Questions on UI for ASP.NET AJAX Forum

1 answer

115 views

Skins not showing in RadGrid Tasks window dropdown

I've just installed the controls and I'm not able to select a skin other than the default skin for RadGrid. I have added the dlls to my bin folder design, UI, UISkins, and XML. Is there another setup I have to do?

Grid

answered on 20 Dec 2011

3 answers

108 views

Dynamically adding docks & persist the statee

Hi,

I have a situation where I need to add usercontrols dynamically & in those usercontrols add RadDocks dynamically which itself contains usercontrol.

Following is the code I am using to add RadDocks in parent usercontrol

in .ascx

<telerik:RadDockLayout runat="server" ID="QuestionsDockLayout">

<telerik:RadDockZone ID="RadDockZone1" runat="server"/>

</telerik:RadDockLayout>

in .ascx.cs

private bool _shouldSavesState = false;

protected void Page_Init(object sender, EventArgs e)

{

QuestionsDockLayout.SaveDockLayout += QuestionsDockLayout_SaveDockLayout;

LoadQuestions();

}

private void LoadQuestions()

{

foreach (var zone in QuestionsDockLayout.RegisteredZones)

{

zone.Docks.Clear();

zone.Controls.Clear();

}

if (!string.IsNullOrEmpty(XmlNode_Page))

{

XmlDocument xmldoc_page = new XmlDocument();

xmldoc_page.Load(new StringReader(XmlNode_Page));

XmlNodeList nodePages = xmldoc_page.SelectNodes("//Question");

if (nodePages != null && nodePages.Count > 0)

{

for (int i = 0; i < nodePages.Count; i++)

{

RadDock radDock = new RadDock();

radDock.ID = "dockPanel_" + this.ID + "_Q" + i;

radDock.AutoPostBack = true;

radDock.Resizable = false;

radDock.DockMode = DockMode.Docked;

radDock.DockHandle = DockHandle.None;

radDock.OnClientInitialize = "SetHandleDock";

QuestionsDockLayout.RegisteredZones[0].Controls.Add(radDock);

XmlNode XnodeQuestion = nodePages[i];

UC_SurveyQuestion SQ = (UC_SurveyQuestion)LoadControl("~/UserControls/UC_SurveyQuestion.ascx");

SQ.ID = XnodeQuestion.Attributes["id"].Value;

SQ.XmlNode_Question = XnodeQuestion.OuterXml;

SQ.Page_ID = this.ID;

HtmlImage img = SQ.FindControl("Handle") as HtmlImage;

img.ClientIDMode = System.Web.UI.ClientIDMode.Static;

img.ID = "Handle_" + radDock.ClientID;

radDock.ContentTemplate = new CompiledTemplateBuilder(parent =>

parent.Controls.Add(SQ)

);

radDock.DockPositionChanged += dock_DockPositionChanged;

}

private void dock_DockPositionChanged(object sender, DockPositionChangedEventArgs e)

{

//if dock position was changed set a flag for saving dock state

_shouldSavesState = true;

}

private void QuestionsDockLayout_SaveDockLayout(object sender, DockLayoutEventArgs e)

{

//Save dock panels state in user's profile

if (_shouldSavesState)

{

List<DockState> lst = QuestionsDockLayout.GetRegisteredDocksState();

}

Now the problem is when I change the positions of RadDock Panels changes to state doesn't persist.
In SaveDockLayout event GetRegisteredDockState method returns the same state of docks as when they are added.

I am not using LoadDockLayout event as indices of RadDocks are same as they are added.

I must be making some silly mistake.

Please help me asap.

Regards,
Suraj Patil

Dock

answered on 20 Dec 2011

2 answers

221 views

How to display real percentage of the upload process in the progress bar?

Hi there,

My upload process take a little while longer (around 30-40 secs in total) as it calls another application to execute extra actions in the same upload function. I want the progress bar to show the real percentage of this process. Can anyone please give me some advice on how I can do this? I have read this demo, but the progress seems like a fake percentage of the upload process. Any help would be greatly appreciated.

Best regards,
Meng

Upload (Obsolete)

answered on 20 Dec 2011

1 answer

67 views

Gridlines in Export

Is it possible to force "View Gridlines" in Excel to be checked, through code?

Thanks!

Grid

answered on 20 Dec 2011

2 answers

108 views

LoadDockLayout Not Firing In User Control Called From RadGrid

Hi Telerik,

I have the following page (DockingTest.aspx):

<%@ Page Title="" Language="vb" AutoEventWireup="false" MasterPageFile="MasterPage.Master" CodeBehind="DockingTest.aspx.vb" Inherits="DockingTest" %>

<%@ Register Assembly="Telerik.Web.UI" Namespace="Telerik.Web.UI" TagPrefix="telerik" %>

<%@ Register tagPrefix="ctl" tagName="GridTest" src="GridTest.ascx" %>

<asp:Content ID="Content1" ContentPlaceHolderID="AppContentTitle" runat="server">

</asp:Content>

<asp:Content ID="Content2" ContentPlaceHolderID="AppContent" runat="server">

<asp:Label ID="lblMessage" runat="server" EnableViewState="false" Visible="false" />

<form id="Form1" runat="server">

<ctl:GridTest ID="ctlGridTest" runat="server" Visible="true" />

</form>

</asp:Content>

It uses a user control (GridTest.ascx):

<%@ Control Language="vb" AutoEventWireup="false" CodeBehind="GridTest.ascx.vb" Inherits="GridTest" %>

<%@ Register Assembly="Telerik.Web.UI" Namespace="Telerik.Web.UI" TagPrefix="telerik" %>

<asp:ScriptManager ID="ScriptManager1" runat="server"/>

<asp:Label ID="lblMessage" runat="server" EnableViewState="false" Visible="false" />

<telerik:RadGrid ID="rgGrid"

runat="server"

Skin="Default"

GridLines="both"

BorderStyle="outset"

BorderWidth="3"

PageSize="15"

AllowPaging="True"

style="width:100%;"

AutoGenerateColumns="false"

AllowSorting="true"

ShowStatusBar="true"

AllowAutomaticDeletes="false"

AllowAutomaticInserts="false"

ItemStyle-BackColor="AliceBlue"

AlternatingItemStyle-BackColor="Lightyellow"

AllowAutomaticUpdates="false">

<PagerStyle Mode="Advanced" />

<MasterTableView Width="100%" DataKeyNames="ZONE_ID" TableLayout="Auto"

CommandItemDisplay="TopAndBottom" EditMode="popUp" ExpandCollapseColumn-ButtonType="pushButton" Name="Template" ShowHeadersWhenNoRecords="true">

<Columns>

<telerik:GridEditCommandColumn UniqueName="Edit">

</telerik:GridEditCommandColumn>

<telerik:GridBoundColumn DataField="ZONE_ID" HeaderText="Zone ID" UniqueName="ZONE_ID">

</telerik:GridBoundColumn>

<telerik:GridBoundColumn DataField="ZONE_TYPE" HeaderText="Zone Type" UniqueName="ZONE_TYPE">

</telerik:GridBoundColumn>

<telerik:GridBoundColumn DataField="ZONE_CONTENT" HeaderText="Zone Content" UniqueName="ZONE_CONTENT">

</telerik:GridBoundColumn>

<telerik:GridButtonColumn ConfirmText="W A R N I N G !!! You are about to delete this zone. Do you still want to continue?" ConfirmDialogType="RadWindow" ConfirmTitle="Delete"

ButtonType="LinkButton" CommandName="Delete" Text="Delete" UniqueName="DeleteColumn">

</telerik:GridButtonColumn>

</Columns>

<EditFormSettings UserControlName="DocksDynamic.ascx" EditFormType="WebUserControl" PopUpSettings-Modal="true" >

</EditFormSettings>

</MasterTableView>

</telerik:RadGrid>

The grid uses an edit form user control (DocksDynamic.ascx):

<%@ Control Language="vb" AutoEventWireup="false" CodeBehind="DocksDynamic.ascx.vb" Inherits="DocksDynamic" %>

<%@ Register TagPrefix="telerik" Namespace="Telerik.Web.UI" Assembly="Telerik.Web.UI" %>

<asp:Button runat="server" CssClass="button" ID="ButtonAddDock" Text="Add Dock" OnClick="ButtonAddDock_Click" />

<asp:Button runat="server" ID="ButtonPostback" CssClass="button" Text="Make Postback" />

<br />

<asp:UpdatePanel runat="server" ID="UpdatePanel1">

<ContentTemplate>

<telerik:RadDockLayout runat="server" ID="RadDockLayout1" OnSaveDockLayout="RadDockLayout1_SaveDockLayout" OnLoadDockLayout="RadDockLayout1_LoadDockLayout">

<telerik:RadDockZone runat="server" ID="RadDockZone1" Width="300" MinHeight="200"

Style="float: left; margin-right: 20px;">

</telerik:RadDockZone>

<telerik:RadDockZone Width="300" MinHeight="200" runat="server" ID="RadDockZone2"

Style="float: left;">

</telerik:RadDockZone>

</telerik:RadDockLayout>

</ContentTemplate>

<Triggers>

<asp:AsyncPostBackTrigger ControlID="ButtonAddDock" EventName="Click" />

</Triggers>

</asp:UpdatePanel>

Below is code-behind for DocksDynamic.ascx.vb:

Imports Telerik.Web.UI

Partial Public Class DocksDynamic

Inherits System.Web.UI.UserControl

Private Property CurrentDockStates() As List(Of DockState)

Get

'Store the info about the added docks in the session. For real life

' applications we recommend using database or other storage medium

' for persisting this information.

Dim _currentDockStates As List(Of DockState) = DirectCast(Session("CurrentDockStatesDynamicDocks"), List(Of DockState))

If [Object].Equals(_currentDockStates, Nothing) Then

_currentDockStates = New List(Of DockState)()

Session("CurrentDockStatesDynamicDocks") = _currentDockStates

End If

Return _currentDockStates

End Get

Set(value As List(Of DockState))

Session("CurrentDockStatesDynamicDocks") = value

End Set

End Property

Private Function CreateRadDockFromState(state As DockState) As RadDock

Dim dock As New RadDock()

dock.DockMode = DockMode.Docked

dock.ID = String.Format("RadDock{0}", state.UniqueName)

dock.ApplyState(state)

dock.Commands.Add(New DockCloseCommand())

dock.Commands.Add(New DockExpandCollapseCommand())

Return dock

End Function

Private Function CreateRadDock() As RadDock

Dim docksCount As Integer = CurrentDockStates.Count

Dim dock As New RadDock()

dock.DockMode = DockMode.Docked

dock.UniqueName = Guid.NewGuid().ToString().Replace("-", "a")

dock.ID = String.Format("RadDock{0}", dock.UniqueName)

dock.Title = "Dock"

dock.Text = String.Format("Added at {0}", DateTime.Now)

dock.Width = Unit.Pixel(300)

dock.Commands.Add(New DockCloseCommand())

dock.Commands.Add(New DockExpandCollapseCommand())

Return dock

End Function

Private Sub CreateSaveStateTrigger(dock As RadDock)

'Ensure that the RadDock control will initiate postback

' when its position changes on the client or any of the commands is clicked.

'Using the trigger we will "ajaxify" that postback.

dock.AutoPostBack = True

dock.CommandsAutoPostBack = True

AddHandler dock.DockPositionChanged, AddressOf Me.DockPositionChanged

'Dim saveStateTrigger As New AsyncPostBackTrigger()

'saveStateTrigger.ControlID = dock.ID

'saveStateTrigger.EventName = "DockPositionChanged"

'UpdatePanel1.Triggers.Add(saveStateTrigger)

'saveStateTrigger = New AsyncPostBackTrigger()

'saveStateTrigger.ControlID = dock.ID

'saveStateTrigger.EventName = "Command"

'UpdatePanel1.Triggers.Add(saveStateTrigger)

End Sub

Protected Sub DockPositionChanged(ByVal sender As Object, ByVal e As DockPositionChangedEventArgs)

Dim str As String = ""

'Put a break here

End Sub

Private Sub Page_Init(sender As Object, e As System.EventArgs) Handles Me.Init

'Recreate the docks in order to ensure their proper operation

Dim i As Integer = 0

While i < CurrentDockStates.Count

Dim dock As RadDock = CreateRadDockFromState(CurrentDockStates(i))

'We will just add the RadDock control to the RadDockLayout.

' You could use any other control for that purpose, just ensure

' that it is inside the RadDockLayout control.

' The RadDockLayout control will automatically move the RadDock

' controls to their corresponding zone in the LoadDockLayout

' event (see below).

RadDockLayout1.Controls.Add(dock)

'We want to save the dock state every time a dock is moved.

CreateSaveStateTrigger(dock)

System.Math.Max(System.Threading.Interlocked.Increment(i), i - 1)

End While

End Sub

Protected Sub RadDockLayout1_LoadDockLayout(sender As Object, e As DockLayoutEventArgs) Handles RadDockLayout1.LoadDockLayout

'Populate the event args with the state information. The RadDockLayout control

' will automatically move the docks according that information.

For Each state As DockState In CurrentDockStates

e.Positions(state.UniqueName) = state.DockZoneID

e.Indices(state.UniqueName) = state.Index

Next

End Sub

Protected Sub RadDockLayout1_SaveDockLayout(sender As Object, e As DockLayoutEventArgs) Handles RadDockLayout1.SaveDockLayout

'Save the dock state in the page Session. This will enable us

' to recreate the dock in the next Page_Init.

CurrentDockStates = RadDockLayout1.GetRegisteredDocksState()

End Sub

Protected Sub ButtonAddDock_Click(sender As Object, e As System.EventArgs)

Dim dock As RadDock = CreateRadDock()

RadDockZone1.Controls.Add(dock)

CreateSaveStateTrigger(dock)

End Sub

End Class

The issue that I'm facing is this.

With the setup above (SETUP 1): DocksDynamics.ascx is used as an EditForm user control for the GridTest.ascx user control's RadGrid that is used by the DockingTest.aspx page ...

For some reason, the RadDockLayout1_LoadDockLayout event is never fired when I click Edit in any of the records in the RadGrid or whenever I add a dock or move a dock from one zone to another.

Furthermore, when I click the Add Dock button, it is able to add one dock, but when I click it a second time, I get the following error message:

Microsoft JScript runtime error: Sys.WebForms.PageRequestManagerServerErrorException: Cannot unregister UpdatePanel with ID 'UpdatePanel1' since it was not registered with the ScriptManager. This might occur if the UpdatePanel was removed from the control tree and later added again, which is not supported.
Parameter name: updatePanel

BUT, if I change my setup to be like this (SETUP 2): DocksDynamics.ascx (with a Script Manager added to it) is used directly in DockingTest.aspx page and not from within a RadGrid in a separate user control, the RadDockLayout1_LoadDockLayout event gets fired.

<%@ Page Title="" Language="vb" AutoEventWireup="false" MasterPageFile="MasterPage.Master" CodeBehind="DocksTest.aspx.vb" Inherits="DocksTest" %>

<%@ Register Assembly="Telerik.Web.UI" Namespace="Telerik.Web.UI" TagPrefix="telerik" %>

<%@ Register tagPrefix="ctl" tagName="DocksDynamic" src="DocksDynamic.ascx" %>

<asp:Content ID="Content1" ContentPlaceHolderID="AppContentTitle" runat="server">

</asp:Content>

<asp:Content ID="Content2" ContentPlaceHolderID="AppContent" runat="server">

<asp:Label ID="lblMessage" runat="server" EnableViewState="false" Visible="false" />

<form id="Form1" runat="server">

<ctl:DocksDynamic ID="ctlDocksDynamic" runat="server" Visible="true" />

</form>

</asp:Content>

Why does the RadDockLayout1_LoadDockLayout event get fired in SETUP 2 but not in SETUP 1?

I really need it to work in SETUP 1. How can I make it do so?

Thanks in advance for your help.

Dock

answered on 20 Dec 2011

9 answers

136 views

RadToolTip For Particular Node

Hi,

I am using RadToolTipManager for showing ToolTip for my RadTreeView Nodes. I want to show tooltip for my specific RadTreeView Node not for every Node. Is there anyway that I can achieve with some ajaxrequest so that I can hide my tooltip or show for that node which I would like to show.  Any help would be really appreciated.

Protected Sub RadToolTipmanager_AjaxUpdate(ByVal sender As Object, ByVal e As ToolTipUpdateEventArgs)

   Dim roleName As String = e.Value
   Dim listOfUsersInToolTip As New RadListBox
   listOfUsersInToolTip.Width = 150
   listOfUsersInToolTip.Height = 200
   Dim usersList As ArrayList = rc.GetUserRolesByRoleName(DNN.GetPMB(Me).PortalId, roleName)
   If usersList.Count <> 0 Then
   For Each user As DotNetNuke.Entities.Users.UserRoleInfo In usersList
   listOfUsersInToolTip.Items.Add(New RadListBoxItem(user.FullName, user.UserID))
   Next
   listOfUsersInToolTip.SortItems()
   e.UpdatePanel.ContentTemplateContainer.Controls.Add(listOfUsersInToolTip)
   Else

   End If

   End Sub

ToolTip

answered on 20 Dec 2011

1 answer

91 views

Maximize problem after Q2 to Q3 upgrade

Hello

After upgrade from release 2011 Q2 to Q3, RadWindows seems not to maximize RadWindow in IE 8/IE 9 ( IE8/9 in the compatibility mode are ok).

It seems to be maximized and then shrinks. RadWindow will maximize itself just after browser is resized.

javascript:
function popup(windowname, url) {
var oManager = GetRadWindowManager();
var oWnd = oManager.GetWindowByName(windowname);
oWnd.show();
oWnd.setUrl(url);
oWnd.Center();
oWnd.Maximize();
HideOverlay();
}

function HideOverlay() {
var overlay = $('div.TelerikModalOverlay');
if (overlay != null) {
overlay.hide();
}
}

Changes in code like removing functions or changing order had no positive effect.

According to the Release Notes, there was some fix about Maximize - shall I change the code somehow to adjust to such change or this could be a bug?

Window

answered on 20 Dec 2011

1 answer

158 views

problem with position - RadToolTips with SumaryValidator in Grid

Hello.

I have one radgrid, when click in button for insert, the tooltips show me validationsumary, but when click button in update, the position of tooltips is not correct. And the tooltips insert to set position after click in button insert.

I will have to set isClientId = true.... after this the problem with position for radtooltips

Is this my code:

<telerik:RadToolTip runat="server" ID="RadToolTipInsert" Position="TopLeft"

ShowEvent="FromCode" Width="400px" RelativeTo="Element"

OnClientBeforeShow="CheckIfShowInsert" Skin="Sitefinity"

ManualClose="True" Animation="Fade" EnableShadow="True"

Title="<span class='MsgTextoToolTip'><b> No es posible guardar debido a lo siguiente:</b></span> "

RenderInPageRoot="True">

<asp:ValidationSummary ID="valSumaryInsert" runat="server"

ValidationGroup="insert_group" />

</telerik:RadToolTip>

<telerik:RadToolTip ID="RadToolTipUpdate" runat="server" Animation="Fade"

EnableShadow="True" ManualClose="True" OnClientBeforeShow="CheckIfShowUpdate"

Position="TopLeft" RelativeTo="Element" ShowEvent="FromCode" Width="400px"

Title="<span class='MsgTextoToolTip'><b> No es posible guardar debido a lo siguiente:</b></span> "

RenderInPageRoot="True" IsClientID="True" TargetControlID="ToolTipsPositionEditMode"

>

<asp:ValidationSummary ID="valSummaryUpdate" runat="server"

ValidationGroup="update_group" />

</telerik:RadToolTip>

<EditItemTemplate>

<asp:ImageButton ID="btnUpdate" runat="server" BorderStyle="None"

BorderWidth="0px" commandname="Update"

ImageUrl="~/Imagenes/PedidoExpress/diskyellow16.png"

ValidationGroup="update_group" onclientclick="ShowTooltipUpdate();"

ToolTip="Guardar los cambios realizados" />

<InsertItemTemplate>

<asp:ImageButton ID="btnInsert" runat="server" BorderStyle="None"

BorderWidth="0px" commandname="PerformInsert"

ImageUrl="~/Imagenes/PedidoExpress/diskgreen16.png"

ValidationGroup="insert_group" onclientclick="ShowTooltipInsert()"

ToolTip="Agregar beneficiario al pedido" />

function CheckIfShowInsert(sender, args) {

var summaryElem = document.getElementById("<%= valSumaryInsert.ClientID %>");

if (summaryElem.style.display == "none") {

args.set_cancel(true);

}

function ShowTooltipInsert() {

window.setTimeout(function () {

var tooltip = $find("<%= RadToolTipInsert.ClientID %>")

tooltip.show();

}, 10);

}

function CheckIfShowUpdate(sender, args) {

var summaryElem = document.getElementById("<%= valSummaryUpdate.ClientID %>");

if (summaryElem.style.display == "none") {

//API: if there are no errors, do not show the tooltip

args.set_cancel(true);

}

function ShowTooltipUpdate() {

var tooltip = $find("<%= RadToolTipUpdate.ClientID %>")

setTimeout( function ()

{

tooltip.show();

}, 20);

}

i attach 2 images, the image one is working fine with insert, but image two a three is the problem i have.

Thank..

Bets Regards,

ToolTip

answered on 20 Dec 2011

6 answers

363 views

RadWindow + Restriction Zone

Hi,

Here I have one table structure below in which I have to open radwindow by restriction zone id. But Its not working for me.

Table Structure:

<table border="0" cellpadding="0" cellspacing="0" width="100%">
        <tr>
            <%--This is main DIV [DivMain] for Master page performed as restriction Zone for RadWindow.--%>
            <td id="DivMain" >
                 <telerik:RadWindowManager IconUrl="/images/logos16x16.png" RestrictionZoneID="DivMain"
                    MinimizeZoneID="divFooterSlider" ID="RadWindowManagerMaster" DestroyOnClose="true"
                    runat="server" EnableShadow="true">
                    <Windows>
                        <telerik:RadWindow IconUrl="/images/logos16x16.png" ID="CommonWindowToLoad" runat="server"
                            Animation="Fade">
                        </telerik:RadWindow>
                    </Windows>
                </telerik:RadWindowManager>
            </td>
        </tr>
        <tr>
            <td>
            </td>
        </tr>
</table>

Note: -
1) I have tried with "KeepInScreenBounds".
2) I have tried with "<td id="DivMain" runat="server">"

By above two options it maximize the window but its maximize to whole browser not limited to that perticular <TD>.

My Javascript by which radwindow calls is below:

<telerik:RadCodeBlock ID="RadCodeBlock1" runat="server">
        <script type="text/javascript">
function openWin(pagename, radwinname) {
                var FullURL = location.href;
                var urlArr = FullURL.split('/');
                var testUrl = urlArr[0] + "//" + urlArr[2];
                var oWnd = radopen(testUrl + "/" + pagename, radwinname);
                oWnd.set_behaviors(Telerik.Web.UI.WindowBehaviors.Reload + Telerik.Web.UI.WindowBehaviors.Move + Telerik.Web.UI.WindowBehaviors.Close + Telerik.Web.UI.WindowBehaviors.Resize + Telerik.Web.UI.WindowBehaviors.Pin + Telerik.Web.UI.WindowBehaviors.Minimize + Telerik.Web.UI.WindowBehaviors.Maximize);
                oWnd.set_title(radwinname);
                oWnd.maximize();
            }
</script>
    </telerik:RadCodeBlock>

Please help me to solve this. Thank you in advance.

Regards,

Kaushal Jani

Window

answered on 20 Dec 2011

1 answer

106 views

Tooltip inside radgrid

Dear All,
i am doing tooltip in radgrid as http://demos.telerik.com/aspnet-ajax/tooltip/examples/targetcontrolsandajax/defaultcs.aspx
demo,but i want to get gridbound column value of that row on UpdateToolTip method,as i can get datakeyvalue.

how can i get?

thanks & regards

ToolTip

answered on 20 Dec 2011
