Raddiagram

1 Answer 22 Views
Diagram, DiagramRibbonBar, DiagramToolBox
Moe
Top achievements
Rank 1
Iron
Veteran
Iron
Moe asked on 20 Oct 2021, 03:30 AM

Hi ,

I want to know Raddiagram shape and color and note move. My program will show below attach (Raddigarm)and user can change shape and color and note move. I would like to know how to do.

What I want in below attach file(want to change.PNG).

My question is below.

Is it possible for users to do the following once the diagram has been generated in the program:
  1. Move the nodes around
  2. Change the shape of nodes
  3. Add/change the color to the nodes
  4. Add comment nodes





Please reply to me asap.



Thanks,

Moe





1 Answer, 1 is accepted

Sort by
0
Dess | Tech Support Engineer, Principal
Telerik team
answered on 21 Oct 2021, 10:26 AM
Hello, Moe,

RadDiagram allows moving the shapes. It is just necessary to click the shape to select it and then drag the shape to the desired location.

RadDiagram offers SettingsPane control to the users to examine and modify the settings of the diagramming items at run-time: https://docs.telerik.com/devtools/winforms/controls/diagram/settings-pane

I would recommend you to have a look at our Demo application >> Diagram >> First Look example which is quite useful for getting started experience. Try to select a shape and use the RadpropertyGrid on the right side to change the Shape. To access the Live Demo simply click on the Windows Start button and type WinForms Demo. If you are not able to find the Live Demos using that approach you can also download it directly from here.

Comment nodes are not available out of the box. But I believe that a possible solution is to use a container shape which allows you to specify description inside the header: https://docs.telerik.com/devtools/winforms/controls/diagram/diagram-items/containershapes

I hope this information helps. If you need any further assistance please don't hesitate to contact me.

Regards,
Dess | Tech Support Engineer, Principal
Progress Telerik
