Questions on UI for WPF Forum

1 answer

74 views

Is there a way to display a message to the user when the bound collection is empty?
I was able to add a custom class to do this for the GridView, but I need to be able to do this with the Tab Control. Right now, it just appears to be blank and I'd like to display a message informing the user on how to create the collection.

TabControl

answered on 16 Sep 2011

1 answer

91 views

Upper Case Data Entry

Is there a built in way to force the data entry on the RadDataForm to upper case as the user types?

DataForm

answered on 16 Sep 2011

5 answers

194 views

Create Gauge in code w/ CustomTickMark

I am creating the Gauges in code (based on a config file) with a Scale, Ranges, and Indicator Needle... mostly from these two examples: http://www.telerik.com/community/forums/wpf/gauges/how-to-build-and-create-dynamic-indicator-in-vb-code-instead-of-xml.aspx and http://www.telerik.com/community/forums/wpf/gauges/adding-gauge-only-with-code.aspx. It works well so far.
I would also like to add a CustomTickMark to the Gauges similar to this post... http://www.telerik.com/community/forums/wpf/gauges/how-do-i-make-a-label-inside-a-gauge.aspx but I need to do it in code rather than XAML. There are several variations of the code I have tried below... none of them seem to work. No label is displayed and also, it throws an error (below) when it's run.

Any help/info/example would be very much appreciated.

Dim tl As New TickList

tl.Name = "ticklist" & gauges.Count.ToString

Dim ctm As New CustomTickMark

ctm.Name = "CustomTickMark" & gauges.Count.ToString

ctm.Template = GetInternalLabel()

tl.Items.Add(ctm)

scale.Ticks.Add(tl)


Private Function GetInternalLabel() As ControlTemplate
       Dim l As FrameworkElementFactory = New FrameworkElementFactory(GetType(TextBlock))
       'l.SetValue(Ellipse.FillProperty, Brushes.AliceBlue)
       'l.SetValue(Ellipse.MarginProperty, New Thickness(2))
       l.SetValue(TextBlock.TextProperty, "Test")


       Dim cv As FrameworkElementFactory = New FrameworkElementFactory(GetType(Canvas))

       'grid.SetValue(Grid.MarginProperty, new Thickness(5));


       cv.AppendChild(l)


       Dim ct As New ControlTemplate(GetType(CustomTickMark))

       'Dim cp As New ContentPresenter
       'cp.Name = "cp" & gauges.Count.ToString
       ''Dim cv As New Canvas
       ''cv.Name = "cv" & gauges.Count.ToString
       'cp.Content = cv
       ''Dim l As New TextBlock
       ''l.Name = "label" & gauges.Count.ToString
       ''l.Text = "test"
       ''cv.Children.Add(l)

       ct.VisualTree = l


       Return ct
   End Function


System.ArgumentNullException was unhandled
  Message=Value cannot be null.
Parameter name: reference
  Source=PresentationCore
  ParamName=reference
  StackTrace:
       at System.Windows.Media.VisualTreeHelper.HitTest(Visual reference, Point point)
       at Telerik.Windows.Controls.Gauges.GaugeHelper.CheckPointOver(FrameworkElement element, Point point) in c:\Builds\WPF_Scrum\Release_WPF\Sources\Development\Controls\Gauge\GaugeHelper.cs:line 62
       at Telerik.Windows.Controls.Gauges.GaugeHelper.CheckMouseOver(FrameworkElement element, MouseEventArgs e) in c:\Builds\WPF_Scrum\Release_WPF\Sources\Development\Controls\Gauge\GaugeHelper.cs:line 33
       at Telerik.Windows.Controls.Gauges.ScaleBase.ScaleBase_MouseMove(Object sender, MouseEventArgs e) in c:\Builds\WPF_Scrum\Release_WPF\Sources\Development\Controls\Gauge\Scales\ScaleBase.cs:line 1426
       at System.Windows.Input.MouseEventArgs.InvokeEventHandler(Delegate genericHandler, Object genericTarget)
       at System.Windows.RoutedEventArgs.InvokeHandler(Delegate handler, Object target)
       at System.Windows.RoutedEventHandlerInfo.InvokeHandler(Object target, RoutedEventArgs routedEventArgs)
       at System.Windows.EventRoute.InvokeHandlersImpl(Object source, RoutedEventArgs args, Boolean reRaised)
       at System.Windows.UIElement.RaiseEventImpl(DependencyObject sender, RoutedEventArgs args)
       at System.Windows.UIElement.RaiseTrustedEvent(RoutedEventArgs args)
       at System.Windows.UIElement.RaiseEvent(RoutedEventArgs args, Boolean trusted)
       at System.Windows.Input.InputManager.ProcessStagingArea()
       at System.Windows.Input.InputManager.ProcessInput(InputEventArgs input)
       at System.Windows.Input.MouseDevice.Synchronize()
       at System.Windows.Input.MouseDevice.PostProcessInput(Object sender, ProcessInputEventArgs e)
       at System.Windows.Input.InputManager.RaiseProcessInputEventHandlers(ProcessInputEventHandler postProcessInput, ProcessInputEventArgs processInputEventArgs)
       at System.Windows.Input.InputManager.ProcessStagingArea()
       at System.Windows.Input.InputManager.ProcessInput(InputEventArgs input)
       at System.Windows.Input.InputProviderSite.ReportInput(InputReport inputReport)
       at System.Windows.Interop.HwndMouseInputProvider.ReportInput(IntPtr hwnd, InputMode mode, Int32 timestamp, RawMouseActions actions, Int32 x, Int32 y, Int32 wheel)
       at System.Windows.Interop.HwndMouseInputProvider.FilterMessage(IntPtr hwnd, WindowMessage msg, IntPtr wParam, IntPtr lParam, Boolean& handled)
       at System.Windows.Interop.HwndSource.InputFilterMessage(IntPtr hwnd, Int32 msg, IntPtr wParam, IntPtr lParam, Boolean& handled)
       at MS.Win32.HwndWrapper.WndProc(IntPtr hwnd, Int32 msg, IntPtr wParam, IntPtr lParam, Boolean& handled)
       at MS.Win32.HwndSubclass.DispatcherCallbackOperation(Object o)
       at System.Windows.Threading.ExceptionWrapper.InternalRealCall(Delegate callback, Object args, Int32 numArgs)
       at MS.Internal.Threading.ExceptionFilterHelper.TryCatchWhen(Object source, Delegate method, Object args, Int32 numArgs, Delegate catchHandler)
       at System.Windows.Threading.Dispatcher.InvokeImpl(DispatcherPriority priority, TimeSpan timeout, Delegate method, Object args, Int32 numArgs)
       at MS.Win32.HwndSubclass.SubclassWndProc(IntPtr hwnd, Int32 msg, IntPtr wParam, IntPtr lParam)
       at MS.Win32.UnsafeNativeMethods.DispatchMessage(MSG& msg)
       at System.Windows.Threading.Dispatcher.PushFrameImpl(DispatcherFrame frame)
       at System.Windows.Threading.Dispatcher.PushFrame(DispatcherFrame frame)
       at System.Windows.Threading.Dispatcher.Run()
       at System.Windows.Application.RunDispatcher(Object ignore)
       at System.Windows.Application.RunInternal(Window window)
       at System.Windows.Application.Run(Window window)
       at System.Windows.Application.Run()
       at WPFDashboard.Application.Main() in C:\Users\jcrumpton\Documents\Visual Studio 2010\Projects\WPFDashboard\WPFDashboard\obj\x86\Debug\Application.g.vb:line 64
       at System.AppDomain._nExecuteAssembly(RuntimeAssembly assembly, String[] args)
       at System.AppDomain.ExecuteAssembly(String assemblyFile, Evidence assemblySecurity, String[] args)
       at Microsoft.VisualStudio.HostingProcess.HostProc.RunUsersAssembly()
       at System.Threading.ThreadHelper.ThreadStart_Context(Object state)
       at System.Threading.ExecutionContext.Run(ExecutionContext executionContext, ContextCallback callback, Object state, Boolean ignoreSyncCtx)
       at System.Threading.ExecutionContext.Run(ExecutionContext executionContext, ContextCallback callback, Object state)
       at System.Threading.ThreadHelper.ThreadStart()
  InnerException:

Gauges

answered on 16 Sep 2011

1 answer

128 views

NullReferenceException after loading data

After installing 2011 Q2, I get a NullReferenceException:

System.NullReferenceException occurred

Message=Object reference not set to an instance of an object.

Source=Telerik.Windows.Controls.GridView

StackTrace:

at Telerik.Windows.Controls.GridView.Automation.GridViewCellAutomationPeer.GetNameCore() in c:\TB\102\WPF_Scrum\Release_WPF_40\Sources\Development\Controls\GridView\GridView\GridView\Automation\GridViewCellAutomationPeer.cs:line 146

InnerException:

This happens after I load the data (22 rows). The first 11 are visible. It happens repeatedly with this set of data but no problem with other data. Went back to 20010 Q2 SP2 and it works fine.

GridView

answered on 16 Sep 2011

4 answers

195 views

Selecting row's childDataControl on first expand

Hello,
I am using a hierachical RadGridView and when i expand a GridViewRow, the first time it expands, the childDataControls list count is 0. If i collapse the row , the event is fired again and the childDataControls list is populated. I need to get the row's childDataControls on the first expand event, is it possible?

I'm trying to select a row's childDataControl (RadGridView) the first time that row is expanded.
What would a different approach be?

private void myGrid_RowIsExpandedChanged(object sender, RowEventArgs e)
{
GridViewRow r = e.Row as GridViewRow;
var childControls = r.ChildDataControls;
}

GridView

answered on 16 Sep 2011

0 answers

162 views

TreeListView not refreshing data on datasource change

I have a TreeListView that is bound to an ObservableCollection datasource.

In the radTreeListView1_CellValidating method I change another cells value depending on certain things. That change is not visible on the TreeListView. But if i click on the cell that was suppose to change. It's value updates to what it should be..

So it looks like datasource gets the change but the view does not refresh until cell gets focus.

Help?

TreeListView

asked on 15 Sep 2011

1 answer

105 views

OpenDocumentCommand

I use the latest internal build RadControls_for_WPF40_2011_2_0912_DEV_hotfix.

It seems like the RichTextBoxUI:RadRichTextBoxRibbonUI.RichTextCommand="{Binding Path=OpenDocumentCommand}
no longer likes to open *.docx -files.

RichTextBox

answered on 15 Sep 2011

1 answer

118 views

Add an item when dragging and dropping a file from windows on to RAD tree view

Hello There,

I need help from you ! As I am using WPF Telerik controls RAD Tree View. I want to add a file name as item when I am dragging and dropping a file from windows explorer on to tree view.

Quick reply is very help fulll .!

ThnQ
Naresh

TreeView

answered on 15 Sep 2011

1 answer

96 views

About ChartArea ScrollBar

Hi there,could I use my own ScrollBar instead of ChartArea Default Bar,and how,Thanks!

BestWishes to Telerik Team

Chart

answered on 15 Sep 2011

1 answer

219 views

TreeListView RowStyle Template

Hi There,

The online documentation suggests that the RadTreeListView may be customized/templated within Expression Blend by selecting the item and clicking 'Object -> Edit Additional Templates -> Edit <Template/Style> -> Edit a Copy...'.

However, when selecting the RadTreeListView in Expression Blend 4, the 'Edit Current' and 'Edit a Copy' menu items are not enabled. This is true for every style and template in the list of available templates to edit.

How can I get this to work? I'd like to use this control for an important project but it will require additional customization.

Thanks.

TreeListView

answered on 15 Sep 2011
