Questions on UI for WinForms Forum

2 answers

110 views

Hi,

I want a checked combo box there is no such control so how can i get it work .

If i check the first item then all my below items shld get checked ,and if i uncheck my first item then the below all items should get uncheck .How can i implement this functionality.can anyone please explain how to achieve this functionality.

Thanks
Hema

ComboBox and ListBox (obsolete as of Q2 2010)

answered on 12 Jul 2011

2 answers

188 views

Problem with pinned column and CellFormatting event

In my RadGridView, I've marked one column as pinned. Without any formatting, this column shows up as a sky blue color. When I apply some cell formatting in the RadGridView's CellFormatting event, the cells in the pinned column are white. I presume this is because I'm resetting cell element formatting values for cells that don't meet the formatting criteria. When I mouse over any cells in the RadGridView, it causes the cells in the pinned column to turn blue again. I've thought about adding a check for IsPinned in the CellFormatting event and changing the color to blue myself, but it seems that this should be handled by the ResetValue method. But, before I submit a bug report, I wanted to make sure I shouldn't be doing something differently.

Thanks,
Robert

Private Sub RadGridView1_CellFormatting(ByVal sender As System.Object, ByVal e As Telerik.WinControls.UI.CellFormattingEventArgs) Handles RadGridView1.CellFormatting

Dim equationFont As New Font("Cambria", 9, FontStyle.Bold Or FontStyle.Italic)

If e.Row.DataBoundItem.Row("EQUATION") = "Y" Then

e.CellElement.Font = equationFont

If gbUseColorCoding Then ' global boolean variable for users to disable colors

e.CellElement.DrawFill = True

e.CellElement.NumberOfColors = 1

e.CellElement.BackColor = Color.PaleGoldenrod

Else

e.CellElement.ResetValue(LightVisualElement.DrawFillProperty)

e.CellElement.ResetValue(LightVisualElement.NumberOfColorsProperty)

e.CellElement.ResetValue(LightVisualElement.BackColorProperty)

End If

Else

e.CellElement.ResetValue(LightVisualElement.FontProperty)

e.CellElement.ResetValue(LightVisualElement.DrawFillProperty)

e.CellElement.ResetValue(LightVisualElement.NumberOfColorsProperty)

e.CellElement.ResetValue(LightVisualElement.BackColorProperty)

End If

End Sub

GridView

answered on 12 Jul 2011

3 answers

289 views

How to set radPageViewPage Font Color

1.How to set radPageViewPage Font Color?

2.How to set border for strip?

Thanks

PageView

answered on 11 Jul 2011

5 answers

223 views

GridViewComboBoxColumn Value Only Visible on Edit

Hi,
I have seen variations of this question asked on several different posts, but either the fix has either been irrelevant to my particular situation or the question has gone unanswered. I have created a simplified example that you can run on your own computer, so as to easily demonstrate my problem.

I have a simple class "dog" which contains a property "Breed" of enum type "DogBreeds". I wish to display this value in a GridView combo box, but using more user-friendly text than the enum values.

This is my data class:

Public Class Dog

Private dmName As String

Private dmColour As String

Private dmBreed As DogBreeds

Public Sub New(ByVal _name As String, ByVal _colour As String, ByVal _breed As DogBreeds)

MyBase.New()

dmName = _name

dmColour = _colour

dmBreed = _breed

End Sub

Public Property Name() As String

Get

Return dmName

End Get

Set(ByVal value As String)

dmName = value

End Set

End Property

Public Property Colour() As String

Get

Return dmColour

End Get

Set(ByVal value As String)

dmColour = value

End Set

End Property

Public Property Breed() As DogBreeds

Get

Return dmBreed

End Get

Set(ByVal value As DogBreeds)

dmBreed = value

End Set

End Property

End Class

And my Enum:

Public Enum DogBreeds

Staff

Husky

GShep

End Enum

To demonstrate the problem, create a GridView on a form called "dgv" and add the following code:

'Add some example data

dogs = New List(Of Dog)

dogs.Add(New Dog("Sacha", "Brown", DogBreeds.Staff))

dogs.Add(New Dog("Nimbus", "Black/Brown", DogBreeds.GShep))

dogs.Add(New Dog("Chinook", "White", DogBreeds.Husky))

'Set the grid data source:

dgv.DataSource = dogs

'Create the data source for the combo column, comprosed of a column of the enum and a column of the

' "friendly" string represetion for that enum value

Dim dtBreeds As New DataTable

dtBreeds.Columns.Add("BreedEnum", GetType(DogBreeds))

dtBreeds.Columns.Add("BreedName", GetType(String))

dtBreeds.Rows.Add(DogBreeds.GShep, "German Sheppard")

dtBreeds.Rows.Add(DogBreeds.Husky, "Icelandic Husky")

dtBreeds.Rows.Add(DogBreeds.Staff, "Staffordshire Bull Terrier")

'Set the column display and value members and the data source for the combo

With DirectCast(dgv.Columns("Breed"), GridViewComboBoxColumn)

.DisplayMember = "BreedName"

.ValueMember = "BreedEnum"

.DataSource = dtBreeds

End With

Run the form. All the combos are blank, but when you click on a combo cell, the correct value is displayed, but disappears again when focus is lost from the cell, so it looks like a display bug. I have successfully used this method on a DataGrid, so not sure why it does not work here.

Any help much appreciated

Shane

GridView

answered on 11 Jul 2011

0 answers

128 views

TreeListView search

Hi,

I have a treelistview which has n-numbers of child node. I want to search in that. Please help me.

Thanks & regards
Vijay Kumar

General Discussions

asked on 11 Jul 2011

4 answers

168 views

How to insert record into radgrid on the fly

Hi

I want to add record on fly by radgrid.

I have some textbox and two buttons (Insert and Submit) to add information in radgrid.

My senario is:
When user enter her/his info into textbox and click on the insert button, value of textbox must be inserted into radgrid at client side without save them into database. In the final user click on the submit button, then all rows in radgrid save in database.

I see this and this demo online, but in both of them using webservice and bind grid from database.
How I can do my senario?

Thank's

GridView

answered on 11 Jul 2011

3 answers

186 views

GridViewRowInfo VisualElement

I am new to Telerik so please forgive the beginner question. I have searched the forums for a possible answer but haven't found anything that specifically answers my question.

I am upgrading the Telerik RadControls for Winforms from Q1 2010 SP2 to Q2 2010. There were obviously some things that broke in the code and I think I have fixed them all, but I cannot seem to find a solution for one. The error is the following:

Telerik.WinControls.UI.GridViewRowInfo does not contain a definition for VisualElement and no extension method...blah...

The line of code looks like this:

if (row.Cells["Status"].Value.Equals("complete"))

row.VisualElement.ForeColor = Color.Gray;

How do I address this? What changed between Q1 2010 SP2 and Q2 2010?

Thank you in Advance for any insight. It is greatly appreciated.

Scott

GridView

answered on 11 Jul 2011

1 answer

109 views

Incorrect auto row height

I have AutoSizeRows=true and grouping enabled. After the DataSource is updated the rows don't seem to readjust their height.
I'm running Telerik RadControls v2010.2.10.713
Is there a way for the grid to recalculate row heights?

GridView

answered on 10 Jul 2011

0 answers

97 views

IMPORTANT INFORMATION ON USING THE TELERIK FORUMS

The goal of the Telerik Forum is to provide all registered users with a way to find answers to their questions before officially contacting Telerik. In case you need a faster and precise response, please start a new support ticket as it gets higher priority than Forum posts.

A post in the Forums doesn't guarantee you a response from the Telerik support team although 95% of all posts are eventually addressed. Additionally, a post is not assigned a response time as with the support ticketing system.

The Forums can be used to:

Discuss coding techniques with fellow Telerik users
Share your experience on the Telerik suite of controls
Ask general questions, not related to Telerik controls
Contact Telerik with a question
Contact Telerik MVPs
Help other users

Telerik strives to constantly improve its support services but it is essential to have full information to supply precise replies. If we do not have enough details we will not be able to properly address your inquiry and we will ask for further info. The extra loop is sure to slow down the time it takes to resolve your problem, and subsequently the further development of your project.

It is vital that you follow these guidelines in order to receive an accurate response:

GUIDELINES TO USING THE SUPPORT FORUM

You should have a valid Telerik account to post in the Forum. Anonymous names will not be allowed and such posts will not be answered or will be deleted.
Use the relevant product forum to post your questions and comments. If your question relates to two or more Telerik products, you can post it in the General Discussions section.
Choose a descriptive name for your thread in order to allow the other users looking for similar information to find it more easy.
Try to keep discussing only one subject per thread. If you have information/inquery unrelated to the initial topic of a thread, please open a new thread.
Describe your question in detail. Make sure to include the following information:

Step by step instructions on how to reproduce the problem
Code snippets (file attachments other than .gif, .jpg, .jpeg, and .png are not supported). If you think that Telerik needs to review your project and/or files, start a new support ticket.
Stack trace, if applicable
Used programming language (VB.NET or C#)
Your experience with .Net and RadControls

State the software you are using, including:

OS version and applied service packs
Regional and language settings, if different from En-US
.NET version (.NET2, .NET4, etc)
Exact version of the Telerik product

Telerik reserves the right to use, reproduce and share the material you post within the forums.
Telerik reserves the right to not participate in all posts.
Telerik reserves the right to remove any messages that do not comply with these terms.

ENJOY!!!

Best Wishes,
The Telerik team

PropertyGrid

asked on 10 Jul 2011

1 answer

267 views

Hide expand/collapse button for level 0 nodes

Does anyone know if it Is it possible to hide the expand/collapse button at all? I am trying to preserve as much horizontal space as possible and also fulfill a requirement that the first level of nodes is always expanded.

I've come across a solution for the ASP.NET AJAX suite but nothing for the WinForms (http://www.telerik.com/community/forums/aspnet-ajax/treeview/drop-expand-collapse-image-from-root-node.aspx#854721)

Thanks,
Adam

Treeview

answered on 08 Jul 2011
