RadMenuItem doesnot show seperator

[Sanket Singhvi]

Hi,

I have declared the following template in my Resource File :
<DataTemplate x:Key="MenuItem">
<telerik:RadMenuItem
                Margin="0"
                Padding="0"
                Header="{Binding Header}"
IsCheckable="{Binding IsCheckable}"
IsChecked="{Binding IsChecked, Mode=TwoWay}"
IsSeparator="{Binding IsSeparator}"
IsEnabled="{Binding IsEnabled}"
Command="{Binding MenuCommand}"
/>
        </DataTemplate>

<HierarchicalDataTemplate
x:Key="MenuItemTemplate"
ItemsSource="{Binding MenuItems}"
ItemTemplate="{StaticResource MenuItem}">
        <telerik:RadMenuItem Header="{Binding Header}"
                             IsCheckable="{Binding IsCheckable}"
                             IsChecked="{Binding IsChecked, Mode=TwoWay}"
                             IsSeparator="{Binding IsSeparator}"
                             Margin="0"
                             Padding="0"
                             IsEnabled="{Binding IsEnabled}"
                             Command="{Binding MenuCommand}"/>
</HierarchicalDataTemplate>

And I am using the above resources in RadGridView as below:
 <telerik:RadContextMenu.ContextMenu>
                <telerik:RadContextMenu x:Name="_gridContextMenu"
Opened="_gridContextMenu_Opened"
ItemTemplate="{StaticResource MenuItemTemplate}"
ItemsSource="{Binding ContextMenu}">
                </telerik:RadContextMenu>
            </telerik:RadContextMenu.ContextMenu>
ContextMenu is a ObservableCollection<ContextMenuController>.

Now Everything seems to be working except that IsSeperator doesn't work. When IsSeperator is true for a ContextMenuController it still shows as an Item occupied more space than it is supposed to be.

Look at the attached image and see how it shows the RadMenuItem which is nothing but a seperator.

Regards
Sanket

[Pana]

Hi Sanket Singhvi,

HierarchicalDataTemplate is a DataTemplate and not a ControlTemplate. I have no idea why are you puttin a
<telerik:RadMenuItem
inside the DataTemplates. It means that the header of the RadMenuItem will actually be another RadMenuItem. Instead you can use a Style and Bindings inside that Style. For example you can have something like:

<Style x:Key="MenuItemBaseStyle" TargetType="telerik:RadMenuItem">
  <Setter Property="Header" Value="{Binding Content}" />
  <Setter Property="IsSeparator" Value="{Binding IsSeparator}" />
  <Setter Property="ItemsSource" Value="{Binding}" />
</Style>

And set the style as ItemContainerStyle on RadMenu or RadMenuItem.

In the upcomming 2011.Q1 we have prepared a Tic-Tac-Toe game MVVM example that will show how you can bind Commands, Icons, Headers, ItemsSource etc. on RadMenuItem.

All the best,
Pana
the Telerik team
