Hello,

I created a report to display values and totals.
I have a problem with the Bordereau N ° 212319
it shows me the total of "Nombre de Plis" in just "DD" column (1 233) while it should appears to display (897 in "DD" and 316 in "TF") as the capture that I have attached. Same problem in "Poids Total"

I am sharing my sample with you online via Dropbox. please check this and advise me any way to address this requirement.

https://www.dropbox.com/s/zts6gyiefp5qdce/myReport.trdp?dl=0
Thanks in advance.

Dimitar
Telerik team
 answered on 07 Apr 2021
1 answer
247 views

Hello!

I am evaluating the tool for my company.
I am creating a .NET 5 application that accesses an Oracle database.
Through the designer, I managed to assemble the report and managed to view the information through the Preview.
When I try to run the report and export a PDF I get the following message:
"Unable to establish a connection to the database. Please verify that your connection string is valid. In case you use a named connection string from the application configuration file, make sure the name is correct and the connection string settings are present in the configuration file of your application. "

Is there a document on how to export a report as PDF using .NET 5 and accessing the Oracle database?

Todor
Telerik team
 answered on 06 Apr 2021
7 answers
2.4K+ views

I'm using Telerik Reporting R1 2019 for ASP.NET Core where the Reporting Services and the HTML5 viewer is at the same project.

Can you direct me to the correct documentation regarding how to set the connection string in this project ?
As I cannot seem to make it work. When it moves to "netcoreapp2.2" does it still need "App.config" to store the connection string ?

I keep getting the unable to connect to database.

Neli
Telerik team
 answered on 06 Apr 2021
1 answer
125 views

Dear Telerik Team

Pls give any suggestions for this?

Eric R | Senior Technical Support Engineer
Telerik team
 answered on 02 Apr 2021
1 answer
7.5K+ views
Today I came across the stumbling block of passing multi-value parameters to a Stored Procedure. After some trial and error, I have discovered a way to do this. I'm posting it here as I don't see any solutions for this problem in the forum already and the Telerik documentation here states it is not possible.

The key is to pass the parameter's multiple values as a comma (or other character) delimited string. To do this, configure your parameter (using a parameter named @department as an example) in the "Configure data source parameters" step of the data source configuration wizard to join the selected values together using the syntax:
=Join(",",Parameters.Department.Value)



Now we need a table-valued function in the database to convert the comma delimited list string to a table of values. Here is what I used:

CREATE FUNCTION splitstring ( @stringToSplit VARCHAR(8000) )
    RETURNS
        @returnList TABLE ([Param] [nvarchar] (500))
AS

BEGIN

    DECLARE @name NVARCHAR(255)
    DECLARE @pos INT

    WHILE CHARINDEX(',', @stringToSplit) > 0
    BEGIN
        SELECT @pos  = CHARINDEX(',', @stringToSplit)
        SELECT @name = SUBSTRING(@stringToSplit, 1, @pos-1)

        INSERT INTO @returnList
        SELECT @name

        SELECT @stringToSplit = SUBSTRING(@stringToSplit, @pos+1, LEN(@stringToSplit)-@pos)
    END

    INSERT INTO @returnList
    SELECT @stringToSplit

    RETURN
END



Now you can utilize the passed parameter in your main report data source SQL query by using the following syntax in your WHERE clause:

WHERE
      @department IS NULL OR
      @department='' OR
      @department='All' OR
      salesman.department IN (SELECT [Param] FROM splitstring(@department))



In my example I'm allowing for a supplied NULL, empty string or 'All' value top denote selecting all departments.

Hope this helps some of you out.





Henrique Duarte
Top achievements
Rank 1
Veteran
 answered on 01 Apr 2021
2 answers
293 views

Hello.

when trying to display this SVG in a picturebox the marker-end shows up with some added artifacts.

Also when using polygon as marker, nothing shows up. Just the artifacts.

<svg viewBox="0 0 240 200" id="drawing">
       <defs>
            <marker id="arrowheadSmall" markerWidth="13" markerHeight="13" fill="black" refX="7" refY="6" orient="auto">
               <path d="M2,2 L2,11 L10,6 L2,2" style="fill: #000000;"></path>
           </marker>
           <pattern id="wallFill" width="4" height="10" fill="#E6E6E6" patternTransform="rotate(45 0 0)"
               patternUnits="userSpaceOnUse">
               <line x1="0" y1="0" x2="0" y2="10" style="stroke:#ABABAB; stroke-width:1"></line>
           </pattern>
       </defs>
       <rect x="10" y="90" width="90" height="10" style="stroke:grey;stroke-width:1" fill="url(#wallFill)"></rect>
       <rect x="10" y="180" width="180" height="10" style="stroke:grey;stroke-width:1" fill="url(#wallFill)"></rect>
       <line x1="190" y1="190" x2="190" y2="70" style="stroke:grey;stroke-width:1"></line>
       <line x1="190" y1="70" x2="70" y2="10" style="stroke:grey;stroke-width:1"></line>
       <text fill="black" font-size="12px" dominant-baseline="middle" transform="translate(90,186)"
           text-anchor="middle">Gulv</text>
      <text fill="black" font-size="12px" dominant-baseline="middle" transform="translate(140,40) rotate(27)"
           text-anchor="middle">Skråtak</text>
       <line x1="200" y1="118" x2="200" y2="73" style="stroke:black" marker-end="url(#arrowheadSmall)"></line>
       <line x1="200" y1="130" x2="200" y2="177" style="stroke:black" marker-end="url(#arrowheadSmall)"></line>
       <line x1="100" y1="62" x2="100" y2="87" style="stroke:black" marker-end="url(#arrowheadSmall)"></line>
       <line x1="100" y1="48" x2="100" y2="28" style="stroke:black" marker-end="url(#arrowheadSmall)"></line>
    <text x="40" y="140" fill="black" font-size="12px" dominant-baseline="middle" text-anchor="middle">2380</text>

       <line x1="40" y1="133" x2="40" y2="103" style="stroke:black" marker-end="url(#arrowheadSmall)"></line>
       <line x1="40" y1="145" x2="40" y2="177" style="stroke:black" marker-end="url(#arrowheadSmall)"></line>
       <text x="110" y="140" fill="black" font-size="12px" dominant-baseline="middle" text-anchor="middle">2690</text>
       <line x1="110" y1="133" x2="110" y2="93" style="stroke:black" marker-end="url(#arrowheadSmall)"></line>
       <line x1="110" y1="145" x2="110" y2="177" style="stroke:black" marker-end="url(#arrowheadSmall)"></line>
      <text x="100" y="56" fill="black" font-size="12px" dominant-baseline="middle" text-anchor="middle">1940</text>
       <text x="200" y="125" fill="black" font-size="12px" dominant-baseline="middle" text-anchor="middle">3080</text>
       <line x1="150" x2="220" y1="70" y2="70" stroke="#2A579A" stroke-width="1" stroke-dasharray="4"></line>
       <path fill="none" stroke="#2A579A" stroke-width="1"
           d="M 177.3116909814869 64.08334433563022 A 14 14 0 0 0 176 70"></path>
       <text fill="#2A579A" font-size="12px" dominant-baseline="middle" transform="translate(162, 65)" text-anchor="middle">23 ° </text>









Neli
Telerik team
 answered on 01 Apr 2021
14 answers
2.1K+ views

Hi,

I cannot understand how to programmatically enable dynamic shrinking and/or growing of sections on programmatically generated report objects.

In particular, from documentation it seems like that at least CanShrink property should be provided, but I cannot find it from code. What am I missing?

Alternatively, is there a way to make PageHeaderSection, PageFooterSection and DetailSection dynamically resize their height accordingly to the height of the visible items inside them?

Thanks in advance

Neli
Telerik team
 answered on 01 Apr 2021
3 answers
250 views
After updating from a 2020 version to the latest (at time of writing) 15.0.21.224, my Toolbox no longer populates with Reporting controls in VS 2019's design view. The designer of my reports load fine (.VB based ones), but the toolbox refuses to show any available controls.

I tried a repair install of reporting, as well as manually uninstalling/reinstalling with no luck.

I also tried right clicking the toolbox to choose items, and all Telerik Reporting stuff is already checked... but still not showing.
Neli
Telerik team
 answered on 31 Mar 2021
1 answer
130 views

Hi

I am using Reporting with aspx net.

Does anyone know if I can add a query string parameter in the base path during the render of report ?







Thanks a lot for any answer





Neli
Telerik team
 answered on 31 Mar 2021
1 answer
384 views

Hello,

I have some reports created in crystal report that I had to convert them using telerik reporting designer.
In crystal report, they use the notion of group headers and group subheaders ..
for example I find:

group header section n ° 1

  • group header section 1a
  • group header section 1b
  • group header section 1c

group header section n° 2

etc..

My question is if I can make the same distribution of groups in telerik report designer ? if not what can you suggest to me in order to reproduce this?

Thank you.

Neli
Telerik team
 answered on 31 Mar 2021
