniqueName == "TotalRemainingItems")

cellText = TotalRemainingItems.ToString();

if (column.UniqueName == "OpenItemsCountLastMonth")

cellText = LastMonthItemsCount.ToString();

if (cellText != "")

{

cell.Data.DataItem = cellText == " " ? "" : cellText;

row.Cells.Add(cell);

}

e.Worksheet.Table.Rows.Add(row);

}

Grid

answered on 03 Aug 2012

1 answer

271 views

EU cookie law

Hi

I have seen it said that the cookie which saves the state of the open items etc is a 'session' cookie.

Does this really mean that it is stored on the server (and therefore not relevant to the EU cookie law) , or is
it stored on the visitor's hard drive (in which case I will have to get permission from the visitors at least for the first visit)?

For most of my client websites, the PanelBar cookie is the only cookie on the site, so it would be handy if I could
forget about it.

Thanks

Clive

PanelBar

answered on 02 Aug 2012

4 answers

131 views

How to create a list of linkbuttons associate with one RadWindow and pass different value to the radwindow

I try to open a RadWindow that will show different data by clicking a list of linkbuttons. These linkbuttons should be created at runtime.
I made that work by the following code example

vb code

For

Each a In aList

' Dynamically create radWindows

'************************************************************************

Dim radWindow As New Telerik.Web.UI.RadWindow

With radWindow

.ID = "radWindow" & a

.Modal = True

.NavigateUrl = "http://test.aspx?a=" & a

End With

' Add new radWindow to radWindowManager

Me.RadWindowManager1.Windows.Add(radWindow)

' Dynamically create linkbutton

' *************************************************************************

Dim lbtnSchool As New LinkButton

With lbtnSchool

.ID = "lbtn" & a

.OnClientClick = "openWindow('" & radWindow.ClientID & "');return false;"

End With

' **************************************************************************

Next

Javascript function

function

openWindow(id) {

var win;

win = $find(id);

win.show();}

However, there is a problem. If I have 100 items to loop, there will be 100 RadWindows added to RadWindowManager. And this is not acceptable. I want to use just one RadWindow and let all linkbuttons call this RadWindow, then pass different data to NavigateUrl . The question is how to pass data to just one RadWindow by different linkbutton?

It will be much easier If there is a server side method, like RadWindow.show() or.open(), which can allow me to open RadWindow in code behind. But seems like the only way to open the RadWindow is using javascript?

Window

answered on 02 Aug 2012

0 answers

96 views

Gif Slow

Good afternoon,

I have a problem with compomente RadWindowManger.
I do not know if it was coincidence, but after my last update version of RadControls p / 2012-2-607, the gif loading of pages seem to be grasping, as if slow, ran quickly before the gif.

Here my code I use to open the pages.

function Baixar() {

window.radopen("Baixa_lote_CtsReceber.aspx", "BaixaLote");

}

<telerik:RadWindowManager id="RadWindowManager1" ShowContentDuringLoad="false" ReloadOnShow="true" runat="server" skin="Outlook" EnableShandow="true" >

<Windows>

<telerik:Radwindow ID="BaixaLote" runat="server" Behaviors="Close,Move" Modal="true" Title="Baixa" Height="655px" Width="975px" />

</Windows>

</telerik:RadWindowManager>

Window

asked on 02 Aug 2012

0 answers

93 views

Manually deleting from grid without sqldatasource

I have a grid

<telerik:RadGrid ID="RadGridFeedings" runat="server" AllowAutomaticInserts="True" AllowAutomaticUpdates="True" AllowAutomaticDeletes="True" AutoGenerateColumns="false" AllowPaging="True" AllowSorting="True" PageSize="10" skin="Default">
                            <PagerStyle Mode="NumericPages" />
                            <GroupingSettings CaseSensitive="false" />
                            <MasterTableView TableLayout="Fixed" Width="100%" CommandItemDisplay="top" DataKeyNames="FeedID" AutoGenerateColumns="false">
                                <Columns>
                                    <telerik:GridDateTimeColumn HeaderText="Date" DataField="FeedDate" UniqueName="FeedDate"
                                        SortExpression="FeedDate" HeaderStyle-Width="20%" ShowFilterIcon="false" DataFormatString="{0:dd/MM/yyyy}" />
                                    <telerik:GridBoundColumn HeaderText="Type" DataField="FoodType" UniqueName="FoodType"
                                        SortExpression="FoodType" HeaderStyle-Width="23%" ShowFilterIcon="false" />
                                    <telerik:GridBoundColumn HeaderText="Size" DataField="FoodSize" UniqueName="FoodSize"
                                        SortExpression="FoodSize" HeaderStyle-Width="22%" ShowFilterIcon="false" />
                                    <telerik:GridBoundColumn HeaderText="Result" DataField="Result" UniqueName="Result"
                                        SortExpression="Result" HeaderStyle-Width="22%" ShowFilterIcon="false" />
                                    <telerik:GridButtonColumn ConfirmText="Delete this product?" ConfirmDialogType="RadWindow"
                    ConfirmTitle="Delete" ButtonType="ImageButton" CommandName="Delete" Text="Delete"
                    UniqueName="DeleteColumn">
                    <ItemStyle HorizontalAlign="Center"/>
                </telerik:GridButtonColumn>
                                </Columns>
                            </MasterTableView>
                        </telerik:RadGrid>

that is being loaded using a datatable via the code behind

Dim dtFeedings As DataTable = RVSelect.SelectFeedings(-1, -1, Request.QueryString("AnimalID"), "", -1, -1, "").Tables(0)

RadGridFeedings.DataSource = dtFeedings

RadGridFeedings.DataBind()

How do I get the edit/delete buttons working in this scenario as all the examples use sqldatasources or linqdatasources?

Many thanks
Simon

Grid

asked on 02 Aug 2012

1 answer

108 views

[Solved] Deleting a column and get the column count

I am new to programming i facing a situation where i need to delete a column to find the new column count of the radgrid.

Private Sub btnNext_Click(ByVal sender As Object, ByVal e As System.EventArgs) Handles btnNext.Click

rgdGridOutput.DataSource = ds.Tables(intTableCount)
rgdGridOutput.DataBind()
Dim x As Integer = rgdGridOutput.MasterTableView.Columns.Count

rgdGridOutput.MasterTableView.GetColumn("ServiceOutput_Id").Visible = False
rgdGridOutput.MasterTableView.GetColumn("ServiceResponse_Id").Visible = False

Dim y As Integer = rgdGridOutput.MasterTableView.Columns.Count
end Sub

I am getting both x and y values as 0. Actually table has 3 columns.

Thanks,
Ajay

Grid

answered on 02 Aug 2012

3 answers

317 views

Image doesn't show up.

Hi, I'm pulling my hair out because I cannot get any image to actually display in the image editor. I have verified that the handlers are in the web.config and that the link to the image is valid (in Firebug). Still nothing. I'm not sure if it's connected, but opening up an image from RadFileEditor brings up a blank window as well.

<telerik:RadFileExplorer ID="RadFileExplorer1" runat="server"

EnableCreateNewFolder="false"

VisibleControls="Toolbar, ContextMenus, FileList"

Configuration-DeletePaths="~/Images/Advertising"

Configuration-EnableAsyncUpload="true"

Configuration-MaxUploadFileSize="9999999"

Configuration-UploadPaths="~/Images/Advertising"

Configuration-ViewPaths="~/Images/Advertising" ClientIDMode="Static">

</telerik:RadFileExplorer>

Web.Config

<system.webServer>

<validation validateIntegratedModeConfiguration="false" />

<modules runAllManagedModulesForAllRequests="true">

<remove name="UrlRoutingModule" />

<add name="UrlRoutingModule" type="System.Web.Routing.UrlRoutingModule, System.Web, Version=4.0.0.0, Culture=neutral, PublicKeyToken=b03f5f7f11d50a3a" />

</modules>

<handlers>

<add name="Telerik_Web_UI_WebResource_axd" verb="*" preCondition="integratedMode" path="Telerik.Web.UI.WebResource.axd" type="Telerik.Web.UI.WebResource" />

<add name="UrlRoutingHandler" preCondition="integratedMode" verb="*" path="UrlRouting.axd" type=

"System.Web.HttpForbiddenHandler, System.Web,
Version=2.0.0.0, Culture=neutral,
PublicKeyToken=b03f5f7f11d50a3a"

/>

<add name="Telerik_Web_UI_SpellCheckHandler_axd" verb="*" preCondition="integratedMode" path="Telerik.Web.UI.SpellCheckHandler.axd" type="Telerik.Web.UI.SpellCheckHandler" />

<add name="Telerik_Web_UI_DialogHandler_aspx" verb="*" preCondition="integratedMode" path="Telerik.Web.UI.DialogHandler.aspx" type="Telerik.Web.UI.DialogHandler" />

<add name="ChartImage_axd" verb="*" preCondition="integratedMode" path="ChartImage.axd" type="Telerik.Web.UI.ChartHttpHandler" />

</handlers>

</system.webServer>

ImageEditor

answered on 02 Aug 2012

2 answers

96 views

Highlight

Is it possible to highlight the letters the user types?
Like in the combobox filtering example (see screenshot)

AutoCompleteBox

answered on 02 Aug 2012

2 answers

73 views

Controls overlapping in some of the forms after installing Telerik version 2012.2.724.35

Hi,

I had Trial version installed but recently upgraded to a licensed version 2012.2.724.35. Since then in some of the forms controls are overlapping (see screenshot attached). Please let me know what could be the issue ASAP.

Thanks,
ADod

Installer and VS Extensions

answered on 02 Aug 2012

1 answer

149 views

Really very good control.

Hello Telerik Team,

Really very very good control.
I really appreciate your work, Because this control are different from other third party (GRID) control.

once again thanks to all of you.

Note : i also notice that i will take so much time in changing groping.
i also know that it must take much time because first it created structure in pivot data then after it will create UI for that.
But, Can you please try to work on this in next version?

Thanks,
Jayesh Goyani

PivotGrid

answered on 02 Aug 2012
