Enable Timeline View in Radscheduler

[Angelo]

Hi, how do i enable the timeline view in the radscheduler? I need to also make it appear as a button alongside "Day", "Week", "Month" buttons in the rad scheduler header. Thanks!

[Princy]

Hello Angelo,

By default RadSchedular got its Timeline view enabled and the link to display the Timeline view appears as a button beside the "Day" "Week" "Month" buttons. If you want the scheduler to focus to the Timeline view on loading the page itself, set the value of the SelectedView property to TimelineView.

ASPX:

<telerik:RadScheduler ID="RadScheduler1" runat="server" SelectedView="TimelineView"
    DataEndField="End" DataKeyField="ID" DataRecurrenceField="RecurrenceRule" DataRecurrenceParentKeyField="RecurrenceParentID"
    OnClientTimeSlotClick="OnClientTimeSlotClick" OnClientAppointmentClick="openAdvancedForm"
    DataStartField="Start" DataSubjectField="Subject" OnAppointmentDelete="RadScheduler1_AppointmentDelete"
    OnAppointmentInsert="RadScheduler1_AppointmentInsert" OnAppointmentUpdate="RadScheduler1_AppointmentUpdate"
    OnFormCreated="RadScheduler1_FormCreated" StartEditingInAdvancedForm="true" StartInsertingInAdvancedForm="true">
    <AdvancedForm Modal="True" />
</telerik:RadScheduler>

Thanks,
Princy.

[Sandy]

Hi,

I want to see 4 days in Time line view.Currently it is showing 3 days in Time line view.Please help me.

[Plamen]

Hello Sandy,


You can refer to this on-line demo and change the settings of the time slots duration and number of slots properties of you RadScheduler as you need for your custom scenario.

hope this will be helpful.

Regards,
Plamen
Telerik

[Sandy]

Hi,
Thank you so much for your help
