Arrange data from two different data objects in subreports

4 posts, 0 answers
  1. Sandeep
    Sandeep avatar
    13 posts
    Member since:
    Aug 2013

    Posted 07 Oct 2014 Link to this post

    Hello,
    I am using sub-reports. I have a report containing two sub-report. Each sub report points to different business data object.
    In the sub-reports how can we arrange data so that it makes more sense?
    In the report you can see the data appears mixed, please refer attachment.
    First nine columns are from (Column A to J) subreport1 and last four columns  (Column K to N) are from subreport2.
    Can we do some arrangements so that the data is separated as per red markings?
    I want data item 2 to start in subrepor1 after we are finished displaying data for data item 1 in subreport2.
    Please advice.
    Regards,
    Sandeep
  2. Sandeep
    Sandeep avatar
    13 posts
    Member since:
    Aug 2013

    Posted 07 Oct 2014 in reply to Sandeep Link to this post

    I am using Windows Form application in C#.
  3. Sandeep
    Sandeep avatar
    13 posts
    Member since:
    Aug 2013

    Posted 08 Oct 2014 Link to this post

    Any thoughts / suggetions please?
  4. Stef
    Admin
    Stef avatar
    3610 posts

    Posted 08 Oct 2014 Link to this post

    Hello Sandeep,

    In your scenario the data is visualized by two separate sub reports. Thus synchronizing the layout of the distinct templates or exchanging information between the data scopes of the sub reports is not supported via expressions.


    Our suggestions in your support ticket on the same question are as follows:


    Only Page Sections are ignored when a report is rendered in a SubReport item. Thus in the sub report you can add a ReportFooterSection or static group (without specified grouping field) and use the built-in Data functions e.g. Exec, to get the required total in the newly produced sections. The report is data driven template and Data functions can be used in header and footer sections as long as the provided data scope is correct.



    Since mixing data scopes of different sub reports is not supported, you can use your data model to display related information between sub reports:

    - Expose properties getting the needed calculations from the data model and use them as fields directly;
    - Avoid passing the scope as a string from the data model. Any change in the reports layout will cause you troubles. Instead use directly the name of the scopes in expressions.
    - To have synchronized sections/items sizes between reports format the data. For example synchronize the string length of two properties used as fields in the different reports, and customize the report templates to have the same sizes for the visualizing items.



    If you need further help, let us continue the discussion in the support ticket regarding these questions in order to avoid splitting details between the threads.


    Thank you for your understanding.

    Regards,
    Stef
