Questions on UI for WPF Forum

1 answer

129 views

I have an assembly that can either run as a stand-alone executable or being hosted in a browser as xbap. The application opens a new RadRibbonWindow which contains a RadRibbonView.

This works fine when the assembly runs stand-alone. However, when the assembly runs as xbap, the RadRibbonWindow overlaps all window buttons (close/minimize/maximize). Is there a solution to this other than hosting the RadRibbonView in a standard WPF-window instead of RadRibbonWindow?

Regards,
Michael

RibbonView and RibbonWindow

answered on 27 Jun 2012

1 answer

88 views

remove little x from appointments

Hello,

I would like to create appointments without the little x in the upper right hand corner of the appointment.

How can this be done?

Thanks in advance.

ScheduleView

answered on 27 Jun 2012

1 answer

190 views

Persist settings for multiple GridViews in one file

I have an app with quite a few different GridViews all of which need to have their settings persisted. Currently, I am creating a file for each GridView to persist the settings between sessions. Is there a way to consolidate this so that more than one gridview can share a settings file? Here is the current code I have for doing persistence:

/// <summary>

/// Interaction logic for BillingActivityView.xaml

/// </summary>

public partial class BillingActivityView

{

private static readonly string _appDataPath = Environment.GetFolderPath(Environment.SpecialFolder.ApplicationData);

private static readonly string _bambooSettingsPath = Path.Combine(_appDataPath, @"Bamboo\Settings");

private static readonly string _testsGridSettingsFilePath = Path.Combine(_bambooSettingsPath, @"TestsGridSettings.bin");

private static readonly string _oldBillClassesGridSettingsFilePath = Path.Combine(_bambooSettingsPath, @"OldBillClassesGridSettings.bin");

private static readonly string _insuranceStatusGridSettingsFilePath = Path.Combine(_bambooSettingsPath, @"InsuranceStatusGridSettings.bin");

/// <summary>

/// Initializes a new instance of the <see cref="DocumentImageView"/> class.

/// </summary>

public BillingActivityView()

{

InitializeComponent();

ServiceProvider.RegisterPersistenceProvider<ICustomPropertyProvider>(typeof(RadGridView), new GridViewCustomPropertyProvider());

}

private void TestsGridView_Initialized(object sender, EventArgs e)

{

LoadGridSettings(TestsGridView, _testsGridSettingsFilePath);

}

private void OldBillClassesGridView_Initialized(object sender, EventArgs e)

{

LoadGridSettings(OldBillClassesGridView, _oldBillClassesGridSettingsFilePath);

}

private void InsuranceStatusGridView_Initialized(object sender, EventArgs e)

{

LoadGridSettings(InsuranceStatusGridView, _insuranceStatusGridSettingsFilePath);

}

public void LoadGridSettings(RadGridView gridView, string settingsPath)

{

var manager = new PersistenceManager();

if (!Directory.Exists(_bambooSettingsPath))

{

Directory.CreateDirectory(_bambooSettingsPath);

}

// Load settings if there is something to load

if (File.Exists(settingsPath))

{

try

{

var fileStream = File.OpenRead(settingsPath);

manager.Load(gridView, fileStream);

fileStream.Close();

}

catch (Exception ex)

{

System.Diagnostics.Debug.WriteLine(ex.Message, "BILLINGACTIVITYVIEW");

}

public void PersistAllGridSettings()

{

PersistGridSettings(TestsGridView, _testsGridSettingsFilePath);

PersistGridSettings(OldBillClassesGridView, _oldBillClassesGridSettingsFilePath);

PersistGridSettings(InsuranceStatusGridView, _insuranceStatusGridSettingsFilePath);

}

public void PersistGridSettings(RadGridView gridView, string settingsPath)

{

var manager = new PersistenceManager();

var stream = manager.Save(gridView);

using (var fileStream = File.Create(settingsPath))

{

stream.CopyTo(fileStream);

}

PersistenceFramework

answered on 26 Jun 2012

1 answer

117 views

Header Text dissapears when Style changes in code

Hello, I have a RadTileView where I want to change the header background color when the tile gets minimized.
When I apply the new style the header text disappears, this doesn't happen when the new style is the same as the old one

(I know this example only works when all items are minimized, not when you maximize another item, but this is just for test purposes)

C#:

private void RadTileViewItem_MouseLeftButtonUp(object sender, MouseButtonEventArgs e)

{

RadTileViewItem item = (sender as RadTileViewItem);

if (item.TileState == TileViewItemState.Maximized)

{

item.TileState = TileViewItemState.Minimized;

item.HeaderStyle = (Style)FindResource("TileViewItemHeaderStyle4");

}

else

{

item.TileState = TileViewItemState.Maximized;

}

XAML:

<UserControl xmlns:my="clr-namespace:WpfApplication1" x:Class="WpfApplication1.NodeView"

xmlns="http://schemas.microsoft.com/winfx/2006/xaml/presentation"

xmlns:x="http://schemas.microsoft.com/winfx/2006/xaml"

xmlns:mc="http://schemas.openxmlformats.org/markup-compatibility/2006"

xmlns:d="http://schemas.microsoft.com/expression/blend/2008"

xmlns:telerik="http://schemas.telerik.com/2008/xaml/presentation"

xmlns:TileView="clr-namespace:Telerik.Windows.Controls.TileView;assembly=Telerik.Windows.Controls.Navigation" >

<UserControl.Resources>

<Style x:Key="TileViewItemHeaderStyle1" TargetType="{x:Type TileView:TileViewItemHeader}">

<Setter Property="Background" Value="red">

</Setter>

</Style>

<Style x:Key="TileViewItemHeaderStyle2" TargetType="{x:Type TileView:TileViewItemHeader}">

<Setter Property="Background" Value="Orange">

</Setter>

</Style>

<Style x:Key="TileViewItemHeaderStyle3" TargetType="{x:Type TileView:TileViewItemHeader}">

<Setter Property="Background" Value="Green">

</Setter>

</Style>

<Style x:Key="TileViewItemHeaderStyle4" TargetType="{x:Type TileView:TileViewItemHeader}">

<Setter Property="Background" Value="Blue">

</Setter>

</Style>

</UserControl.Resources>

<Grid>

<telerik:RadTileView Name="radTileView1" MinimizedColumnWidth="300" MinimizedRowHeight="155" VerticalAlignment="Top" IsVirtualizing="True" Grid.ColumnSpan="3">

<telerik:RadTileViewItem Header="Node Back Left" HeaderStyle="{StaticResource TileViewItemHeaderStyle1}" MouseLeftButtonUp="RadTileViewItem_MouseLeftButtonUp"/>

<telerik:RadTileViewItem Header="Node Back Right" HeaderStyle="{StaticResource TileViewItemHeaderStyle2}" MouseLeftButtonUp="RadTileViewItem_MouseLeftButtonUp"/>

<telerik:RadTileViewItem Header="Node Front Left" HeaderStyle="{StaticResource TileViewItemHeaderStyle3}" MouseLeftButtonUp="RadTileViewItem_MouseLeftButtonUp"/>

<telerik:RadTileViewItem Header="Node Front Right" HeaderStyle="{StaticResource TileViewItemHeaderStyle4}" MouseLeftButtonUp="RadTileViewItem_MouseLeftButtonUp"/>

<telerik:RadTileViewItem Header="Node Center" HeaderStyle="{StaticResource TileViewItemHeaderStyle3}" MouseLeftButtonUp="RadTileViewItem_MouseLeftButtonUp">

</telerik:RadTileViewItem>

</telerik:RadTileView>

</Grid>

</UserControl>

A

TileView

answered on 26 Jun 2012

2 answers

141 views

Get the time for a click event position

Hi,

I need to allow the user to add timeline live events by clicking with the mouse somewhere in the timeline. Can anyone tell me how to get the time corresponding to a mouse click event?

Regards,
Mathias

TimeLine

answered on 26 Jun 2012

1 answer

119 views

Set Destination Folder on saving

Hi,

is it possible to pre-select the destination-folder on saving a document in the richtextbox by code?

Background:
For Each Project in my Application i have to create a Folder (d:/Projects/Holiday_2012/Docs/). After opening a project in my
application the user could create a document in the richtextbox. If the user wants so save the document the Dialog should open
in the wright Destination Folder.

SOLVED !!!!!

Thanks
Regards
Rene

RichTextBox

answered on 26 Jun 2012

1 answer

146 views

IOException was thrown on "RadNumericUpDown"

Using 2012.2.607.40 I receive an exception, "Cannot locate resource 'themes/genericmetrotouch.xaml'", in the VS 2010 Xaml designer when a RadNumericUpDown control is included in the form. I've included a screenshot of the exception. There is no exception when running the app, or if I display the form in Blend.
Thanks,
Steve

NumericUpDown

answered on 26 Jun 2012

3 answers

133 views

Floating Rad Pane To Dock

Hi,

I have read an article where the when we use the rad pane to float. It uses FloatingOnly. Is there a way to override this menu to use the method MakeFloatingDockable instead of MakeFloatingOnly

Also how would you re-dock a floating window from code.

Docking

answered on 26 Jun 2012

3 answers

172 views

Binding to RadEntityFrameworkDataSource

I need to make an hierarchical tree bound to an entity model. Shall I use a RadEntityFrameworkDataSource? Do you have any examples?

TreeView

answered on 26 Jun 2012

1 answer

289 views

Custom theme for RadTimeline

I'm trying to make a custom theme for the RadTimeline.

Im my custom theme, I want to wrap a ScrollViewer around the Timeline's TimelineItemContainer just like described in this post: http://www.telerik.com/community/forums/silverlight/timeline/vertical-scrollbar-scrollviewer-and-radtimeline.aspx
and I want to remove the horizontal scrollbar of the control (the RadSlider at the bottom).

I've tried to create a custom theme using the approach described here:
http://www.telerik.com/help/silverlight/common-styling-apperance-themes-custom-theme-project-telerik-approach.html
(albeit the documentation is for Silverlight, couldn't find anything similar for WPF)
and I've also had a look at the sample project here:
http://www.telerik.com/community/forums/wpf/general-discussions/how-can-i-create-a-custom-theme-for-wpf-application.aspx

I couldn't manage to get the theme working.
I'm not sure if I made everything right in the theme project - especially the following things in the XAML of my custom theme:

<my:MyTheme x:Key="Theme" />
The many references to ThemeType=telerik:Office_BlackTheme
content of Generic.xaml
declaration of MyTheme class

Basically, I've just copied the file C:\Program Files (x86)\Telerik\RadControls for WPF Q1 2012 SP1\Themes\WPF40\Windows7\Themes\Telerik.Windows.Controls.DataVisualization.xaml which contains the style for RadTimeline to my CustomTheme project and modified the style there. I'm not quite sure, if that was correct, or what I've done wrong.

Actually, it doesn't have to be a whole custom theme, I just want to change the style of RadTimeline like described above. So, my first try was to edit the style using Expression Blend. I selected the RadTimeline and chose: Edit Template --> Edit a Copy. This alone shouldn't change the style at all, shouldn't it? But instead, the whole control is white/transparent - please see the attached files before_edit_template.png and after_edit_template.png. I expect it to look exactly the same as before calling Edit Template --> Edit a Copy. Why isn't it?

Here (http://johannes.unterguggenberger.info/TimelineCustomTheme.zip) is a Solution which contains 2 Projects: A custom theme project and a project which uses the custom theme (at least tries to) to change the style of a RadTimeline. Maybe someone could have a look at it and maybe tell me, what's the problem, or point me in a direction.

Thanks in advance!

TimeLine

answered on 26 Jun 2012
