JSON data bind with Kendo Grid can't display

2 Answers 608 Views
Data Source
This is a migrated thread and some comments may be shown as answers.
ZHILONG
Top achievements
Rank 1
ZHILONG asked on 21 Sep 2016, 07:31 AM

Hello Everyone,

I am developing a ASP.NET MVC program with angular kendoUI, my program gets JSON data successfully, but the data can not display in kendo GRID normally. Could anyone provide some advice, thank you.

Image:



Javascript:

function getDetailRouting(dataItem) {


           return {
               dataSource: {
                   //data: $scope.Structure
                   //type: "Json",
                   transport: {
                       read: "/api/routings/details/" + dataItem.Model + "/" + dataItem.PCBA
                   }
                   ,
                   schema: {
                       data: "data",
                       model: {
                           fields: {
                               Model: { type: "string" },
                               PCBA: { type: "string" },
                               SeqNo: { type: "int" },
                               Process: { type: "string" },
                               FailedUnitReturnTo: { type: "string" },
                               MaxTestRound: { type: "int" },
                               MaxFailure: { type: "int" },
                               StandardTime: { type: "date" },
                               SamplingTest: { type: "boolean" },
                               SamplingLogic: { type: "string" },
                               PanelMatching: { type: "boolean" },
                               PanelSize: { type: "int" },
                               RetestFlag: { type: "string" },
                               MatchingbyExtSN: { type: "boolean" },
                               Label1: { type: "string" },
                               Label2: { type: "string" },
                               Label3: { type: "string" },
                           }
                       }
                   },
                   serverPaging: true,
                   serverSorting: true,
                   serverFiltering: true,
                   pageSize: 5,
                   ////filter: { field: "EmployeeID", operator: "eq", value: dataItem.EmployeeID }
               },
               height: 150,
               scrollable: true,
               sortable: true,
               pageable: true,
               filterable: true,
               columns: [
               { field: "Model", title: "Model", width: "56px" },
               { field: "PCBA", title: "PCBA", width: "110px" }
               ]
           };

       }

Html:

<div kendo-grid id="grid" k-options="StructureGrid"  k-data-source="StructureGrid.dataSource">
    <div k-detail-template>
        <kendo-tabstrip>
            <ul>
                <li class="k-state-active">Routing</li>
                <li>Contact information</li>
            </ul>
            <div>
                <div kendo-grid k-options="getDetailRouting(dataItem)"></div>
            </div>
            <div>
                <ul class="contact-info-form">
                    <li><label>SeqNo:</label> <input class="k-textbox" ng-model="dataItem.Country" /></li>
                    <li><label>Process:</label> <input class="k-textbox" ng-model="dataItem.City" /></li>
                    <li><label>Failed Unit Return TO:</label> {{dataItem.Address}}</li>

                </ul>
            </div>
        </kendo-tabstrip>
    </div>
</div>









2 Answers, 1 is accepted

Sort by
0
ZHILONG
Top achievements
Rank 1
answered on 22 Sep 2016, 09:11 AM
figure out, set data: "";
0
Alex Hajigeorgieva
Telerik team
answered on 22 Sep 2016, 03:18 PM
Hi Zhilong,

The Kendo UI Data Source schema data configuration property is not always necessary. It depends on the server response:

http://docs.telerik.com/kendo-ui/api/javascript/data/datasource#configuration-schema.data

It seems that you may remove the schema data configuration because the response contains only the dataItems.

Regards,
Alex
