How to set column header in multi-column reports

[Sudkanung]

I using multi-column in telerik reporting but result not same as my imaging.
I have 1 group (group by username)
This is result form multi-column reports

Mary Jane              4          2.4         9          2.5
No.       KG.            5          2.6
1          2.5             6          2.5
2          2.8             7          2.3
3          2.3             8          2.7

But I want report look like this.

Mary Jane
No.       KG.            No.       KG.        No.       KG.
1          2.5             4          2.4         7          2.3
2          2.8             5          2.6         8          2.7
3          2.3             6          2.5         9          2.5

What should I do?

[Hadib Ahmabi]

If you want 3 columns, filled across-then-down:
1  2  3
4  5  6
7  8  9
then you can do that with a crosstab. Look at this thread: http://www.telerik.com/community/forums/reporting/telerik-reporting/how-to-show-detail-data-to-across-then-down.aspx

If you want to have 3 columns evenly filled down-then-across:
1   4   7
2   5   8
3   6   9
then you cannot achieve that unless you make sure that only 3 items will fit in the height of the page and use the built-in multi-column functionality.

[Sudkanung]

No I want report down then across but I want heading of column show in every column.
And multi-column report can't using with report viewer but I want to show data before print how I can do?(Now I sending data to printer directly.)

[Steve]

Hi Sudkanung,

In multi-column report layout, the Report header and group header sections span the width of the column, so if you have a group that continues on several logical pages/columns, the group header would be displayed only on the first column.

Greetings,
Steve
the Telerik team

[Sudkanung]

Now I set 2 group first group is group by user and set PrintOnEveryPage=true
and second group is no grouping and set PrintOnEveryPage=true
result is like this :
Mary Jane              Mary Jane          Mary Jane
No.       KG.            No.       KG.        No.       KG.
1          2.5             4          2.4         7          2.3
2          2.8             5          2.6         8          2.7
3          2.3             6          2.5         9          2.5

and if I change PrintOnEveryPage=false for first group(second group is PrintOnEveryPage=true)
then result is change like this :
Mary Jane              No.       KG.        No.       KG.
No.       KG.            4          2.4         8          2.7
1          2.5             5          2.6         9          2.5
2          2.8             6          2.5
3          2.3             7          2.3

[Steve]

Hi Sudkanung,

The behavior you describe is by design and expected as per our previous reply. Since Mary Jane is a group header, it cannot span over the other columns.

Kind regards,
Steve
the Telerik team
