[Solved] GridViewToggleRowDetailsColumn button does not select row

[Matthias]

Hi,

I am using Silverlight 4 and the latest Telerik build.  I am having a problem with using a GridViewToggleRowDetailsColumn button with a RadGridView.  When I click the '+' sign on a row to show the RowDetails, it does not select the row at the same time.  I can expand other rows but the RowDetails only show for the selected row, which can be different from the expanded row. I have attached a screenshot to help explain.  Can anyone point me in the right direction?

Thanks,

Matt

[Milan]

Hi Matthias,

The purpose of the GridViewToggleRowDetailsColumn is to expand row details - it will not select the respective item. If you would like to select row details when they are expanded you could try something like this:

// subscribe to RowDetailsVisibilityChanged
private void RadGridView_RowDetailsVisibilityChanged(object sender, GridViewRowDetailsEventArgs e)
{
    if (e.Visibility.Value == System.Windows.Visibility.Visible)
    {
        e.Row.IsSelected = true;
    }
}

All the best,
Milan
the Telerik team

Do you want to have your say when we set our development plans? Do you want to know when a feature you care about is added or when a bug fixed? Explore the Telerik Public Issue Tracking system and vote to affect the priority of the items.

[Matthias]

That's exactly what I was looking for :)

Thanks!

[Sadi]

Is there a better solution to this out now..? How is it supposed to be implemented in MVVM.

[Vlad]

Hello,

 You can use attached behavior with the same if you want reusable MVVM style code.

Regards,
Vlad
the Telerik team

[Subhendu]

A sample implementation of attached propertey (Not the beahaviour )

public static class CommandProvider

   {

       public static ICommand GetCommand(DependencyObject obj)

       {

           return (ICommand)obj.GetValue(CommandProperty);

       }



       public static void SetCommand(DependencyObject obj, ICommand value)

       {

           obj.SetValue(CommandProperty, value);

       }



      public static readonly DependencyProperty CommandProperty =

           DependencyProperty.RegisterAttached(

               "Command",

               typeof(ICommand),

               typeof(CommandProvider),

               new PropertyMetadata(

                   default(ICommand),

                   new PropertyChangedCallback(HandleCommandChangedCallback)));





   public static void HandleCommandChangedCallback(

           DependencyObject dependencyObject,

           DependencyPropertyChangedEventArgs eventArgs)

       {

         if (dependencyObject is RadGridView)

           {

               var radGrid = dependencyObject as RadGridView;



               if (radGrid != default(RadGridView))

               {

                   radGrid.RowDetailsVisibilityChanged += (sender, args) =>

                       {

                           if (args.Visibility.Value ==Visibility.Visible )

                           {

                               args.Row.IsSelected = true;

                           }

                       };

               }

           }

       }

   }

and in XAML :

<telerik:RadGridView extensibility:CommandProvider.Command="{Binding RowVisibilityChanged}">

RowVisibilityChanged is you RelayCommand.
