Ankesh Bharti
Top achievements
Rank 1
Ankesh Bharti
asked on 30 Mar 2010, 12:14 PM
Hi,
I have to use grouping in RadGrid. But my requirement to use this feature in some different way. I want to drag and drop the columns on my own created Div in the same page(having RadGrid) instead of using GridGroupPanel. And then on the click of button (which is on the Div) to apply grouping performs the desired result of grouping. Can you please help me in this regard. How can i achive this functionality.
Thanks in Advance ...
I have to use grouping in RadGrid. But my requirement to use this feature in some different way. I want to drag and drop the columns on my own created Div in the same page(having RadGrid) instead of using GridGroupPanel. And then on the click of button (which is on the Div) to apply grouping performs the desired result of grouping. Can you please help me in this regard. How can i achive this functionality.
Thanks in Advance ...
15 Answers, 1 is accepted
0
Hello Ankesh,
Basically, the control does not expose any api for performing these actions. The grouping will be cancelled if you drag the column to an invalid element on the page - different from the group panel. Another option would be to expose a panel which allows the user to construct the group expression, and apply it dynamically, to the grid control. Such a setup is demonstrated in the following example:
http://demos.telerik.com/aspnet-ajax/grid/examples/groupby/expressions/defaultcs.aspx
I hope this information helps.
Best wishes,
Yavor
the Telerik team
Do you want to have your say when we set our development plans? Do you want to know when a feature you care about is added or when a bug fixed? Explore the Telerik Public Issue Tracking system and vote to affect the priority of the items.
Basically, the control does not expose any api for performing these actions. The grouping will be cancelled if you drag the column to an invalid element on the page - different from the group panel. Another option would be to expose a panel which allows the user to construct the group expression, and apply it dynamically, to the grid control. Such a setup is demonstrated in the following example:
http://demos.telerik.com/aspnet-ajax/grid/examples/groupby/expressions/defaultcs.aspx
I hope this information helps.
Best wishes,
Yavor
the Telerik team
Do you want to have your say when we set our development plans? Do you want to know when a feature you care about is added or when a bug fixed? Explore the Telerik Public Issue Tracking system and vote to affect the priority of the items.
0

Rachana
Top achievements
Rank 1
answered on 12 Apr 2012, 11:40 AM
Hello Yavor,
i want to darg and drop the groups in radgrid view..but am not getting how to drag and drop the groups in the grid can u please explain me about this plz..
i want to darg and drop the groups in radgrid view..but am not getting how to drag and drop the groups in the grid can u please explain me about this plz..
0

Rachana
Top achievements
Rank 1
answered on 12 Apr 2012, 11:40 AM
Hello Yavor,
i want to darg and drop the groups in radgrid view..but am not getting how to drag and drop the groups in the grid i have written code for onGroupschanging event still nthg is happening..am not able to drag the group can u please explain me about this plz.
i want to darg and drop the groups in radgrid view..but am not getting how to drag and drop the groups in the grid i have written code for onGroupschanging event still nthg is happening..am not able to drag the group can u please explain me about this plz.
<
telerik:RadGrid
runat
=
"server"
Skin
=
"Vista"
ID
=
"gvSectionList"
AllowPaging
=
"false"
ClientSettings
OnRowDrop
=
"gvSectionList_RowDrop"
Width
=
"100%"
AllowMultiRowSelection
=
"true"
OnNeedDataSource
=
"gvSectionList_NeedDataSource"
OnGroupsChanging
=
"gvSectionlist_GroupsChanging"
AutoGenerateColumns
=
"false"
OnItemDataBound
=
"gvSectionList_ItemDataBound"
>
<
MasterTableView
DataKeyNames
=
"tmpSectionId"
>
<
GroupByExpressions
>
<
telerik:GridGroupByExpression
>
<
SelectFields
>
<
telerik:GridGroupByField
FieldAlias
=
"Term"
FieldName
=
"tmpTerm_Name"
FormatString
=
""
HeaderValueSeparator
=
" Name: "
></
telerik:GridGroupByField
>
</
SelectFields
>
<
GroupByFields
>
<
telerik:GridGroupByField
FieldName
=
"tmpTerm_Name"
FormatString
=
""
HeaderText
=
""
></
telerik:GridGroupByField
>
</
GroupByFields
>
</
telerik:GridGroupByExpression
>
</
GroupByExpressions
>
<
Columns
>
<
telerik:GridBoundColumn
DataField
=
"tmpTermId"
Resizable
=
"false"
Reorderable
=
"false"
>
</
telerik:GridBoundColumn
>
<
telerik:GridBoundColumn
DataField
=
"tmpTerm_Name"
Resizable
=
"false"
Reorderable
=
"false"
>
</
telerik:GridBoundColumn
>
<
telerik:GridBoundColumn
DataField
=
"tmpTerm_EndDate"
Resizable
=
"false"
Reorderable
=
"false"
>
</
telerik:GridBoundColumn
>
<
telerik:GridBoundColumn
DataField
=
"tmpCourseID"
Resizable
=
"false"
Reorderable
=
"false"
>
</
telerik:GridBoundColumn
>
<
telerik:GridBoundColumn
DataField
=
"tmpCourse_Name"
HeaderText
=
"Course Name"
HeaderStyle-Width
=
"25%"
ItemStyle-Width
=
"25%"
Resizable
=
"false"
Reorderable
=
"false"
>
</
telerik:GridBoundColumn
>
<
telerik:GridBoundColumn
DataField
=
"tmpSectionId"
Resizable
=
"false"
Reorderable
=
"false"
>
</
telerik:GridBoundColumn
>
<
telerik:GridBoundColumn
DataField
=
"tmpSection_Name"
HeaderText
=
"Section Name"
HeaderStyle-Width
=
"25%"
ItemStyle-Width
=
"25%"
Resizable
=
"false"
Reorderable
=
"false"
>
</
telerik:GridBoundColumn
>
<
telerik:GridBoundColumn
DataField
=
"tmpTerm_Status"
Resizable
=
"false"
Reorderable
=
"false"
>
</
telerik:GridBoundColumn
>
<
telerik:GridBoundColumn
DataField
=
"tmpRegUserCount"
HeaderText
=
"Registered Students"
HeaderStyle-Width
=
"25%"
ItemStyle-Width
=
"25%"
Resizable
=
"false"
Reorderable
=
"false"
>
</
telerik:GridBoundColumn
>
<
telerik:GridBoundColumn
DataField
=
"tmpGustUserCount"
HeaderText
=
"Guest Students"
HeaderStyle-Width
=
"25%"
ItemStyle-Width
=
"25%"
Resizable
=
"false"
Reorderable
=
"false"
>
</
telerik:GridBoundColumn
>
<
telerik:GridBoundColumn
DataField
=
"tmpStartDate"
Resizable
=
"false"
Reorderable
=
"false"
>
</
telerik:GridBoundColumn
>
</
Columns
>
</
MasterTableView
>
<
ClientSettings
AllowRowsDragDrop
=
"True"
AllowColumnsReorder
=
"true"
AllowDragToGroup
=
"True"
ReorderColumnsOnClient
=
"true"
>
<
Resizing
AllowColumnResize
=
"true"
/>
<
Selecting
AllowRowSelect
=
"True"
EnableDragToSelectRows
=
"false"
/>
<
ClientEvents
OnRowDropping
=
"onRowDropping"
/>
<
Scrolling
AllowScroll
=
"true"
/>
</
ClientSettings
>
<
PagerStyle
Mode
=
"NumericPages"
PageButtonCount
=
"4"
/>
</
telerik:RadGrid
>
0

Richard
Top achievements
Rank 1
answered on 16 Apr 2012, 02:48 PM
see below
0

Richard
Top achievements
Rank 1
answered on 16 Apr 2012, 02:53 PM
Rachana:
The grouping functionality of RadGrid is covered in-depth on this page of the documentation: Basic Grouping. And, the online demo that provides the best insights is the Grid/Outlook-Style Grouping
It looks like you have not enabled the GridGroupPanel in your RadGrid definition. This is done by adding the ShowGroupPanel="true" property as in the following markup from the demo:
Let me know if this helps!
The grouping functionality of RadGrid is covered in-depth on this page of the documentation: Basic Grouping. And, the online demo that provides the best insights is the Grid/Outlook-Style Grouping
It looks like you have not enabled the GridGroupPanel in your RadGrid definition. This is done by adding the ShowGroupPanel="true" property as in the following markup from the demo:
<
telerik:RadGrid
ID
=
"RadGrid1"
DataSourceID
=
"SqlDataSource1"
runat
=
"server"
PageSize
=
"20"
AllowSorting
=
"True"
AllowMultiRowSelection
=
"True"
AllowPaging
=
"True"
ShowGroupPanel
=
"True"
AutoGenerateColumns
=
"False"
GridLines
=
"none"
>
Let me know if this helps!
0

Vamsi Kamal
Top achievements
Rank 1
answered on 22 Aug 2012, 10:59 AM
Hi,
Is it possible to enable grouping drag and drop without providing any default column in RadGrid?
When the RadGrid is loaded first time I don't want any grouping, Based on my need I will drag and drop the columns to use group by facility. Is it possible in RadGrid, if yes could you plz give me a sample code.
Many thanks in advance,
Vamsi
Is it possible to enable grouping drag and drop without providing any default column in RadGrid?
When the RadGrid is loaded first time I don't want any grouping, Based on my need I will drag and drop the columns to use group by facility. Is it possible in RadGrid, if yes could you plz give me a sample code.
Many thanks in advance,
Vamsi
0
Hello Vamsi,
You could achieve the requested behavior by simply removing the GroupExpressions from your RadGrid's declaration:
and enable the GroupPanel drag-n-drop feature:
I hope this will prove helpful.
Regards,
Eyup
the Telerik team
You could achieve the requested behavior by simply removing the GroupExpressions from your RadGrid's declaration:
<
GroupByExpressions
>
...
</
GroupByExpressions
>
<
telerik:RadGrid
...
ShowGroupPanel
=
"true"
>
...
<
ClientSettings
AllowDragToGroup
=
"true"
/>
</
telerik:RadGrid
>
I hope this will prove helpful.
Regards,
Eyup
the Telerik team
If you want to get updates on new releases, tips and tricks and sneak peeks at our product labs directly from the developers working on the RadControls for ASP.NET AJAX, subscribe to their blog feed now.
0

Vamsi Kamal
Top achievements
Rank 1
answered on 24 Aug 2012, 11:22 AM
Thanks for your reply, But I am getting "Expression cannot be null or empty " error after removing those lines and dragging and droping my desired column.
Currently I am facing two problems using RadGrid Grouping after providing one default column for grouping field.
1. The RadGrid is not rendering properly when it is loaded for the first time. (Please find the screenshot.)
2. If I Drag and Drop any column to GroupPanel then it is showing below error.
Error Message : "Expression cannot be null or empty"
I can see both the above issues only when the RadGrid is loaded for the first time.
If I do any action like ungroup the initail grouped column/ Changed the paging/ Refresh/ Sort then it is rendering properly and then onwards it is working fine as expected.
Could you please suggest me a solution for this.?
Many Thanks,
Vamsikamal
0
Hello Vamsi,
I have created a sample RadGrid web site to test the described behavior. On my side everything works as expected and the grid gets rendered and grouped correctly. Please check out the attached application and try to distinguish the crucial differences between our projects.
Regards,
Eyup
the Telerik team
I have created a sample RadGrid web site to test the described behavior. On my side everything works as expected and the grid gets rendered and grouped correctly. Please check out the attached application and try to distinguish the crucial differences between our projects.
Regards,
Eyup
the Telerik team
If you want to get updates on new releases, tips and tricks and sneak peeks at our product labs directly from the developers working on the RadControls for ASP.NET AJAX, subscribe to their blog feed now.
0

Vamsi Kamal
Top achievements
Rank 1
answered on 27 Aug 2012, 01:15 PM
Hello Eyup,
Thanks for your response but I am not able to set up the project. I am getting below error.
The database 'D:\TEST\GROUPING\APP_DATA\NORTHWIND.MDF' cannot be opened
because it is version 655. This server supports version 612 and earlier. A
downgrade path is not supported.
Thanks for your response but I am not able to set up the project. I am getting below error.
The database 'D:\TEST\GROUPING\APP_DATA\NORTHWIND.MDF' cannot be opened
because it is version 655. This server supports version 612 and earlier. A
downgrade path is not supported.
Could not open new database
'D:\TEST\GROUPING\APP_DATA\NORTHWIND.MDF'. CREATE DATABASE is aborted.
An
attempt to attach an auto-named database for file
D:\Test\Grouping\App_Data\Northwind.mdf failed. A database with the same name
exists, or specified file cannot be opened, or it is located on UNC share
0
Hello Vamsi,
Please note that you will need to have SQL Server 2008 installed on your machine to run the sample web site and then add its provided service name in the web config:
In addition, please note that if you are using GridTemplateColumns, you will need to define their GroupByExpression manually as demonstrated in the last section of the following topic:
http://www.telerik.com/help/aspnet-ajax/grid-group-by-declarative-definition.html
Hope this helps.
Regards,
Eyup
the Telerik team
Please note that you will need to have SQL Server 2008 installed on your machine to run the sample web site and then add its provided service name in the web config:
<
connectionStrings
>
<
add
name
=
"ConnectionString"
connectionString
=
"Data Source=.\SQLEXPRESS;AttachDbFilename=|DataDirectory|\Northwind.mdf;Integrated Security=True;User Instance=True"
providerName
=
"System.Data.SqlClient"
/>
</
connectionStrings
>
In addition, please note that if you are using GridTemplateColumns, you will need to define their GroupByExpression manually as demonstrated in the last section of the following topic:
http://www.telerik.com/help/aspnet-ajax/grid-group-by-declarative-definition.html
Hope this helps.
Regards,
Eyup
the Telerik team
If you want to get updates on new releases, tips and tricks and sneak peeks at our product labs directly from the developers working on the RadControls for ASP.NET AJAX, subscribe to their blog feed now.
0

shweta
Top achievements
Rank 1
answered on 03 Mar 2014, 12:48 PM
Hi,
when m trying to group three or four column it is showing "NO records found".
How i'll fix that issue.
plz reply.
thanks.
when m trying to group three or four column it is showing "NO records found".
How i'll fix that issue.
plz reply.
thanks.
0

Princy
Top achievements
Rank 2
answered on 04 Mar 2014, 05:42 AM
Hi Shweta,
Please take a look at the sample code snippet to group data. Provide your code snippet if this doesn't help.
ASPX:
Thanks,
Princy
Please take a look at the sample code snippet to group data. Provide your code snippet if this doesn't help.
ASPX:
<
telerik:RadGrid
ID
=
"RadGrid1"
runat
=
"server"
ShowGroupPanel
=
"true"
AllowPaging
=
"true"
AllowSorting
=
"true"
GroupingEnabled
=
"true"
GroupingSettings-ShowUnGroupButton
=
"true"
>
<
MasterTableView
>
<
GroupByExpressions
>
<
telerik:GridGroupByExpression
>
<
SelectFields
>
<
telerik:GridGroupByField
FieldName
=
"ShipCity"
HeaderText
=
"ShipCity"
/>
</
SelectFields
>
<
GroupByFields
>
<
telerik:GridGroupByField
FieldName
=
"ShipCity"
SortOrder
=
"Descending"
/>
</
GroupByFields
>
</
telerik:GridGroupByExpression
>
</
GroupByExpressions
>
<
Columns
>
<
telerik:GridBoundColumn
UniqueName
=
"OrderID"
DataField
=
"OrderID"
HeaderText
=
"OrderID"
/>
<
telerik:GridBoundColumn
DataField
=
"ShipCity"
HeaderText
=
"ShipCity"
UniqueName
=
"ShipCity"
/>
<
telerik:GridBoundColumn
DataField
=
"ShipCountry"
HeaderText
=
"ShipCountry"
UniqueName
=
"ShipCountry"
/>
<
telerik:GridBoundColumn
DataField
=
"ShipRegion"
HeaderText
=
"ShipRegion"
UniqueName
=
"ShipRegion"
/>
</
Columns
>
</
MasterTableView
>
<
ClientSettings
AllowDragToGroup
=
"true"
>
</
ClientSettings
>
</
telerik:RadGrid
>
Thanks,
Princy
0

shweta
Top achievements
Rank 1
answered on 04 Mar 2014, 08:29 AM
Hi princy,
i have 4 columns in grid but two column has dropdown inside it. now m doing grouping and if i m putting any column after dropdown column for grouping so it is showing NO records found..what i need to do to fix that issue.
below is my code.
<telerik:RadGrid runat="server" ID="radGridContentTitle" AllowPaging="True" PageSize="8"
AllowSorting="True" GridLines="None" Skin="Office2007" ItemStyle-Wrap="true"
AutoGenerateColumns="False" OnItemDataBound="radGridContentTitle_ItemDataBound"
OnNeedDataSource="radGridContentTitle_NeedDataSource" OnPageIndexChanged="radGridContentTitle_PageIndexChanged"
Height="280px" Enabled="true" OnPreRender="radGridContentTitle_PreRender" AllowFilteringByColumn="true" ShowGroupPanel="true">
<AlternatingItemStyle></AlternatingItemStyle>
<ItemStyle Wrap="True"></ItemStyle>
<GroupingSettings CaseSensitive="false" />
<PagerStyle Mode="NextPrevAndNumeric" Position="Bottom" />
<MasterTableView GroupLoadMode="Server" TableLayout="Fixed">
<Columns>
<telerik:GridBoundColumn DataField="ContentTitleId" HeaderText="ID" UniqueName="ID" FilterControlWidth="120px">
</telerik:GridBoundColumn>
<telerik:GridBoundColumn DataField="ContentTitleName" HeaderText="Content Title" FilterControlWidth="120px">
</telerik:GridBoundColumn>
<telerik:GridTemplateColumn DataField="Flag8125Description" HeaderText="8125 Setup" UniqueName="DropdownColumn" ShowSortIcon="true" SortExpression="Flag8125Description"
Groupable="true" GroupByExpression="Group By Flag8125ID" ColumnGroupName="8125 Setup" FilterControlWidth="120px">
<ItemTemplate>
<telerik:RadComboBox ID="dropDownListInGrid" runat="server" EnableItemCaching="True"
EnableTextSelection="False" AppendDataBoundItems="True" DataTextField="Flag8125Description"
DataValueField="Flag8125ID" ShowDropDownOnTextboxClick="False" Skin="Office2007">
<Items>
<telerik:RadComboBoxItem runat="server" Text="Select One" Value="0" />
</Items>
</telerik:RadComboBox>
</ItemTemplate>
</telerik:GridTemplateColumn>
<telerik:GridTemplateColumn DataField="EInduction" HeaderText="eInduction" UniqueName="EInductionFlag" SortExpression="EInduction" Groupable="true"
GroupByExpression="Group By EInduction">
<ItemTemplate>
<telerik:RadComboBox ID="rcbGridEInductionFlag" runat="server" EnableItemCaching="True"
EnableTextSelection="False" AppendDataBoundItems="True" DataTextField="EInductionDescription"
DataValueField="EInduction" ShowDropDownOnTextboxClick="False" Skin="Office2007" Width="40">
<Items>
<telerik:RadComboBoxItem runat="server" Text="No" Value="0" />
</Items>
</telerik:RadComboBox>
</ItemTemplate>
</telerik:GridTemplateColumn>
</Columns>
</MasterTableView>
<ClientSettings AllowColumnsReorder="true" AllowDragToGroup="true" AllowGroupExpandCollapse="true" ReorderColumnsOnClient="true">
<Selecting AllowRowSelect="True" />
<Scrolling UseStaticHeaders="true" AllowScroll="true" SaveScrollPosition="true" FrozenColumnsCount="6"
ScrollHeight="260" />
</ClientSettings>
</telerik:RadGrid>
</td>
</tr>
please check and let me know.asap.
thanks.
i have 4 columns in grid but two column has dropdown inside it. now m doing grouping and if i m putting any column after dropdown column for grouping so it is showing NO records found..what i need to do to fix that issue.
below is my code.
<telerik:RadGrid runat="server" ID="radGridContentTitle" AllowPaging="True" PageSize="8"
AllowSorting="True" GridLines="None" Skin="Office2007" ItemStyle-Wrap="true"
AutoGenerateColumns="False" OnItemDataBound="radGridContentTitle_ItemDataBound"
OnNeedDataSource="radGridContentTitle_NeedDataSource" OnPageIndexChanged="radGridContentTitle_PageIndexChanged"
Height="280px" Enabled="true" OnPreRender="radGridContentTitle_PreRender" AllowFilteringByColumn="true" ShowGroupPanel="true">
<AlternatingItemStyle></AlternatingItemStyle>
<ItemStyle Wrap="True"></ItemStyle>
<GroupingSettings CaseSensitive="false" />
<PagerStyle Mode="NextPrevAndNumeric" Position="Bottom" />
<MasterTableView GroupLoadMode="Server" TableLayout="Fixed">
<Columns>
<telerik:GridBoundColumn DataField="ContentTitleId" HeaderText="ID" UniqueName="ID" FilterControlWidth="120px">
</telerik:GridBoundColumn>
<telerik:GridBoundColumn DataField="ContentTitleName" HeaderText="Content Title" FilterControlWidth="120px">
</telerik:GridBoundColumn>
<telerik:GridTemplateColumn DataField="Flag8125Description" HeaderText="8125 Setup" UniqueName="DropdownColumn" ShowSortIcon="true" SortExpression="Flag8125Description"
Groupable="true" GroupByExpression="Group By Flag8125ID" ColumnGroupName="8125 Setup" FilterControlWidth="120px">
<ItemTemplate>
<telerik:RadComboBox ID="dropDownListInGrid" runat="server" EnableItemCaching="True"
EnableTextSelection="False" AppendDataBoundItems="True" DataTextField="Flag8125Description"
DataValueField="Flag8125ID" ShowDropDownOnTextboxClick="False" Skin="Office2007">
<Items>
<telerik:RadComboBoxItem runat="server" Text="Select One" Value="0" />
</Items>
</telerik:RadComboBox>
</ItemTemplate>
</telerik:GridTemplateColumn>
<telerik:GridTemplateColumn DataField="EInduction" HeaderText="eInduction" UniqueName="EInductionFlag" SortExpression="EInduction" Groupable="true"
GroupByExpression="Group By EInduction">
<ItemTemplate>
<telerik:RadComboBox ID="rcbGridEInductionFlag" runat="server" EnableItemCaching="True"
EnableTextSelection="False" AppendDataBoundItems="True" DataTextField="EInductionDescription"
DataValueField="EInduction" ShowDropDownOnTextboxClick="False" Skin="Office2007" Width="40">
<Items>
<telerik:RadComboBoxItem runat="server" Text="No" Value="0" />
</Items>
</telerik:RadComboBox>
</ItemTemplate>
</telerik:GridTemplateColumn>
</Columns>
</MasterTableView>
<ClientSettings AllowColumnsReorder="true" AllowDragToGroup="true" AllowGroupExpandCollapse="true" ReorderColumnsOnClient="true">
<Selecting AllowRowSelect="True" />
<Scrolling UseStaticHeaders="true" AllowScroll="true" SaveScrollPosition="true" FrozenColumnsCount="6"
ScrollHeight="260" />
</ClientSettings>
</telerik:RadGrid>
</td>
</tr>
please check and let me know.asap.
thanks.
0

Princy
Top achievements
Rank 2
answered on 05 Mar 2014, 04:28 AM
Hi Shweta,
Please try setting the GroupByExpression as follows for your TemplateColumn:
ASPX:
Thanks,
Princy
Please try setting the GroupByExpression as follows for your TemplateColumn:
ASPX:
<
telerik:GridTemplateColumn
DataField
=
"Flag8125Description"
Groupable
=
"true"
GroupByExpression
=
"Flag8125ID Group By Flag8125ID"
>
<
ItemTemplate
>
. . . .
Thanks,
Princy
