Questions on UI for WinForms Forum

3 answers

194 views

Hi all,
Is there a way to hide non working hours in TimelineView with Timescales.Hours/HalfHours/Minutes

e.g. collapse Columns before and after the WorkTime-Timespan - thus allowing shorter drag+Drop movements

| Day 1 | Day 2 |
| 08 09 10 11 12 13 14 16 18 20| 08 09 10 11 12 13 14 16 18 20|

Currently I call my own RenderView() method which loops over all visible cells

void ActiveView_PropertyChanged(object sender, PropertyChangedEventArgs e)

{

switch (e.PropertyName)

{

case "StartDate":

It would be more convinient to subscribe to a ElementRender Event and set the background color there - like the one exposed in RadCalendar.

Scheduler and Reminder

answered on 20 Dec 2012

0 answers

101 views

radgridview hierarchy problem

Hi
I ask for help, there is a small problem.

There are two tables: the nomenclature and files.

Nomenclature hierarchy built in RadTreeView.
List of files in RadGridView
When you select a list of files filled in gridview
Doing so:

protected override void OnLoad(EventArgs e)
        {
            base.OnLoad(e);

            this.nomenclatureTableAdapter.Fill(this.dataSet.nomenclature);
            this.filesTableAdapter.Fill(this.dataSet.files);

            radGridView1.DataSource = this.index3fkBindingSource;

            this.radGridView1.Relations.AddSelfReference(radGridView1.MasterTemplate, "ID", "FID");
        }
The first time he correctly selects and builds a hierarchy.
But when another node, it populates the file list in their previous range, and even without the hierarchy.
SubFiles is not visible and not the list of files.

GridView

asked on 20 Dec 2012

3 answers

106 views

Set chart datatable cell color dynamically

Is there a way to dynamically set the cell background color of a datatable? Something similar to the image attached.

Chart (obsolete as of Q1 2013)

answered on 20 Dec 2012

2 answers

131 views

After databind: update current view

Hi,

I have a client server solution. Several clients connect to a single database hosting the scheduler data. When a client changes the data in the database table (adding, removing, changing an appointment) the SQL message broker kicks in and all other clients execute a function to update their scheduler. So far this works like a charm:

''' <summary>

''' Sql Server notifies the scheduler table data is changed!

''' The current scheduler data needs to rebind to reflect the changes...

''' </summary>

''' <param name="sender"></param>

''' <param name="e"></param>

''' <remarks></remarks>

Private Sub AgendaWijziging(sender As Object, e As System.Data.SqlClient.SqlNotificationEventArgs)

If Me.InvokeRequired Then

RadScheduler1.BeginInvoke(New MethodInvoker(AddressOf radScheduler1_rebind))

Else

radScheduler1_rebind()

End If

End Sub

''' <summary>

''' Rebind the scheduler after a database change by another client

''' </summary>

''' <remarks></remarks>

Private Sub radScheduler1_rebind()

Try

Me.Cursor = Cursors.WaitCursor

' attempt to find current first time slot in view (user scrolled to this time slot)

'Dim dayView As SchedulerDayViewGroupedByResourceElement = TryCast(Me.RadScheduler1.SchedulerElement.ViewElement, SchedulerDayViewGroupedByResourceElement)

'Dim singleDayView As SchedulerDayViewElement = Nothing

'Dim resetToTime As DateTime? = Nothing

'Dim firstCell As SchedulerCellElement

'If dayView IsNot Nothing Then

' singleDayView = dayView.GetDayViewElements.FirstOrDefault

' If singleDayView IsNot Nothing Then

' firstCell = singleDayView.DataAreaElement.Table.Children.First

' If firstCell IsNot Nothing Then

'            resetToTime = CType(cell, SchedulerCellElement).Date (date only... no time?)

' End If

'End If

RadScheduler1.DataBind()

' go back to the timeslot the user scrolled to.. (does not work :( resetToTime contains date only )

'If singleDayView IsNot Nothing AndAlso resetToTime IsNot Nothing Then

'    singleDayView.DataAreaElement.Table.ScrollToTime(New TimeSpan(resetToTime.Value.Hour, resetToTime.Value.Minute, resetToTime.Value.Second))

'End If

' re-initialize the sql broker notification

_context.MonitorAgenda()

Catch ex As Exception

Dim currentMethode As MethodBase = MethodBase.GetCurrentMethod

FormHelper.LogError(ex, currentMethode.DeclaringType.ToString, currentMethode.ToString)

Finally

Me.Cursor = Cursors.Arrow

End Try

End Sub

The problem is in the commented code: After the databind is executed, the scheduler view is reset to 00:00 hour. I basically attempt to update the binding without updating the display, so when another workstation adds a appointment on a timeslot in view it just appears in the scheduler the user is looking at or (when in a timeslot out of view) would appear when scrolling. As an added bonus the scheduler contains several resources.

So how can I "detect" the start or end of the top _visible_ timeslot and then use "dv.DataAreaElement.Table.ScrollToTime(TimeSpan.FromHours(firstCell.Hour))" to Update the view after databind?
Or should I approach this differently?

regards,
Raoul

Scheduler and Reminder

answered on 19 Dec 2012

3 answers

263 views

GridViewMaskBoxColumn

Hello
I wanted to have a column which has thousand seprator so I used "GridViewDecimalColumn" but when I typed in the cell the thousand separator
has been disappeared and when I left the cell it was shown again. as the result of this i decided to use "GridViewMaskBoxColumn" insted ,because
it hasnt those problem .
by using GridViewMaskBoxColumn my problem solved but I face to another problem,I need to set maximum value to this column
but I cant define MaximumValue for this column ,please help me to do this.

GridViewMaskBoxColumn dec = new GridViewMaskBoxColumn();
            dec.FieldName = "dec";
          dec.FormatString = "{0:#,##}";
            radGridView1.Columns.Add(dec);

GridView

answered on 19 Dec 2012

4 answers

399 views

Gridview, datatable, selected row

Hello!
I am using a gridview like this:

private void LoadGrid()

{

DataTable dataTable = new DataTable();

DataColumn itemIdColumn = new DataColumn("ItemId", typeof(int));

DataColumn itemCodeColumn = new DataColumn("ItemCode", typeof(string));

DataColumn itemNameColumn = new DataColumn("ItemName", typeof(string));

DataColumn sellPriceColumn = new DataColumn("SellPrice", typeof(decimal));

DataColumn vatValueColumn = new DataColumn("VatValue", typeof(decimal));

DataColumn itemTypeColumn = new DataColumn("ItemType", typeof(int));

dataTable.Columns.Add(itemCodeColumn);

dataTable.Columns.Add(itemNameColumn);

dataTable.Columns.Add(sellPriceColumn);

dataTable.Columns.Add(vatValueColumn);

dataTable.Columns.Add(itemTypeColumn);

dataTable.Columns.Add(itemIdColumn);

dataTable.BeginLoadData();

var lst = _relatedItemBc.GetItemsForMainGrid(FilteredItem);

for (int i = 0; i < lst.Count; i++)

{

DataRow row = dataTable.NewRow();

row["ItemCode"] = lst[i].ItemCode;

row["ItemName"] = lst[i].ItemName;

row["SellPrice"] = lst[i].SellPrice;

row["VatValue"] = lst[i].VATValue;

row["ItemType"] = lst[i].ItemType;

row["ItemId"] = lst[i].ItemID;

dataTable.Rows.Add(row);

}

dataTable.EndLoadData();

rbcDataGridViewMain.MasterTemplate.BeginUpdate();

rbcDataGridViewMain.DataSource = dataTable;

rbcDataGridViewMain.MasterTemplate.EndUpdate();

}

How can i get the informations for the current row, the row i have selected?

Thank you!

GridView

answered on 19 Dec 2012

3 answers

126 views

Gridview Combobox Column

Hi There,

I have a combobox column in a gridview, the combobox has a datasource set to a list of objects returned from my database. One of these items in this datasource is an "Other" item. I am looking for a way so that when a user clicks "Other" as the selected item the combobox can be edited and a new value inserted into the datasource.

Can anyone offer any advice on the best way to do this?

Many Thanks For The Suggestions/Help?

GridView

answered on 19 Dec 2012

1 answer

426 views

RadGridView ExportToExcelML

We are having two different issues with exporting using the Export To ExcelML.

First I'll show the code that we're using:

Me.RadGridView1.Columns("Date"

).ExcelExportType = DisplayFormatType.Custom

Me.RadGridView1.Columns("Date").ExcelExportFormatString = " mm/dd/yyyy "

Dim exporter As Export.ExportToExcelML = New Export.ExportToExcelML(Me

.RadGridView1)

exporter.FileExtension =

"xls"



exporter.HiddenColumnOption = HiddenOption.DoNotExport

exporter.ExportVisualSettings =

True



exporter.RunExport(fileName)

The first issue. In the database we have the Date column as a DateTime datatype. I have the Custom ExcelExportType set to only show "mm/dd/yyyy" When it exports it will show up with that format - but the data still has the time included with it. We need it to only export the date, not the time.

The second issue comes from trying to open the exported file. Every time we try to open the .xls file, a warning comes up
"The file that you are trying to open, 'Filename.xls' is in a different format than specified by the file extension"
Everything still worked after that - but it is a little annoying have to go through that each time.

Please let me know of any suggestions.

Thanks.

GridView

answered on 19 Dec 2012

2 answers

102 views

Inactive Color

Hi;

How I Can change backgroudcolor and fore color when enable = false in a RadDropDownList? text contrast with the background is very bad.

regards.

DropDownList

answered on 19 Dec 2012

2 answers

121 views

Calling columns by public column name

Hi,

Creating columns in manual way (using designer) make them only visible in Designer.cs file, because declaration is in InitializeComponent() function.
How to avoid that, so for example ill able to call cell value like that:

GridView.Rows[4].Cells[myColumn.name].Value

GridView

answered on 19 Dec 2012
