Do you have any means for a variety of UI color expresion?

12 posts, 1 answers
  1. Yaroslav
    Yaroslav avatar
    153 posts
    Member since:
    Jan 2016

    Posted 31 Aug 2016 Link to this post

    Your color Themes (VisualStudio 2013,Office2013,Windows 8 touch,Windows 8,Expression Dark, ... e.t.c) give not very rich color expression. For example, RadTreeListView is looked as in RadTreeListView.PNG file attached. What about your Green Theme - it is somewhat dark. Do you have any means for a variety of coloring?
  2. Yaroslav
    Yaroslav avatar
    153 posts
    Member since:
    Jan 2016

    Posted 31 Aug 2016 in reply to Yaroslav Link to this post

    RadTreeListView instance in RadTreeListView.PNG file has Office2013 style.
  3. Martin
    Admin
    Martin avatar
    105 posts

    Posted 02 Sep 2016 Link to this post

    Hi Yaroslav,

    In our more recent themes we provide a way of globally changing the palette colors. You can modify and customize the colors of the chosen theme to achieve a different coloring. You may like to try our Color Theme Generator, where you can change the various brushes runtime for each of the themes that support it and customize them to your needs.

    Regards,
    Martin
    Telerik by Progress
    Do you need help with upgrading your AJAX, WPF or WinForms project? Check the Telerik API Analyzer and share your thoughts.
  4. Yaroslav
    Yaroslav avatar
    153 posts
    Member since:
    Jan 2016

    Posted 02 Sep 2016 in reply to Martin Link to this post

    Hello, Martin. I'll try Color Theme Generator. If some questions appeare, I'll ask you in this post. Thank you.
  5. Yaroslav
    Yaroslav avatar
    153 posts
    Member since:
    Jan 2016

    Posted 17 Oct 2016 in reply to Yaroslav Link to this post

    I tryed to use Telerik Color Theme Generator for WPF and I've not found any help information for beginners. How can I connect Color Theme Generator with my application? How to begin to work with Color Theme Generator? Please help.
  6. Answer
    Martin
    Admin
    Martin avatar
    105 posts

    Posted 18 Oct 2016 Link to this post

    Hi Yaroslav,

    There was an issue with the exported code from the ColorThemeGenerator that we recently fixed, so if you have installed an older version (more than 2 weeks ago), I could suggest you uninstall and reinstall it again. The code exported was missing " " around the string values.

    Our newer themes (the ones present in the ColorThemeGenerator) provide a theme palette that allows the change of the Colors for the SolidColorBrushes in our controls. The ColorThemeGenerator is a tool for visualization of the changes you are making to the colors in runtime and providing a ready-to-paste code with the values you have picked for the colors.

    The tool exports code that you can paste in the constructor of the MainWindow. There is an example in the following article about Windows8 and Windows8Touch but the principle is the same for all the newer themes (after Windows8).

    Regards,
    Martin
    Telerik by Progress
    Do you need help with upgrading your AJAX, WPF or WinForms project? Check the Telerik API Analyzer and share your thoughts.
  7. Yaroslav
    Yaroslav avatar
    153 posts
    Member since:
    Jan 2016

    Posted 25 Oct 2016 in reply to Martin Link to this post

    How to uninstall an old version of ColorSchemeGenerator?
  8. Yaroslav
    Yaroslav avatar
    153 posts
    Member since:
    Jan 2016

    Posted 25 Oct 2016 in reply to Yaroslav Link to this post

    Dear, Martin. You write about ColorThemeGenerator the following: "...The tool exports code that you can paste in the constructor of the MainWindow..." I bag your pardon but I'm still not clear - how this is done. I develop multimodule Prism application (WPF MVVM) and I use your 'Office 2016' theme. For example, in one of the modules I have a View and there are some RadComboBox instances in this View. When each one of the RadComboBoxes in the View is dropped-down then I'd like to colorize the background of a selected element in 'Plum' color (#FFDDA0DD).

    1) Please write me how I can do it using ColorThemeGenerator?

    2) Do these changes in pallet affect all other ComboBox instances in my application or not?

  9. Yaroslav
    Yaroslav avatar
    153 posts
    Member since:
    Jan 2016

    Posted 25 Oct 2016 in reply to Yaroslav Link to this post

    Well, I was a little adjust to ColorThemeGenerator. So I set colors in CTG and then copy the colors to MainWindow (Shell) constructor.
  10. Yaroslav
    Yaroslav avatar
    153 posts
    Member since:
    Jan 2016

    Posted 27 Oct 2016 in reply to Yaroslav Link to this post

    Hello, Martin. Now I work with Color Theme Generator. Thank you very much for your help and support.
  11. Patrick
    Patrick avatar
    33 posts
    Member since:
    Aug 2011

    Posted 22 Aug in reply to Martin Link to this post

    Hi sir, I tried the Color Theme Generator (latest  version available on august 2017). Not all theme are present. Is it possible to put all available themes in telerik?



    Thanks,

  12. Martin
    Admin
    Martin avatar
    105 posts

    Posted 25 Aug Link to this post

    Hello,

    The themes that are present in the Color Theme Generator are the ones that support the theme Palette - a mechanism that we provide for global modification of a fixed number of brush and opacity resources for each of the themes. It is implemented in Windows8, Windows8Touch, VisualStudio2013, Office2013, Green, Office2016, Office2016Touch and Material themes. The other themes simply do not support such a mechanism and are not designed with one in mind so trying to implement it might not be possible at all in most of them and would introduce a breaking change.

    You can make modifications for the older themes by extracting the Control templates and modifying them in Blend or VS designer or directly in XAML, which mean per control.

    Regards,
    Martin
