How to Display Hierarchical Data

RadPanelBarItem inherits from HeaderedItemsControl therefore it can display hierarchical data, e.g. collections that contain other collections.

The HierarchicalDataTemplate class is designed to be used with HeaderedItemsControl types to display such data. There should be virtually no differences between the usage of HierarchicalDataTemplate in RadPanelBar and other controls.

The following example demonstrates how to create a hierarchical data source and bind a RadPanelBar to it, using a HierarchicalDataTemplate. The ItemsSource property of the HierarchicalDataTemplate specifies the binding that has to be applied to the ItemsSource property of each item. The DataTemplate property specifies the template that has to be applied on each item, while the ItemTemplate is the template applied on its child items.

1. Create a new class and name it MyViewModel:

   C#

   	public class MyViewModel
   	{
   	    public MyViewModel()
   	    {
   	        this.RelatedItems = new ObservableCollection<object>();
   	    }
   	    public string Title { get; set; }
   	    public DateTime DateCreated { get; set; }
   	    public double Price { get; set; }
   	    public IList<object> RelatedItems { get; set; }
   	}

   VB.NET

   	Public Class MyViewModel
   	    Public Sub New()
   	        Me.RelatedItems = New ObservableCollection(Of Object)()
   	    End Sub
   	    Public Property Title() As String
   	        Get
   	            Return _Title
   	        End Get
   	        Set(ByVal value As String)
   	            _Title = value
   	        End Set
   	    End Property
   	    Private _Title As String
   	    Public Property DateCreated() As DateTime
   	        Get
   	            Return _DateCreated
   	        End Get
   	        Set(ByVal value As DateTime)
   	            _DateCreated = value
   	        End Set
   	    End Property
   	    Private _DateCreated As DateTime
   	    Public Property Price() As Double
   	        Get
   	            Return _Price
   	        End Get
   	        Set(ByVal value As Double)
   	            _Price = value
   	        End Set
   	    End Property
   	    Private _Price As Double
   	    Public Property RelatedItems() As IList(Of Object)
   	        Get
   	            Return _RelatedItems
   	        End Get
   	        Set(ByVal value As IList(Of Object))
   	            _RelatedItems = value
   	        End Set
   	    End Property
   	    Private _RelatedItems As IList(Of Object)
   	End Class

   The class has four properties:

   • Property Price which is of type double.

   • Property CreatedOn which is of type DateTime.

   • Property Title which is of type string.

   • Property RelatedItems which is a collection of objects. These are the child items. Add a static method to the class which aims to create some mock-up data:

     C#

     	public static IList<object> GenerateItems()
     	{
     	    var result = new ObservableCollection<object>();
     	    foreach (var num in Enumerable.Range(1, 5))
     	    {
     	        var item = new MyViewModel();
     	        item.DateCreated = DateTime.Today.AddDays(-num % 15);
     	        item.Price = num * 100 + Convert.ToDouble(num) / 100;
     	        item.Title = String.Format("Item {0}", num);
     	        for (int i = 0; i < 5; i++)
     	        {
     	            var child = new MyViewModel();
     	            child.DateCreated = DateTime.Today.AddDays(-num % 5 - i);
     	            child.Price = num * 100 + Convert.ToDouble(num + i) / 100;
     	            child.Title = String.Format("Item {0}.{1}", num, i);
     	            item.RelatedItems.Add(child);
     	        }
     	        result.Add(item);
     	    }
     	    return result;
     	}

     VB.NET

     	Public Shared Function GenerateItems() As IList(Of Object)
     	    Dim result = New ObservableCollection(Of Object)()
     	    For Each num In Enumerable.Range(1, 5)
     	        Dim item = New MyViewModel()
     	        item.DateCreated = DateTime.Today.AddDays(-num Mod 15)
     	        item.Price = num * 100 + Convert.ToDouble(num) / 100
     	        item.Title = [String].Format("Item {0}", num)
     	        For i As Integer = 0 To 4
     	            Dim child = New MyViewModel()
     	            child.DateCreated = DateTime.Today.AddDays(-num Mod 5 - i)
     	            child.Price = num * 100 + Convert.ToDouble(num + i) / 100
     	            child.Title = [String].Format("Item {0}.{1}", num, i)
     	            item.RelatedItems.Add(child)
     	        Next
     	        result.Add(item)
     	    Next
     	    Return result
     	End Function

2. Declare a HierarchicalDataTemplate

   XAML

   	<Window.Resources>
   	    <DataTemplate x:Key="PanelBarItemTemplate">
   	        <StackPanel>
   	            <TextBlock Text="{Binding Title}"/>
   	            <TextBlock Text="{Binding DateCreated}"/>
   	            <TextBlock Text="{Binding Price}"/>
   	        </StackPanel>
   	    </DataTemplate>

   	    <HierarchicalDataTemplate x:Key="PanelBarHeaderTemplate"
   	               ItemsSource="{Binding RelatedItems}"
   	               ItemTemplate="{StaticResource PanelBarItemTemplate}">
   	        <TextBlock Text="{Binding Title}" />
   	    </HierarchicalDataTemplate>
   	</Window.Resources>

3. Define the RadPanelBar and set its ItemTemplate property

   XAML

   	<telerik:RadPanelBar x:Name="radPanelBar" Width="200"
   	               HorizontalAlignment="Center" VerticalAlignment="Top"
   	               ItemTemplate="{StaticResource PanelBarHeaderTemplate}">
   	</telerik:RadPanelBar>

4. Set the ItemsSource property of the RadPanelBar

   C#

   	this.radPanelBar.ItemsSource = MyViewModel.GenerateItems();

   VB.NET

   	Me.radPanelBar.ItemsSource = MyViewModel.GenerateItems()
