RadGridView Column Display Error

[Edward Chen]

Hi,
After attaching a datasource to a radgridview , I apply best fit on the entire grid. But sometimes my grid behaves wierd and gives me something like the attached image. Please help.

Thanks a lot
Shweta

[Richard Slade]

Hello Edward,

Please could you give some further details on your error. For exmaple, any special grid settings that you are using, such as AutoSizeRows etc.. and if you can post a small sample that replicates the issue, then that would also help

In the meantime, here is a sample that you can try in a new project. Please let me know if this works fine for you.
Thanks
Richard

Designer File

<Global.Microsoft.VisualBasic.CompilerServices.DesignerGenerated()> _
Partial Class GenericItemListForm
    Inherits System.Windows.Forms.Form

    'Form overrides dispose to clean up the component list.
    <System.Diagnostics.DebuggerNonUserCode()> _
    Protected Overrides Sub Dispose(ByVal disposing As Boolean)
        Try
            If disposing AndAlso components IsNot Nothing Then
                components.Dispose()
            End If
        Finally
            MyBase.Dispose(disposing)
        End Try
    End Sub

    'Required by the Windows Form Designer
    Private components As System.ComponentModel.IContainer

    'NOTE: The following procedure is required by the Windows Form Designer
    'It can be modified using the Windows Form Designer.
    'Do not modify it using the code editor.
    <System.Diagnostics.DebuggerStepThrough()> _
    Private Sub InitializeComponent()
        Dim SortDescriptor1 As Telerik.WinControls.Data.SortDescriptor = New Telerik.WinControls.Data.SortDescriptor()
        Me.RadGridView1 = New Telerik.WinControls.UI.RadGridView()
        CType(Me.RadGridView1, System.ComponentModel.ISupportInitialize).BeginInit()
        Me.SuspendLayout()
        '
        'RadGridView1
        '
        Me.RadGridView1.BackColor = System.Drawing.SystemColors.Control
        Me.RadGridView1.Cursor = System.Windows.Forms.Cursors.Default
        Me.RadGridView1.Dock = System.Windows.Forms.DockStyle.Fill
        Me.RadGridView1.Font = New System.Drawing.Font("Segoe UI", 8.25!)
        Me.RadGridView1.ForeColor = System.Drawing.SystemColors.ControlText
        Me.RadGridView1.ImeMode = System.Windows.Forms.ImeMode.NoControl
        Me.RadGridView1.Location = New System.Drawing.Point(0, 0)
        '
        'RadGridView1
        '
        Me.RadGridView1.MasterTemplate.EnableAlternatingRowColor = True
        Me.RadGridView1.MasterTemplate.ShowRowHeaderColumn = False
        SortDescriptor1.Direction = System.ComponentModel.ListSortDirection.Descending
        SortDescriptor1.PropertyName = "DateStamp"
        Me.RadGridView1.MasterTemplate.SortDescriptors.AddRange(New Telerik.WinControls.Data.SortDescriptor() {SortDescriptor1})
        Me.RadGridView1.Name = "RadGridView1"
        Me.RadGridView1.Padding = New System.Windows.Forms.Padding(0, 0, 0, 1)
        Me.RadGridView1.RightToLeft = System.Windows.Forms.RightToLeft.No
        '
        '
        '
        Me.RadGridView1.RootElement.Padding = New System.Windows.Forms.Padding(0, 0, 0, 1)
        Me.RadGridView1.Size = New System.Drawing.Size(874, 443)
        Me.RadGridView1.TabIndex = 0
        Me.RadGridView1.Text = "RadGridView1"
        '
        'GenericItemListForm
        '
        Me.AutoScaleDimensions = New System.Drawing.SizeF(6.0!, 13.0!)
        Me.AutoScaleMode = System.Windows.Forms.AutoScaleMode.Font
        Me.ClientSize = New System.Drawing.Size(874, 443)
        Me.Controls.Add(Me.RadGridView1)
        Me.Name = "GenericItemListForm"
        Me.Text = "PendingItems"
        CType(Me.RadGridView1, System.ComponentModel.ISupportInitialize).EndInit()
        Me.ResumeLayout(False)

    End Sub
    Friend WithEvents RadGridView1 As Telerik.WinControls.UI.RadGridView
    'Friend WithEvents BaseItemsBindingSource As System.Windows.Forms.BindingSource
End Class

form1.vb

Imports Telerik.WinControls.UI
Imports System.Text
Imports Telerik.WinControls.Data
Imports Telerik.WinControls.UI.Export
Imports System.ComponentModel

Public Class GenericItemListForm


    Public Sub New()
        InitializeComponent()

        RadGridView1.AutoSizeRows = False
        RadGridView1.AutoSizeColumnsMode = GridViewAutoSizeColumnsMode.None
        RadGridView1.AutoGenerateColumns = True

        Dim myList As New BindingList(Of MyObject)
        For i As Integer = 0 To 20
            Dim item As New MyObject("Name " & i.ToString(), "A text description " & i.ToString(), i)
            myList.Add(item)
        Next
        Me.RadGridView1.DataSource = myList
    End Sub

    Private Sub RadGridView1_DataBindingComplete(ByVal sender As System.Object, ByVal e As Telerik.WinControls.UI.GridViewBindingCompleteEventArgs) Handles RadGridView1.DataBindingComplete
        Me.RadGridView1.BestFitColumns()
    End Sub
End Class


Public Class MyObject

    Public Sub New(ByVal name As String, ByVal description As String, ByVal id As Integer)
        Me.Name = name
        Me.Description = description
        Me.Id = id
    End Sub

    Public Property Name As String
    Public Property Description As String
    Public Property Id As Integer

End Class

[Edward Chen]

Thanks a lot . I will give it a try.
