<%@ Page Title="" Language="vb" AutoEventWireup="false" MasterPageFile="MasterPage.Master" CodeBehind="DockingTest.aspx.vb" Inherits="DockingTest" %> <%@ Register Assembly="Telerik.Web.UI" Namespace="Telerik.Web.UI" TagPrefix="telerik" %> <%@ Register tagPrefix="ctl" tagName="GridTest" src="GridTest.ascx" %> <asp:Content ID="Content1" ContentPlaceHolderID="AppContentTitle" runat="server"> </asp:Content> <asp:Content ID="Content2" ContentPlaceHolderID="AppContent" runat="server"> <asp:Label ID="lblMessage" runat="server" EnableViewState="false" Visible="false" /> <form id="Form1" runat="server"> <ctl:GridTest ID="ctlGridTest" runat="server" Visible="true" /> </form> </asp:Content> <%@ Control Language="vb" AutoEventWireup="false" CodeBehind="GridTest.ascx.vb" Inherits="GridTest" %> <%@ Register Assembly="Telerik.Web.UI" Namespace="Telerik.Web.UI" TagPrefix="telerik" %> <asp:ScriptManager ID="ScriptManager1" runat="server"/> <asp:Label ID="lblMessage" runat="server" EnableViewState="false" Visible="false" /> <telerik:RadGrid ID="rgGrid" runat="server" Skin="Default" GridLines="both" BorderStyle="outset" BorderWidth="3" PageSize="15" AllowPaging="True" style="width:100%;" AutoGenerateColumns="false" AllowSorting="true" ShowStatusBar="true" AllowAutomaticDeletes="false" AllowAutomaticInserts="false" ItemStyle-BackColor="AliceBlue" AlternatingItemStyle-BackColor="Lightyellow" AllowAutomaticUpdates="false"> <PagerStyle Mode="Advanced" /> <MasterTableView Width="100%" DataKeyNames="ZONE_ID" TableLayout="Auto" CommandItemDisplay="TopAndBottom" EditMode="popUp" ExpandCollapseColumn-ButtonType="pushButton" Name="Template" ShowHeadersWhenNoRecords="true"> <Columns> <telerik:GridEditCommandColumn UniqueName="Edit"> </telerik:GridEditCommandColumn> <telerik:GridBoundColumn DataField="ZONE_ID" HeaderText="Zone ID" UniqueName="ZONE_ID"> </telerik:GridBoundColumn> <telerik:GridBoundColumn DataField="ZONE_TYPE" HeaderText="Zone Type" UniqueName="ZONE_TYPE"> </telerik:GridBoundColumn> <telerik:GridBoundColumn DataField="ZONE_CONTENT" HeaderText="Zone Content" UniqueName="ZONE_CONTENT"> </telerik:GridBoundColumn> <telerik:GridButtonColumn ConfirmText="W A R N I N G !!! You are about to delete this zone. Do you still want to continue?" ConfirmDialogType="RadWindow" ConfirmTitle="Delete" ButtonType="LinkButton" CommandName="Delete" Text="Delete" UniqueName="DeleteColumn"> </telerik:GridButtonColumn> </Columns> <EditFormSettings UserControlName="DocksDynamic.ascx" EditFormType="WebUserControl" PopUpSettings-Modal="true" > </EditFormSettings> </MasterTableView> </telerik:RadGrid>
<%@ Control Language="vb" AutoEventWireup="false" CodeBehind="DocksDynamic.ascx.vb" Inherits="DocksDynamic" %> <%@ Register TagPrefix="telerik" Namespace="Telerik.Web.UI" Assembly="Telerik.Web.UI" %> <asp:Button runat="server" CssClass="button" ID="ButtonAddDock" Text="Add Dock" OnClick="ButtonAddDock_Click" /> <asp:Button runat="server" ID="ButtonPostback" CssClass="button" Text="Make Postback" /> <br /> <br /> <asp:UpdatePanel runat="server" ID="UpdatePanel1"> <ContentTemplate> <telerik:RadDockLayout runat="server" ID="RadDockLayout1" OnSaveDockLayout="RadDockLayout1_SaveDockLayout" OnLoadDockLayout="RadDockLayout1_LoadDockLayout"> <telerik:RadDockZone runat="server" ID="RadDockZone1" Width="300" MinHeight="200" Style="float: left; margin-right: 20px;"> </telerik:RadDockZone> <telerik:RadDockZone Width="300" MinHeight="200" runat="server" ID="RadDockZone2" Style="float: left;"> </telerik:RadDockZone> </telerik:RadDockLayout> </ContentTemplate> <Triggers> <asp:AsyncPostBackTrigger ControlID="ButtonAddDock" EventName="Click" /> </Triggers> </asp:UpdatePanel>
Below is code-behind for DocksDynamic.ascx.vb:
Imports Telerik.Web.UI Partial Public Class DocksDynamic Inherits System.Web.UI.UserControl Private Property CurrentDockStates() As List(Of DockState) Get 'Store the info about the added docks in the session. For real life ' applications we recommend using database or other storage medium ' for persisting this information. Dim _currentDockStates As List(Of DockState) = DirectCast(Session("CurrentDockStatesDynamicDocks"), List(Of DockState)) If [Object].Equals(_currentDockStates, Nothing) Then _currentDockStates = New List(Of DockState)() Session("CurrentDockStatesDynamicDocks") = _currentDockStates End If Return _currentDockStates End Get Set(value As List(Of DockState)) Session("CurrentDockStatesDynamicDocks") = value End Set End Property Private Function CreateRadDockFromState(state As DockState) As RadDock Dim dock As New RadDock() dock.DockMode = DockMode.Docked dock.ID = String.Format("RadDock{0}", state.UniqueName) dock.ApplyState(state) dock.Commands.Add(New DockCloseCommand()) dock.Commands.Add(New DockExpandCollapseCommand()) Return dock End Function Private Function CreateRadDock() As RadDock Dim docksCount As Integer = CurrentDockStates.Count Dim dock As New RadDock() dock.DockMode = DockMode.Docked dock.UniqueName = Guid.NewGuid().ToString().Replace("-", "a") dock.ID = String.Format("RadDock{0}", dock.UniqueName) dock.Title = "Dock" dock.Text = String.Format("Added at {0}", DateTime.Now) dock.Width = Unit.Pixel(300) dock.Commands.Add(New DockCloseCommand()) dock.Commands.Add(New DockExpandCollapseCommand()) Return dock End Function Private Sub CreateSaveStateTrigger(dock As RadDock) 'Ensure that the RadDock control will initiate postback ' when its position changes on the client or any of the commands is clicked. 'Using the trigger we will "ajaxify" that postback. dock.AutoPostBack = True dock.CommandsAutoPostBack = True AddHandler dock.DockPositionChanged, AddressOf Me.DockPositionChanged 'Dim saveStateTrigger As New AsyncPostBackTrigger() 'saveStateTrigger.ControlID = dock.ID 'saveStateTrigger.EventName = "DockPositionChanged" 'UpdatePanel1.Triggers.Add(saveStateTrigger) 'saveStateTrigger = New AsyncPostBackTrigger() 'saveStateTrigger.ControlID = dock.ID 'saveStateTrigger.EventName = "Command" 'UpdatePanel1.Triggers.Add(saveStateTrigger) End Sub Protected Sub DockPositionChanged(ByVal sender As Object, ByVal e As DockPositionChangedEventArgs) Dim str As String = "" 'Put a break here End Sub Private Sub Page_Init(sender As Object, e As System.EventArgs) Handles Me.Init 'Recreate the docks in order to ensure their proper operation Dim i As Integer = 0 While i < CurrentDockStates.Count Dim dock As RadDock = CreateRadDockFromState(CurrentDockStates(i)) 'We will just add the RadDock control to the RadDockLayout. ' You could use any other control for that purpose, just ensure ' that it is inside the RadDockLayout control. ' The RadDockLayout control will automatically move the RadDock ' controls to their corresponding zone in the LoadDockLayout ' event (see below). RadDockLayout1.Controls.Add(dock) 'We want to save the dock state every time a dock is moved. CreateSaveStateTrigger(dock) System.Math.Max(System.Threading.Interlocked.Increment(i), i - 1) End While End Sub Protected Sub RadDockLayout1_LoadDockLayout(sender As Object, e As DockLayoutEventArgs) Handles RadDockLayout1.LoadDockLayout 'Populate the event args with the state information. The RadDockLayout control ' will automatically move the docks according that information. For Each state As DockState In CurrentDockStates e.Positions(state.UniqueName) = state.DockZoneID e.Indices(state.UniqueName) = state.Index Next End Sub Protected Sub RadDockLayout1_SaveDockLayout(sender As Object, e As DockLayoutEventArgs) Handles RadDockLayout1.SaveDockLayout 'Save the dock state in the page Session. This will enable us ' to recreate the dock in the next Page_Init. CurrentDockStates = RadDockLayout1.GetRegisteredDocksState() End Sub Protected Sub ButtonAddDock_Click(sender As Object, e As System.EventArgs) Dim dock As RadDock = CreateRadDock() RadDockZone1.Controls.Add(dock) CreateSaveStateTrigger(dock) End Sub End Class The issue that I'm facing is this.
With the setup above (SETUP 1): DocksDynamics.ascx is used as an EditForm user control for the GridTest.ascx user control's RadGrid that is used by the DockingTest.aspx page ...
For some reason, the RadDockLayout1_LoadDockLayout event is never fired when I click Edit in any of the records in the RadGrid or whenever I add a dock or move a dock from one zone to another.
Furthermore, when I click the Add Dock button, it is able to add one dock, but when I click it a second time, I get the following error message:
Microsoft JScript runtime error: Sys.WebForms.PageRequestManagerServerErrorException: Cannot unregister UpdatePanel with ID 'UpdatePanel1' since it was not registered with the ScriptManager. This might occur if the UpdatePanel was removed from the control tree and later added again, which is not supported.
Parameter name: updatePanel
BUT, if I change my setup to be like this (SETUP 2): DocksDynamics.ascx (with a Script Manager added to it) is used directly in DockingTest.aspx page and not from within a RadGrid in a separate user control, the RadDockLayout1_LoadDockLayout event gets fired.
<%@ Page Title="" Language="vb" AutoEventWireup="false" MasterPageFile="MasterPage.Master" CodeBehind="DocksTest.aspx.vb" Inherits="DocksTest" %> <%@ Register Assembly="Telerik.Web.UI" Namespace="Telerik.Web.UI" TagPrefix="telerik" %> <%@ Register tagPrefix="ctl" tagName="DocksDynamic" src="DocksDynamic.ascx" %> <asp:Content ID="Content1" ContentPlaceHolderID="AppContentTitle" runat="server"> </asp:Content> <asp:Content ID="Content2" ContentPlaceHolderID="AppContent" runat="server"> <asp:Label ID="lblMessage" runat="server" EnableViewState="false" Visible="false" /> <form id="Form1" runat="server"> <ctl:DocksDynamic ID="ctlDocksDynamic" runat="server" Visible="true" /> </form> </asp:Content> <telerik:RadToolTip runat="server" ID="RadToolTipInsert" Position="TopLeft" ShowEvent="FromCode" Width="400px" RelativeTo="Element" OnClientBeforeShow="CheckIfShowInsert" Skin="Sitefinity" ManualClose="True" Animation="Fade" EnableShadow="True" Title="<span class='MsgTextoToolTip'><b> No es posible guardar debido a lo siguiente:</b></span> " RenderInPageRoot="True"> <asp:ValidationSummary ID="valSumaryInsert" runat="server" ValidationGroup="insert_group" /> </telerik:RadToolTip> <telerik:RadToolTip ID="RadToolTipUpdate" runat="server" Animation="Fade" EnableShadow="True" ManualClose="True" OnClientBeforeShow="CheckIfShowUpdate" Position="TopLeft" RelativeTo="Element" ShowEvent="FromCode" Width="400px" Title="<span class='MsgTextoToolTip'><b> No es posible guardar debido a lo siguiente:</b></span> " RenderInPageRoot="True" IsClientID="True" TargetControlID="ToolTipsPositionEditMode" > <asp:ValidationSummary ID="valSummaryUpdate" runat="server" ValidationGroup="update_group" /> </telerik:RadToolTip><EditItemTemplate> <asp:ImageButton ID="btnUpdate" runat="server" BorderStyle="None" BorderWidth="0px" commandname="Update" ImageUrl="~/Imagenes/PedidoExpress/diskyellow16.png" ValidationGroup="update_group" onclientclick="ShowTooltipUpdate();" ToolTip="Guardar los cambios realizados" /> <InsertItemTemplate> <asp:ImageButton ID="btnInsert" runat="server" BorderStyle="None" BorderWidth="0px" commandname="PerformInsert" ImageUrl="~/Imagenes/PedidoExpress/diskgreen16.png" ValidationGroup="insert_group" onclientclick="ShowTooltipInsert()" ToolTip="Agregar beneficiario al pedido" />function CheckIfShowInsert(sender, args) { var summaryElem = document.getElementById("<%= valSumaryInsert.ClientID %>"); if (summaryElem.style.display == "none") { args.set_cancel(true); } } function ShowTooltipInsert() { window.setTimeout(function () { var tooltip = $find("<%= RadToolTipInsert.ClientID %>") tooltip.show(); }, 10); } function CheckIfShowUpdate(sender, args) { var summaryElem = document.getElementById("<%= valSummaryUpdate.ClientID %>"); if (summaryElem.style.display == "none") { //API: if there are no errors, do not show the tooltip args.set_cancel(true); } } function ShowTooltipUpdate() { var tooltip = $find("<%= RadToolTipUpdate.ClientID %>")
setTimeout( function () { tooltip.show(); }, 20); }<telerik:RadButton ID="ID1" runat="server" ToggleType="Radio" GroupName="MyGroup" ButtonType="ToggleButton" AutoPostBack="false" Text="Choice 1" Checked='<%# Bind("datasourcefield")=="Choice 1" %>'> </telerik:RadButton><br /> <telerik:RadButton ID="ID2" runat="server" ToggleType="Radio" GroupName="MyGroup" ButtonType="ToggleButton" AutoPostBack="false" Text="Choice 2" Checked='<%# Bind("datasourcefield")=="Choice 2" %>'> </telerik:RadButton><br />
If this code would not work, what would?
I am currently using Telerik Version v.2009.02.0826.35, and encountering an issue where the RadEditor sporadically will display much wider than defined, forcing horizontal scrolling. Looking at other threads here about this problem, the solution seems to be registering external skins.
However, I am not using a skin for either the RadEditor control, nor the DetailsView that is is part of.
The one thing I did notice though, is that the toolbar, which is loaded from an XML file, doesn't display properly either when the RadEditor misbehaves. I've included two screenshoots - one bad, one good.
Here is a snapshot of the portion of the aspx page where the RadEditor exists:
<div id="divDetailsView" runat="server">
<asp:DetailsView ID="detDetailsView" runat="server" Height="208px" Width="930px"
OnItemCommand="divDetailsView_ItemCommand" AutoGenerateRows="False" DataKeyNames="ref_id"
DataSourceID="SqlDataSourceDetails" HorizontalAlign="Center" DefaultMode="Edit"
EnableModelValidation="True" BorderStyle="None" GridLines="None" >
<Fields>
<asp:TemplateField HeaderText="Name: " SortExpression="ref_name">
<EditItemTemplate>
<asp:TextBox ID="ref_name" runat="server" Text='<%# Bind("ref_name") %>'></asp:TextBox>
<asp:RequiredFieldValidator ID="rfvReferenceName" runat="server" Text="* Reference Name is required"
ControlToValidate="ref_name" Font-Bold="True" BorderStyle="None"></asp:RequiredFieldValidator>
</EditItemTemplate>
<InsertItemTemplate>
<asp:TextBox ID="ref_name" runat="server" Text='<%# Bind("ref_name") %>'></asp:TextBox>
<asp:RequiredFieldValidator ID="rfvReferenceName" runat="server" Text="* Reference Name is required"
ControlToValidate="ref_name" Font-Bold="True" BorderStyle="None"></asp:RequiredFieldValidator>
</InsertItemTemplate>
<ItemTemplate>
<asp:Label ID="lblReferenceName" runat="server" Text='<%# Bind("ref_name") %>'></asp:Label>
</ItemTemplate>
<ControlStyle BorderStyle="Inset" BorderWidth="1px" Width="250px" />
<HeaderStyle Font-Bold="True" HorizontalAlign="Right" BorderWidth="5px" BorderColor="White"
VerticalAlign="Top" />
<ItemStyle HorizontalAlign="Left" />
</asp:TemplateField>
<asp:TemplateField HeaderText="Section: " SortExpression="sec_id">
<EditItemTemplate>
<asp:DropDownList ID="lstSection" runat="server" DataSourceID="SqlDataSourceSections"
DataTextField="sec_name" DataValueField="sec_id" SelectedValue='<%# Bind("sec_id") %>'
Width="175px">
</asp:DropDownList>
</EditItemTemplate>
<InsertItemTemplate>
<asp:DropDownList ID="lstSection" runat="server" DataSourceID="SqlDataSourceSections"
DataTextField="sec_name" DataValueField="sec_id" SelectedValue='<%# Bind("sec_id") %>'
Width="175px">
</asp:DropDownList>
</InsertItemTemplate>
<ItemTemplate>
<asp:Label ID="lblSection" runat="server" Text='<%# Bind("sec_name") %>'></asp:Label>
</ItemTemplate>
<ControlStyle BorderStyle="Inset" BorderWidth="1px" Width="250px" />
<HeaderStyle Font-Bold="True" HorizontalAlign="Right" BorderWidth="5px" BorderColor="White"
VerticalAlign="Top" />
</asp:TemplateField>
<asp:TemplateField HeaderText="Description: " SortExpression="ref_descript">
<ItemTemplate>
<telerik:RadEditor ID="RadEditor1" runat="server" Content='<%# Bind("ref_descript") %>'
Width="500px" ToolbarMode="Default" ToolsFile="~/Admin/RefToolbar.xml" BackColor="White">
<CssFiles>
<telerik:EditorCssFile Value="~/EditorContentArea.css" />
</CssFiles>
<MediaManager UploadPaths="~/Images" ViewPaths="~/Images" MaxUploadFileSize="2147483647" />
<DocumentManager UploadPaths="~/Documents" ViewPaths="~/Documents" MaxUploadFileSize="2147483647" />
<ImageManager UploadPaths="~/Images" ViewPaths="~/Images" MaxUploadFileSize="2147483647" />
<FlashManager UploadPaths="~/Flash" ViewPaths="~/Flash" MaxUploadFileSize="2147483647" />
</telerik:RadEditor>
</ItemTemplate>
<ControlStyle BorderStyle="Inset" BorderWidth="1px" Width="500px" />
<HeaderStyle Font-Bold="True" HorizontalAlign="Right" BorderWidth="5px" BorderColor="White"
VerticalAlign="Top" />
<ItemStyle HorizontalAlign="Left" />
</asp:TemplateField>
Any idea how/what I can do to resolve this ??
Thanks !
Bruce
