Custom Pin

4 posts, 1 answers
  1. Thomas
    Thomas avatar
    17 posts
    Member since:
    Oct 2012

    Posted 12 Sep Link to this post

    Hi,

    I would like to be able to create a custom pin with a Usercontrol on it. Is this possible and in addition could you suggest a way to do it? How should the control be hosted?

    class MyCustomPin : MapVisualElement
    {

    }

    Regards,

    Thomas

  2. Hristo
    Admin
    Hristo avatar
    1015 posts

    Posted 12 Sep Link to this post

    Hi Thomas,

    Thank you for writing.

    User controls cannot be hosted in the MapPin object. Can you please share more details about your actual setup and we will suggest the best way to accomplish your task?

    I hope this helps. Looking forward to your reply.

    Regards,
    Hristo
    Progress Telerik
    Try our brand new, jQuery-free Angular 2 components built from ground-up which deliver the business app essential building blocks - a grid component, data visualization (charts) and form elements.
  3. Thomas
    Thomas avatar
    17 posts
    Member since:
    Oct 2012

    Posted 13 Sep Link to this post

    Hi Hristo,

    A little more detail:

    I'm receiving events from from different objects in near to real time. The objects are placed on the map and I would like to show different performance stats for each of the objects in a usercontrol on the map. I've attached a mockup of the control just to give you an idea.

    I guess something like this could be done, but I dont know how it will perform... and it would be nicer just to update the UC each time a new evet is recieved...

    MarkerDetailControl mdc = new MarkerDetailControl();

    Bitmap b = new Bitmap(mdc.Width, mdc.Height);

    mdc.DrawToBitmap(b, new Rectangle(0, 0, b.Width, b.Height));

    //and then

    MyCustomMarker.Image = b;

    //Add to layer on so on...

  4. Answer
    Hristo
    Admin
    Hristo avatar
    1015 posts

    Posted 13 Sep Link to this post

    Hello Thomas,

    Thank you for writing.

    As I understand creating an image out of your user control and adding it to the chart would be suitable for your actual project. This can be accomplished by creating a custom pin element with an Image property. The logic for painting the actual image can be implemented in the Paint method override:
    public class CustomMapPin : MapPin
    {
        private Image image;
        private PointL pixelLocation;
        private RectangleL drawRect;

        public CustomMapPin(PointG location)
            : base(location)
        {
        }

        public Image Image
        {
            get
            {
                return image;
            }
            set
            {
                this.image = value;
            }
        }

        public override bool IsInViewport
        {
            get { return true; }
        }

        public override void Paint(IGraphics graphics, IMapViewport viewport)
        {
            if (this.Image == null)
            {
                base.Paint(graphics, viewport);
                return;
            }

            object state = graphics.SaveState();
            graphics.TranslateTransform(drawRect.X, drawRect.Y);
            Graphics g = graphics.UnderlayGraphics as Graphics;

            long mapSize = MapTileSystemHelper.MapSize(viewport.ZoomLevel);

            for (int i = -1; i <= viewport.NumberOfWraparounds; i++)
            {
                g.DrawImage(this.Image, new RectangleF(i * mapSize, 0, this.Image.Size.Width, this.Image.Size.Height));
            }

            graphics.RestoreState(state);
        }

        public override void ViewportChanged(IMapViewport viewport, ViewportChangeAction action)
        {
            if (this.Image == null)
            {
                base.ViewportChanged(viewport, action);
                return;
            }

            long mapSize = MapTileSystemHelper.MapSize(viewport.ZoomLevel);

            if ((action & ViewportChangeAction.Zoom) != 0)
            {
                this.pixelLocation = MapTileSystemHelper.LatLongToPixelXY(this.Location, viewport.ZoomLevel);
            }

            if ((action & ViewportChangeAction.Pan) != 0)
            {
                this.drawRect = new RectangleL(pixelLocation.X - this.Image.Size.Width / 2, pixelLocation.Y - this.Image.Size.Height, this.Image.Size.Width, this.Image.Size.Height);
            }
        }

        public override bool HitTest(PointG pointG, PointL pointL, IMapViewport viewport)
        {
            if (this.Image == null)
            {
                return base.HitTest(pointG, pointL, viewport);
            }

            return this.drawRect.Contains(pointL);
        }
    }

    You can use the custom pins just as the base object it extends:
    this.radMap1.Layers.Add(new MapLayer("L1"));
    CustomMapPin marker = new CustomMapPin(new PointG(36, -110));
    marker.Size = new Size(50, 50);
    marker.Image = Properties.Resources.bell;
    this.radMap1.Layers["L1"].Add(marker);

    I hope this helps. Should you have further questions please do not hesitate to write back.

    Regards,
    Hristo
    Progress Telerik
