Questions on UI for WPF Forum

2 answers

262 views

I have a gridview and one of the columns needs a popup window for selecting the appropriate value because the list of available choices is over 200 records.

I've created a CellEditTemplate with a button bound to a command on my viewmodel, but I'm not sure this is the best approach. Because I have to bind the selectedItem of the grid to a property, so that when I show the popup window, it can alter the appropriate property of the selectedItem.

When I click on the "insert row", the new row isn't automatically the selected row. How do I get to to automatically be the selected row, so that my popup window has something to change? Or is there a better way to present the choices to the user besides a popup window?

GridView

answered on 09 Jun 2011

2 answers

119 views

[Solved] Trouble binding combobox from cellEditTemplate

I have gridView defined inside a DataTemplate for a TabControl.

Within this GridView I have a column that I need to provide a list of choices from over 200 records with multiple columns, that needs to be filterable, so I thought either a button that brings up a popup window, or using a combobox with a gridview. Either solution requires me to bind to properties on my viewmodel for the list of 200+ records.

Controls inside the DataTemplate defined for the TabControl are bound to the VM by setting a name on the UserControl and binding to {DataContext.Property, ElementName=MyUserControl}. This works, until I get to the DataTemplate that is defining the CellEditTemplate. I thought I could use the same method for declaring my binding, but it just isn't working.

Is there a heirarchy limit I'm reaching, but having a DataTemplate defined inside of a DataTemplate?

GridView

answered on 09 Jun 2011

1 answer

138 views

WPF Gridview with Non Case Sensitive Filtering

Hi

in my project,wpf radgrid Filter case sensitive is working fine.
But the same items with Different Case come as Different CheckBoxes in the Filter Select Option

eg:
ABC and abc comes as different filter select options. but in filtering textbox,if we give the value as abc it returns both abc and ABC
i want to set this as one in filter checkbox group also.
Is this possible

GridView

answered on 09 Jun 2011

1 answer

156 views

Gridview (Scroll Bar Problem)

Hi

I'm having a weird issue with the grid view column if you I'm using Width="*" i get a really long horizontal scroll bar.

Code:
<ScrollViewer HorizontalScrollBarVisibility="Auto" BorderThickness="0" >
<telerik:RadGridView Grid.Row="1" ScrollMode="Deferred"     RowIndicatorVisibility="Collapsed"   CanUserFreezeColumns="False" ShowGroupPanel="False" AutoGenerateColumns="False" >
                    <telerik:RadGridView.Columns>
                    <telerik:GridViewDataColumn Header="Name" Width="200" />
                    <telerik:GridViewDataColumn Header="Phone" Width="*" />
                    </telerik:RadGridView.Columns>
                </telerik:RadGridView>
</ScrollViewer>

Thanks

GridView

answered on 09 Jun 2011

6 answers

547 views

download themes

Hello,

I am looking for themes for each component Telerik.

I want the user to choose its theme.

I can not find the files corresponding to these themes.

Could you help me?

Best regards

General Discussions

answered on 09 Jun 2011

2 answers

374 views

[Solved] Syncing selection between two gridviews

I have two gridviews that are bound to the same QueryableCollectionView. I need the selected items of the two gridviews to be the same at all times.

There seem to be some built-in funtionalty like this. If a select a row in GridView1 the same row will be selected in GridView2. But if I select multiple rows in GridView1, only the first selected of those rows will be selected in GridView2.

How can I sync the selection between the gridviews?

I used to have the gridviews bound to the same RadObservableCollection. Then I synced the selection manually on the SelectionChanged-event on GridView1 like this:

private void GridView1_SelectionChanged(object sender, SelectionChangeEventArgs e)

{

GridView2.SelectedItems.Clear();

foreach (var item in GridView1.SelectedItems)

{

GridView2.SelectedItems.Add(item);

}

That worked fine, but I doesn't work now when I've switched to using QueryableCollectionView. When I clear the selected items of GridView2 the selected items of GridView1 will also be cleared. So it seems to be some built-in sync here (I'm guessing the QueryableCollectionView keeps track of selected items), but not like I need it to work

GridView

answered on 09 Jun 2011

5 answers

138 views

[Solved] Title in front of PlotArea

Hi,

I'am trying to position the Chart Titles into the ChartPlotArea.
That's all well and good, but if i'm setting the Background Color of the PlotArea differently than the Background of the ChartArea the PlotArea hides the ChartTitle.
Setting a ZIndex for the PlotArea and the Title dosn't work.
Picture without setting a special background color
Picture with setting a special background color

Here is my Code:

<UserControl.Resources>

<Style x:Key="XTitleStyle" TargetType="{x:Type telerik:AxisTitle}">

<Setter Property="Margin" Value="0,-32,1,0"/>

<Setter Property="HorizontalAlignment" Value="Right"/>

<Setter Property="Panel.ZIndex" Value="10"/>

</Style>

<Style x:Key="Y1TitleStyle" TargetType="{x:Type telerik:AxisTitle}">

<Setter Property="VerticalAlignment" Value="Top"/>

<Setter Property="RenderTransform">

<Setter.Value>

<TransformGroup>

<TranslateTransform X="-5" Y="-80"/>

<RotateTransform Angle="90"/>

</TransformGroup>

</Setter.Value>

</Setter>

</Style>

<Style TargetType="{x:Type telerik:MarkedZone}">

<Setter Property="Panel.ZIndex" Value="-1"/>

</Style>

</UserControl.Resources>

<Grid Width="Auto" Height="Auto">

<telerik:RadChart HorizontalAlignment="Stretch" Margin="10,5,10,5" Name="radChart1" VerticalAlignment="Stretch" BorderThickness="0" Background="{DynamicResource backgroundTabControl}">

<telerik:RadChart.SeriesMappings>

<telerik:SeriesMapping ItemsSource="{Binding Series1, RelativeSource={RelativeSource FindAncestor, AncestorType={x:Type UserControl}}}" >

<telerik:SeriesMapping.SeriesDefinition>

<telerik:LineSeriesDefinition ShowItemLabels="False" ShowPointMarks="False">

<telerik:LineSeriesDefinition.Appearance>

<telerik:SeriesAppearanceSettings StrokeThickness="1.5"/>

</telerik:LineSeriesDefinition.Appearance>

</telerik:LineSeriesDefinition>

</telerik:SeriesMapping.SeriesDefinition>

<telerik:SeriesMapping.ItemMappings>

<telerik:ItemMapping FieldName="Y" DataPointMember="YValue"/>

</telerik:SeriesMapping.ItemMappings>

</telerik:SeriesMapping>

</telerik:RadChart.SeriesMappings>

<telerik:RadChart.DefaultView>

<telerik:ChartDefaultView ChartLegend="{x:Null}">

<telerik:ChartDefaultView.ChartArea>

<telerik:ChartArea EnableAnimations="False" EnableStripLinesAnimation="False" SnapsToDevicePixels="True">

<telerik:ChartArea.PlotAreaStyle>

<Style TargetType="{x:Type telerik:ClipPanel}">

<Setter Property="Background" Value="White"/>

<Setter Property="Panel.ZIndex" Value="-1"/>

</Style>

</telerik:ChartArea.PlotAreaStyle>

<telerik:ChartArea.Annotations>

<telerik:MarkedZone Background="White" />

</telerik:ChartArea.Annotations>

<telerik:ChartArea.AxisX>

<telerik:AxisX AutoRange="False" MajorGridLinesVisibility="Visible" MajorTicksVisibility="Visible" Title="test">

<telerik:AxisX.AxisStyles>

<telerik:AxisStyles TitleStyle="{StaticResource XTitleStyle}" />

</telerik:AxisX.AxisStyles>

</telerik:AxisX>

</telerik:ChartArea.AxisX>

<telerik:ChartArea.AxisY>

<telerik:AxisY AutoRange="False" MajorGridLinesVisibility="Visible" MinorGridLinesVisibility="Collapsed" Title="test" PlotAreaAxisVisibility="Visible" StripLinesVisibility="Collapsed">

<telerik:AxisY.AxisStyles>

<telerik:AxisStyles TitleStyle="{StaticResource Y1TitleStyle}"/>

</telerik:AxisY.AxisStyles>

</telerik:AxisY>

</telerik:ChartArea.AxisY>

</telerik:ChartArea>

</telerik:ChartDefaultView.ChartArea>

</telerik:ChartDefaultView>

</telerik:RadChart.DefaultView>

</telerik:RadChart>

</Grid>

I would like to display the AxisTitle above the PlotArea and above any MarkedZones. Is there any solution?

Best regards
Dominik

Chart

answered on 09 Jun 2011

1 answer

89 views

[Solved] Displaying Sparklines in same order as underlying data

Hello,

I am displaying a couple of sparkline graphs. The underlying data is a List<KeyValuePair<Int32, Int32>>. The sparkline seems to be automatically sorting and displaying the data by the key. (I'm basically displaying a count by month, the left most point needs to be current month)

Is there any way to display the data how it's layed out in the collection itself?

Sparkline

answered on 09 Jun 2011

1 answer

155 views

2d range bar as stacked bar horizontal

Hi,

I have a quick question can i use 2d range bar as stacked bar (Horizontal). if yes can you please send the sample project.

thanks
sarag.

Chart

answered on 09 Jun 2011

0 answers

103 views

Print all the columns in the same page when we do Print Preview.

Hello Team,

Here we have a Telerik gridview and around 25 no. of columns is there. The problem is when we view Print Preview the output appears but not exactly what we expected. The 1st page take few columns and the rest goes to 2nd page and rest one goes to 3rd page but if we have 4 rows in a grid along with 25 columns, then the result must appear on the same page after the first best fit columns on the same page.

Please see below the logic of Print Preview-



public

static void PrintPreview(GridViewDataControl source, bool modal)

{

var window = new Window { Title = "Print Preview" };

var dialog = new PrintDialog();

var document = source.ToPrintFriendly().ToFixedDocument(dialog);

var documentViewer = new DocumentViewer

{

Document = document

};

window.Content = documentViewer;

if (modal)

window.ShowDialog();

else

window.Show();

}

I have tried the given link in the forum and customise the logic but no luck to achieved what we expected as a output-
Here's link- http://www.telerik.com/community/code-library/wpf/gridview/radgridview-print-and-print-preview.aspx

Kindly help me out to over come this issue.

Regards,
Naren

GridView

asked on 09 Jun 2011
