Questions on UI for WinForms Forum

7 answers

322 views

Hi There,

I am very new to Telerik winform controls and trying to use RadRibbonBar and would like to get all the child elements (i.e. start menu items, buttons, group boxes etc) from the ribbon bar in a control collection. I want to enable and disable the specific controls based on user rights.

Please let me know if there is any possibility to get around that.

Cheers,

Robert

RibbonBar

answered on 14 Mar 2013

1 answer

121 views

Scroll Schedule when dragging appointment

Sir;

Can we scroll schedule when we are dragging a appointment.
( is there any property like ensure visible)
Also can we create a appointment just on clicking scheduler and drag and drop to desire date and time.

Thanks & regards
Raman kumar

Scheduler and Reminder

answered on 14 Mar 2013

3 answers

761 views

Printing and Print Preview

Is there a flag or argument that would differentiate the purpose in the IPrintable:PrintPage function.

I would like to modify what the print preview looks like as opposed to what is actually being sent to the printer. Our printers prints everything in Landscape, even though the the page orientation is Portrait. (yes its a specialized printer) . So I would like the user to be able to read it on the screen in Horizontal, but when I send it to the printer itself, Id like the text to be Vertical.

For PrintPreview I am using the RadGdiGraphics, and Telerik.WinControls.Primitives.TextParams.

Currently I have it set as

tp.textOrientation = Orientation.Vertical

Which is what needs to be sent to the printer, but for print preview I would like

tp.textOrientation = Orientation.Horizontal

-------

Could this be accomplished using a PrintController. I've see limited documentation on that, and no examples, or explanation of exactly what it does, or allow you to programatically control.

Thanks in advance.

General Discussions

answered on 14 Mar 2013

7 answers

235 views

RadTabControl control support microsoft coded ui automation

Hi,
Trying to automate the web application using the Microsoft coded ui, in one of page Telerik RadTabControl is used.
Telerik control Version: 2011.2.712.1040
Not able to automate the controls that is present inside the RadTabControl.

Please conform whether the 'RadTabControl' support the automation?

General Discussions

answered on 14 Mar 2013

10 answers

296 views

Change the font menu in radgridview

How can I change the font menu on radgridview??
Attach a photo

GridView

answered on 14 Mar 2013

3 answers

227 views

Cant able to clear filter value in GridViewDateTimeColumn

HI,

I am not able to clear filter value in GridViewDateTimeColumn while pressing delete key or backspace key. Instead of clear it resets to default date. Whether can we set any key down event explicitly in that DateTimePIcker or was there any other way to clear filter value when press delete key.

GridView

answered on 14 Mar 2013

2 answers

796 views

[Solved] Accessing child elements of a Custom ListView Item

Hi Guys

I'm want to create a listview of items where the item has a waiting bar which appears when the item is pressed and disappears again once a long running process kicked off by the press has completed. I have successfully built the custom item but when I go to the ItemMouseClick event of the listview I'm not sure how to access the waiting bar element so that I can make it visible and set it running.

Many thanks in advance

regards
Ian Carson

public class RadCustomVariationViewVisualItem : IconListViewVisualItem

{

private LightVisualElement _imageElement;

private LightVisualElement _nameElement;

private LightVisualElement _descriptionElement;

private RadWaitingBarElement _waitingBarElement;

private StackLayoutPanel _overallLayout;

private StackLayoutPanel _textLayout;

protected override void CreateChildElements()

{

base.CreateChildElements();

_overallLayout = new StackLayoutPanel {Orientation = Orientation.Horizontal};

_imageElement = new LightVisualElement

{

DrawText = false,

ImageLayout = ImageLayout.Center,

StretchVertically = false,

Margin = new Padding(10, 22, 10, 5),

NotifyParentOnMouseInput = true,

ShouldHandleMouseInput = false

};

_overallLayout.Children.Add(_imageElement);

_textLayout = new StackLayoutPanel { Orientation = Orientation.Vertical };

_overallLayout.Children.Add(_textLayout);

_nameElement = new LightVisualElement

{

TextAlignment = ContentAlignment.MiddleLeft,

Margin = new Padding(10, 10, 10, 5),

Font = new Font("Segoe UI", 12, FontStyle.Bold, GraphicsUnit.Point),

NotifyParentOnMouseInput = true,

ShouldHandleMouseInput = false

};

_textLayout.Children.Add(_nameElement);

_descriptionElement = new LightVisualElement

{

TextAlignment = ContentAlignment.MiddleLeft,

Margin = new Padding(10, 5, 10, 5),

Font = new Font("Segoe UI", 12, FontStyle.Bold, GraphicsUnit.Point),

NotifyParentOnMouseInput = true,

ShouldHandleMouseInput = false

};

_textLayout.Children.Add(_descriptionElement);

_waitingBarElement= new RadWaitingBarElement();

_waitingBarElement.WaitingBarOrientation = Orientation.Horizontal;

_waitingBarElement.WaitingDirection = ProgressOrientation.Right;

_waitingBarElement.Size = new Size(120, 14);

_waitingBarElement.WaitingIndicatorSize = new Size(50, 30);

_waitingBarElement.WaitingSpeed = 90;

_waitingBarElement.WaitingStep = 2;

_waitingBarElement.WaitingStyle = WaitingBarStyles.Dash;

//_waitingBarElement.Visibility = ElementVisibility.Collapsed;

_waitingBarElement.StartWaiting();

_textLayout.Children.Add(_waitingBarElement);

Children.Add(_overallLayout);

Padding = new Padding(10);

Margin = new Padding(4, 2, 4, 2);

Shape = new RoundRectShape(5);

DrawBorder = true;

DrawFill = true;

BorderInnerColor = SystemColors.ControlLightLight;

BorderInnerColor2 = SystemColors.Control;

BorderInnerColor3 = SystemColors.ControlDark;

BorderInnerColor4 = SystemColors.ControlDarkDark;

BorderGradientStyle = GradientStyles.Solid;

BorderBottomColor = SystemColors.ControlDark;

BorderLeftColor = SystemColors.ControlDark;

BorderTopColor = SystemColors.ControlDark;

BorderRightColor = SystemColors.ControlDark;

BorderGradientAngle = 270;

BorderGradientStyle = GradientStyles.Solid;

BackColor = SystemColors.Window;

BackColor2 = SystemColors.Control;

BackColor3 = SystemColors.ControlDark;

BackColor4 = SystemColors.ControlLightLight;

GradientAngle = 90;

GradientPercentage = (float) 0.5;

GradientPercentage2 = (float) 0.666;

GradientStyle = GradientStyles.Linear;

NumberOfColors = 2;

SmoothingMode = SmoothingMode.AntiAlias;

}

protected override void OnMouseEnter(EventArgs e)

{

base.OnMouseEnter(e);

BorderInnerColor = SystemColors.ControlLightLight;

BorderInnerColor2 = SystemColors.Control;

BorderInnerColor3 = SystemColors.ControlDark;

BorderInnerColor4 = SystemColors.ControlDarkDark;

BorderGradientStyle = GradientStyles.Solid;

BorderBottomColor = SystemColors.ControlDark;

BorderLeftColor = SystemColors.ControlDark;

BorderTopColor = SystemColors.ControlDark;

BorderRightColor = SystemColors.ControlDark;

BorderGradientAngle = 90;

BorderGradientStyle = GradientStyles.Linear;

BackColor = SystemColors.Window;

BackColor2 = SystemColors.Control;

BackColor3 = SystemColors.ControlDark;

BackColor4 = SystemColors.ControlLightLight;

GradientAngle = 90;

GradientPercentage = (float)0.5;

GradientPercentage2 = (float)0.666;

GradientStyle = GradientStyles.Linear;

NumberOfColors = 3;

SmoothingMode = SmoothingMode.AntiAlias;

}

protected override void OnMouseLeave(EventArgs e)

{

base.OnMouseLeave(e);

BorderInnerColor = SystemColors.ControlLightLight;

BorderInnerColor2 = SystemColors.Control;

BorderInnerColor3 = SystemColors.ControlDark;

BorderInnerColor4 = SystemColors.ControlDarkDark;

BorderGradientStyle = GradientStyles.Solid;

BorderBottomColor = SystemColors.ControlDark;

BorderLeftColor = SystemColors.ControlDark;

BorderTopColor = SystemColors.ControlDark;

BorderRightColor = SystemColors.ControlDark;

BorderGradientAngle = 270;

BorderGradientStyle = GradientStyles.Solid;

BackColor = SystemColors.Window;

BackColor2 = SystemColors.Control;

BackColor3 = SystemColors.ControlDark;

BackColor4 = SystemColors.ControlLightLight;

GradientAngle = 90;

GradientPercentage = (float)0.5;

GradientPercentage2 = (float)0.666;

GradientStyle = GradientStyles.Linear;

NumberOfColors = 2;

SmoothingMode = SmoothingMode.AntiAlias;

}

protected override void SynchronizeProperties()

{

_imageElement.Image = (Image)Data["Image"];

_nameElement.Text = Convert.ToString(Data["Name"]);

_descriptionElement.Text = Convert.ToString(Data["Description"]);

}

protected override SizeF MeasureOverride(SizeF availableSize)

{

var measuredSize = base.MeasureOverride(availableSize);

_overallLayout.Measure(measuredSize);

return measuredSize;

}

protected override SizeF ArrangeOverride(SizeF finalSize)

{

base.ArrangeOverride(finalSize);

_overallLayout.Arrange(new RectangleF(PointF.Empty, finalSize));

return finalSize;

}

private void LvViewsItemMouseClick(object sender, ListViewItemEventArgs e)

{

if (_resultsTable==null)

_resultsTable = StrategyBacktestLoader.getBacktestResults(frmParadigmFM.Authority, ThisParent.StrategyID, ThisParent.ID,

ThisVariation.ID);

var element = sender as RadCustomVariationViewVisualItem;

var view = (BacktestViewType) e.Item.Tag;

DisplayBacktestView(view);

}

ListView

answered on 14 Mar 2013

1 answer

590 views

RadListView scroll

Hello,

I'm having problems when updating the DataSource property.
when I update the DataSource property of a radListView object the scroll bar jumps to the start.
when accessing the scroll properties (.AutoScrollPosition, VerticalScroll.Value) i always get that the value is 0.
how can i keep the ListView in it's place (making the scroll not go back to the start of the list)?

thank you

ListView

answered on 13 Mar 2013

5 answers

475 views

RadMultiColumnComboBox filtering(with lot of data)

Hi,
I am using this property for best fit my column(objComboBox.MultiColumnComboBoxElement.AutoSizeDropDownToBestFit =

true;) in RadMultiColumnComboBox columns but when i have data source which have a lot of data i need to implement filtering on it.
I am implemening it in this way:

FilterDescriptor filter = new FilterDescriptor();

filter.PropertyName = objComboBox.DisplayMember;

filter.Operator =

FilterOperator.Contains;

objComboBox.EditorControl.MasterTemplate.FilterDescriptors.Add(filter);
but it's take a lot of time when the filter is auto complete.
Please how to make filtering in this controll and dont take a time.
Note: When i am not using AutoSizeDropDownToBestFit it's( Filter) works fine and i dont have delay( my data source have more then 1000 items and 3 columns), but when i have Combo which have more then 3 column and the size of DropDown is less, than the user can not see what have in that control.
What is your suggestion to eliminate this issue.
Best regards,
Gezim

MultiColumn ComboBox

answered on 13 Mar 2013

1 answer

289 views

RadRibbonForm and Form Icon Problem

How do I show my form icon in the taskbar only, not in ribbonbar, when I am using the RadRibbonForm and BackStage?

RibbonBar

answered on 13 Mar 2013
