Questions on UI for WPF Forum

0 answers

146 views

setting background color for special slot

Hi,

I am using special slots to differentiate working hours and non working hours in scheduleview. For non working hours I change the background color just to indicate that the slot is not available. My problem is if two slots with the same time-span are added in special slot list then I get the slot background color very darker. For example, I add the slots which are in the past time to special slot collection. If the current time is 11 AM then the slot (12 am - 10:59am) is added in special slots. So It is reflected in Scheduleview and background color is changed. Now I have one more slot for setting the day break. The slot (10am-10:30am) is the break time. So I also need to add this in the special slot collection. If I add this the bg color of the break slot is very darker when compared to others. Because already one slot ( from 12 am -10:59) is a special slot. I dont want this to happen. HOw to do this?

With Thanks and Regards
Jeyakumar

ScheduleView

asked on 15 Nov 2011

1 answer

113 views

Apply Filter on Expanded node only

Hello,

I have a treelistview. When user right click on an item and applies filter then I add one FilterDescriptor to the treelistview.
But it tries to filter on all the rows. My requirement is when user right click on any item then the filter should be applied only to the expanded nodes, not to those are collapsed nodes.

I have treelistview having upto 7 levels of expanded nodes. What i want is when user applies filter descriptor then it should filter all the data whose first level is expanded

Level 1

Level 2

Level 3

Level 4

Level 5

Level 6

Level 7

(-)

Org

Dept 1

Cell 1

Mgr 1

Lead 1

Resp 1

Work1

Work2

Work3

Resp 2

Work4

Work5

Work6

(+)

Dept 2

(+)

Dept 3

(-)

Dept4

Cell 4

Mgr 4

Lead 4

Resp 4

Work1

Work2

Work3

Resp 4

Work4

Work5

Work6

Dept 2 & Dept 3 are not in expanded state. While I filter I want the filter should be applied to those records of Dept 1 & Dept 4 only

User can right click on Level 7 data

.

TreeListView

answered on 15 Nov 2011

2 answers

269 views

How to cancel the Current Item Changed event

There are times when I would need to cancel the Current Item Changed event. This is based on un-saved data for exmaple. So, when the user clicks on the right/left arrows (for navigation), the Data Form instantly changes the Current Item and then fires the event.

Well, if conditions determine that the user should not move forward/backward, how do I go back to the previous Current Item?

Example: Data Form has three values (1, 2, 3). Current Item is 2. User clicks right nav. arrow and Data Form takes the user to Item 3. based on a condition (true/false) I need the Data Form to stay on item 2 (or go back to item 2)

Any ideas would be appreciated.

Thanks, M

DataForm

answered on 14 Nov 2011

2 answers

97 views

Hide specific days of a week in WeekView

Hello,

In a ScheduleView, I need to hide some days of each week (for example wednesdays and fridays). I look at the grouping and filtering functionalities, but I'm not sure it can help me with my need.

Is it possible to do this on a ScheduleView (only in WeekView) ? If yes, can you tell me how ?

Thank you in advance

Pauline

ScheduleView

answered on 14 Nov 2011

8 answers

398 views

How can I hide a Row in the GridView?

I would like to hide some rows in a GridView, however setting the Row's visibility to Collapsed still leaves a blank space where the row should be.

The trigger I am using to hide both GridViewGroupRows and GridViewRows looks like this:

<Style TargetType="{x:Type telerik:GridViewGroupRow}">

<Setter Property="Visibility" Value="Visible" />

<Style.Triggers>

<DataTrigger Binding="{Binding Group.Key, RelativeSource={RelativeSource Self}}" Value="SomeValue">

<Setter Property="Visibility" Value="Collapsed" />

</DataTrigger>

</Style.Triggers>

</Style>

I do not want to filter results because I need them for aggregate results in the groups and the footer. So how can I hide specific GridViewRows without filtering the data?

GridView

answered on 14 Nov 2011

1 answer

183 views

Problem with bind Context Menù parameter

Hi i have correct make a Context menù and binded it some example,
after i have bind DelegateCommand some MyCommand,
And the Context menù is ok, but i whant pass to ContextMenù from the treeview Datacontext ,
the data, for call the right item when i click on the RadMenuItem, and take for example treeitemDatacontext.GuidId

In the telerik example use CommandParameter="{Binding Menu.ClickedListBoxItem, RelativeSource={RelativeSource Self}}"
but i dont undestand the Menu.ClickedListBoxItem item .

i have try, but not work, please help me

regard

<UserControl x:Class="Sicant.Modules.PSCDocument.Controls.TreeView"

xmlns="http://schemas.microsoft.com/winfx/2006/xaml/presentation"

xmlns:x="http://schemas.microsoft.com/winfx/2006/xaml"

xmlns:d="http://schemas.microsoft.com/expression/blend/2008"

xmlns:example="clr-namespace:Sicant.Modules.PSCDocument"

xmlns:mc="http://schemas.openxmlformats.org/markup-compatibility/2006"

xmlns:tlkn="http://schemas.telerik.com/2008/xaml/presentation"

xmlns:Commands="clr-namespace:Sicant.Global.Commands;assembly=Sicant.Global" d:DesignHeight="600"

d:DesignWidth="300"

mc:Ignorable="d">

<UserControl.Resources>

<Style x:Key="SquareButton" TargetType="{x:Type Button}">

<Setter Property="Button.Height" Value="25" />

<Setter Property="Button.Width" Value="25" />

<Setter Property="Margin" Value="2,2,2,2" />

</Style>

<Style x:Key="Menu" TargetType="Grid">

<Setter Property="Height" Value="25" />

<Setter Property="Width" Value="300" />

<Setter Property="Background" Value="{StaticResource DarkBrush}" />

</Style>

<DataTemplate x:Key="Risorsa1_Template">
