Questions on UI for ASP.NET AJAX Forum

3 answers

255 views

I need to add GridHeaderItem just like the way it is done in this link with the GridView
http://csharpdotnetfreak.blogspot.com/2008/11/merging-gridview-headers-to-have.html

Here's the part of the code from the link:
protected void grvMergeHeader_RowCreated
(object sender, GridViewRowEventArgs e)
{
if (e.Row.RowType == DataControlRowType.Header)
{
    GridView HeaderGrid = (GridView)sender;
    GridViewRow HeaderGridRow =
    new GridViewRow(0, 0, DataControlRowType.Header,
    DataControlRowState.Insert);
    TableCell HeaderCell = new TableCell();
    HeaderCell.Text = "Department";
    HeaderCell.ColumnSpan = 2;
    HeaderGridRow.Cells.Add(HeaderCell);

    HeaderCell = new TableCell();
    HeaderCell.Text = "Employee";
    HeaderCell.ColumnSpan = 2;
    HeaderGridRow.Cells.Add(HeaderCell);

    grvMergeHeader.Controls[0].Controls.AddAt
    (0, HeaderGridRow);

}
}

I tried on my own up to this point but with no sucess. MyRadGrid is the name of the RadGrid.

protected

void RollUpDataRadGrid_ItemCreated(object sender, GridItemEventArgs e)

{

if (e.Item is GridHeaderItem)

{

RadGrid HeaderGrid = (RadGrid)sender;

GridHeaderItem headerItem = new GridHeaderItem(MyRadGrid.MasterTableView, 0, 0);

TableCell headerCell = new TableCell();

headerCell.Text =

"Department";

headerCell.ColumnSpan = 2;

headerItem.Cells.Add(headerCell);

headerCell =

new TableCell();

headerCell.Text =

"Employee";

headerCell.ColumnSpan = 2;

headerItem.Cells.Add(headerCell);

MyRadGrid.Controls[0].Controls.AddAt(0, headerItem);

}

I will appreciate if anyone has some inputs to it.

Thanks,
Raju

Grid

answered on 01 Oct 2012

6 answers

527 views

force radcombobox to always expand upwards

I have a fixed position div that is always at the bottom of my page. Inside that is a RadComboBox with around 30 items. Sometimes it expands upwards, sometimes it expands downwards and so out of view and unusable.

How can I force the RadComboBox to always expand upwards?

Thanks.

ComboBox

answered on 01 Oct 2012

1 answer

70 views

[Solved] pictures below x axis

Hi,
I need create chart with possibiliti to display pictures below x-axis line in 2 (or more) rows. In sample picture you can see 2 rows 'act' and 'fcst'. The pictures should be displayed for each hour depends on data .
Is it possible in RadChart (or any different Telerik charts?)
Regards.
Leszek

Chart (Obsolete)

answered on 01 Oct 2012

4 answers

474 views

Is their any good site or tutorial to learn telerik control self from basic

I am Fresher and also very new to telerik,so
Is their any good site or tutorial to learn telerik control self from basic
Thank U

General Discussions

answered on 01 Oct 2012

1 answer

106 views

Rad grid not doing CRUD(Means doing nothing)

I am following the post to do Automatic CRUD operation on rad grid using Entity Framework by using:
http://demos.telerik.com/aspnet-ajax/grid/examples/automaticoperations/efdatabinding/defaultvb.aspx

My code for Design Page:

<%@ Page Language="C#" AutoEventWireup="true" CodeBehind="Demo.aspx.cs" Inherits="Telerik.Demo" %>
<%@ Register TagPrefix="telerik" Namespace="Telerik.Web.UI" Assembly="Telerik.Web.UI" %>

<!DOCTYPE html PUBLIC "-//W3C//DTD XHTML 1.1//EN" "http://www.w3.org/TR/xhtml11/DTD/xhtml11.dtd">
<html xmlns="http://www.w3.org/1999/xhtml">
<head id="Head1" runat="server">
    <style type="text/css">
        .MyImageButton
        {
            cursor: hand;
        }
        .EditFormHeader td
        {
            font-size: 14px;
            padding: 4px !important;
            color: #0066cc;
        }
    </style>
</head>
<body class="BODY" style="background-color: Black">
    <form id="form1" runat="server">
    <div>
        <telerik:RadScriptManager ID="RadScriptManager1" runat="server">
        </telerik:RadScriptManager>
        <telerik:RadAjaxManager ID="RadAjaxManager1" runat="server">
            <AjaxSettings>
                <telerik:AjaxSetting AjaxControlID="RadGrid1">
                    <UpdatedControls>
                        <telerik:AjaxUpdatedControl ControlID="RadGrid1" LoadingPanelID="RadAjaxLoadingPanel1" />
                    </UpdatedControls>
                </telerik:AjaxSetting>
            </AjaxSettings>
        </telerik:RadAjaxManager>
        <telerik:RadAjaxLoadingPanel ID="RadAjaxLoadingPanel1" runat="server" />
        <telerik:RadGrid ID="RadGrid1" runat="server" DataSourceID="EntityDataSource1" GridLines="None"
            AllowPaging="True" AllowAutomaticUpdates="True" AllowAutomaticInserts="True"
            AllowAutomaticDeletes="True" AllowSorting="True" Width="750px" OnItemCreated="RadGrid1_ItemCreated"
            CellSpacing="0" Skin="Black">
            <PagerStyle Mode="NextPrevAndNumeric" />
            <ClientSettings>
                <Selecting CellSelectionMode="None"></Selecting>
            </ClientSettings>
            <MasterTableView DataSourceID="EntityDataSource1" AutoGenerateColumns="False" DataKeyNames="ID"
                CommandItemDisplay="Top">
                <CommandItemSettings ExportToPdfText="Export to PDF"></CommandItemSettings>
                <RowIndicatorColumn Visible="True" FilterControlAltText="Filter RowIndicator column">
                </RowIndicatorColumn>
                <ExpandCollapseColumn Visible="True" FilterControlAltText="Filter ExpandColumn column">
                </ExpandCollapseColumn>
                <Columns>
                    <telerik:GridEditCommandColumn ButtonType="ImageButton" UniqueName="EditCommandColumn">
                    </telerik:GridEditCommandColumn>
                    <telerik:GridBoundColumn DataField="ID" HeaderText="ID" SortExpression="ID" UniqueName="ID"
                         MaxLength="5">
                    </telerik:GridBoundColumn>
                    <telerik:GridBoundColumn DataField="Name" HeaderText="Name" SortExpression="Name"
                        UniqueName="Name">
                    </telerik:GridBoundColumn>
                    <telerik:GridBoundColumn DataField="Address" HeaderText="Address" SortExpression="Address"
                        UniqueName="Address">
                    </telerik:GridBoundColumn>
                    <telerik:GridBoundColumn DataField="DeptID" HeaderText="DeptID" SortExpression="DeptID"
                        UniqueName="DeptID">
                    </telerik:GridBoundColumn>
                    <telerik:GridButtonColumn Text="Delete" CommandName="Delete" ButtonType="ImageButton" />
                </Columns>
                <EditFormSettings>
                    <EditColumn ButtonType="ImageButton" />
                </EditFormSettings>
            </MasterTableView>
            <FilterMenu EnableImageSprites="False">
            </FilterMenu>
        </telerik:RadGrid>
        <asp:EntityDataSource ID="EntityDataSource1" runat="server" ConnectionString="name=Entity"
            DefaultContainerName="Entity" EnableDelete="True" EnableFlattening="False" EnableInsert="True"
            EnableUpdate="True" EntitySetName="EMPLOYEEs" EntityTypeFilter="EMPLOYEE">
        </asp:EntityDataSource>
    </div>
    </form>
</body>
</html>

Code Behind Page:

using System;
using System.Collections.Generic;
using System.Linq;
using System.Web;
using System.Web.UI;
using System.Web.UI.WebControls;
using Telerik.Web.UI;

namespace Telerik
{
    public partial class Demo : System.Web.UI.Page
    {
        Entity ent = new Entity();
        EMPLOYEE emp = new EMPLOYEE();
        protected void Page_Load(object sender, EventArgs e)
        {
                RadGrid1.DataSourceID = null;
                BindGrid();
        }

        public void BindGrid()
        {
                var query5 = from employee in ent.EMPLOYEEs
                             select new
                             {
                                 ID = employee.ID,
                                 NAME = employee.NAME,
                                 ADDRESS = employee.ADDRESS,
                                 DEPTID = employee.DEPTID
                             };
                RadGrid1.DataSource = query5;
        }

        protected void RadGrid1_ItemCreated(object sender, Web.UI.GridItemEventArgs e)
        {
            if (e.Item is GridEditableItem && e.Item.IsInEditMode)
            {
                if (!(e.Item is GridEditFormInsertItem))
                {
                    GridEditableItem item = e.Item as GridEditableItem;
                    GridEditManager manager = item.EditManager;
                    GridTextBoxColumnEditor editor = manager.GetColumnEditor("ID") as GridTextBoxColumnEditor;
                    editor.TextBoxControl.Enabled = false;
                }
            }
        }

        protected void gv1_NeedDataSource(object sender, Web.UI.GridNeedDataSourceEventArgs e)
        {
            BindGrid();
        }
    }
}

while execution it does nothing,only grid is displayed without any of the CRUD operation
Plz Help,
Thanks

Grid

answered on 01 Oct 2012

2 answers

109 views

RadGrid Edit Mode Paging

I have a radgrid that when the page loads all items are in edit mode. When I click to go to the next page all of the items on the next page aren't in edit mode. :( I gave to click "edit" for each item. I'd like for the next page to go into edit mode too.

This is what I'm using to get it into edit mode, which works for the first page.

protected void RadGrid1_ItemCreated(object sender, GridItemEventArgs e)

{

if (e.Item is GridDataItem)

{

GridDataItem item = (GridDataItem)e.Item;

LinkButton lnkBtnDelete = (LinkButton)item["AutoGeneratedDeleteColumn"].Controls[0];

lnkBtnDelete.Attributes["onclick"] = "javascript:return confirm(\'Do you want to delete this item?\')";

}

if (!Page.IsPostBack && e.Item is GridEditableItem)

{

e.Item.Edit = true;

}

protected void RadGrid1_PreRender(object sender, EventArgs e)

{

if (!IsPostBack)

{

foreach (GridItem item in RadGrid1.MasterTableView.Items)

{

if (item is GridEditableItem)

{

GridEditableItem editableItem = item as GridDataItem;

editableItem.Edit = true;

}

RadGrid1.Rebind();

}

Grid

answered on 30 Sep 2012

1 answer

148 views

Insert into first position

Hi,

I have a grid with a lot of data. I notice that when I add a new row it load the grid and presents the editable section at the very end of the grid pagination. This increases the amount of time required to add a record. Whenever we are adding a record we are doing so on the first page so it is most desirable to have the insert happen in the 1st position instead of having to reload the grid and go to the end. Hope that make sense and how can I accomplish this.

Thanks

Eric

Grid

answered on 30 Sep 2012

5 answers

221 views

Multiple GridDropDownColumns

Just starting to use telerik controls and I've combed through the forums and documentation for my problem but something hasn't clicked for me. My scenario is that I have a radgrid with multiple griddropdowncolumns, 7 of them to be exact (days of the week). The data is being bound in codebehind of type int for these 7 columns (there are other columns but those are coming back fine). When I'm binding the data to the grid, the griddropdowncolumns do not populate at all. The values should be between 1-5 to represent a status for each day. So, initially, upon load of the radgrid, the columns will appear with respective status' and in edit mode the user shoul be able to select a different status for each day. Sorry for the length, but trying to make my point here...
Here is a snippet of my aspx code:

<telerik:GridDropDownColumn DataField="Mon" HeaderText="Mon" ListTextField=""

ListValueField="Mon" UniqueName="MonTitleColumn" DropDownControlType="RadComboBox" ColumnEditorID="MonTitleEditor1" />

<telerik:GridDropDownColumn DataField="Tue" HeaderText="Tue" ListTextField="StatusName"

ListValueField="Tue" UniqueName="TueTitleColumn" DropDownControlType="RadComboBox" ColumnEditorID="FebTitleEditor1" />

<telerik:GridDropDownColumn DataField="Wed" HeaderText="Wed" ListTextField="StatusName"

ListValueField="Wed" UniqueName="MarTitleColumn" DropDownControlType="DropDownList" ColumnEditorID="MarTitleEditor1" />

<telerik:GridDropDownColumn DataField="Thu" HeaderText="Thu" ListTextField="StatusName"

ListValueField="Thu" UniqueName="ThuTitleColumn" DropDownControlType="DropDownList" ColumnEditorID="AprTitleEditor1" />

<telerik:GridDropDownColumn DataField="Fri" HeaderText="Fri" ListTextField="StatusName"

ListValueField="Fri" UniqueName="MayTitleColumn" DropDownControlType="DropDownList" ColumnEditorID="MayTitleEditor1" />

How do I show the value in the db (1-5) for each of the GridDropDownColumns and in edit mode select the values 1-5...
I'm afraid I've spent all day and yesterday and my brain is fried. And in the process I've thoroughly confused myself.
Any and all help is appreciated!
SS

Grid

answered on 30 Sep 2012

1 answer

108 views

How to close EditForm on condition

Hi!

Here is my problem:
I use ascx editform in telerik radgrid. I have some textboxes, a Cancel and a Save button on it.
I want it to work the following way:
- if the user writes correct values in the textboxes and clicks the save button, the editform must close and the grid must show the new values.
- if the user writes wrong values in the textboxes and clicks the button, the editform must stay visible so the user can change the wrong values.

The situation is a little bit more complicated, because I use the editform in the grid's childgrid/detailtable.
If it is possible, I want to solve the problem in the ascx form's code behind.

Sorry for my bad English,
Thanks for the answers!

Grid

answered on 29 Sep 2012

1 answer

79 views

DataGrid Grouping when binding to class that contains collections of other classes.

Hi,

I have a data structure similar to the one below where one class contains a colleciton of another class as one of it's fields:

Product
{
    String name
    String desription
    Address[] addresses
}

Address
{
    String state
    String suburb
}

Within a data grid which I am binding to the Product class, I want to display only the Product "name" field but have it grouped by the "state" field of the first item of the addresses collection (within my data I am ensuring that every Product has at least one Address)

So my data grid would look somthing like:

VIC
    - Product Name 1
    - Product name 2
NSW
    - Product Name 3
    - Product Name 4

Is this possible? To date I can only get grouping working on fields within the Business (or top level) class, not fields from the Address (or nested) class.

Grid

answered on 29 Sep 2012
