Specify column names for child relation grid

[Daniil]

Hello,

How is it possible to specify columns for child table?

I don't want columns for hierarchical grid to be auto generated.

I'm reading http://www.telerik.com/help/wpf/gridview-basic-hierarchies.html but it does not seam to be there

Thank You

[Vlad]

Hi,

 You can use HierarchyChildTemplate similar to this demo to define your child tables.

All the best,
Vlad
the Telerik team

[Daniil]

I'm sorry, but I still don't get it. Could you please make a WPF example?

[Maya]

Hello Daniil,

I am sending you a sample project demonstrating how to set the columns in a child grid. The things you need to do for defining them is to add a ChildTableDefinition:

<telerik:RadGridView.ChildTableDefinitions>
     <telerik:GridViewTableDefinition />
</telerik:RadGridView.ChildTableDefinitions>

And then to create the HierarchyChildTemplate:

<telerik:RadGridView.HierarchyChildTemplate>
     <DataTemplate>
       <telerik:RadGridView Name="playersGrid"
                             ItemsSource="{Binding Players}"
                             AutoGenerateColumns="False">
       <telerik:RadGridView.Columns>
        <telerik:GridViewDataColumn UniqueName="NameColumn" DataMemberBinding="{Binding Name}"/>
        <telerik:GridViewDataColumn UniqueName="NumberColumn" DataMemberBinding="{Binding Number}"/>


      </telerik:RadGridView.Columns>
       </telerik:RadGridView>
     </DataTemplate>
</telerik:RadGridView.HierarchyChildTemplate>

The corresponding demo example for RadControls for WPF could be found here.

Regards,
Maya
the Telerik team

[Tarik]

Could you please show an example that access the grid children grids via code?

[Vlad]

Hi,

 You can use DataLoading/AutoGeneratingColumn events to assess auto-generated child grid columns

Greetings,
Vlad
the Telerik team
