Excel Export Is Not Working with grid

5 posts, 0 answers
  1. Olivier
    Olivier avatar
    3 posts
    Member since:
    Jul 2017

    Posted 25 Jul 2017 Link to this post

    I

    <div class="panel-body">
                            @(Html.Kendo().Grid<CdsAdmin.ViewModels.TravelPreferenceVM>()
                                  .Name("gridTravelPreference")
                                  .Columns(columns =>
                                  {
                                      columns.Bound(c => c.TPF_ID).Hidden();
                                      columns.Bound(c => c.TPO_ID).Hidden();
                                      columns.Bound(c => c.TPF_NAME).Filterable(true).Width(200);
                                      columns.Bound(c => c.TPF_DESC).Filterable(false).Width(250);
                                      columns.Bound(c => c.TPF_STATUS).ClientTemplate("# if (TPF_STATUS == 1 ) {# Active #} else {# Inative #}#").Filterable(false).Width(100);
                                      columns.Bound(c => c.TPF_PREFERENCE).ClientTemplate("# if (TPF_PREFERENCE == 1 ) {# <i class='fa fa-heart'></i><i class='fa fa-heart'></i> #} " +
                                          "else if (TPF_PREFERENCE == 2 ) {# <i class='fa fa-heart'></i><i class='fa fa-heart'></i><i class='fa fa-heart'></i>  #} " +
                                          "else if (TPF_PREFERENCE == 3 ) {# <i class='fa fa-stars'></i> Exclusive  #} " +
                                          "else if (TPF_PREFERENCE == 0 ) {# Neutral #} " +
                                          "else if (TPF_PREFERENCE == -1 ) {# Hidden #} " +
                                          "else {# TPF_PREFERENCE #}#").Filterable(false).Width(200);
                                      columns.Bound(c => c.HTL_CD).Filterable(false);
                                      columns.Bound(c => c.HCH_ID).Filterable(false);
                                      columns.Command(command => { command.Edit().Text(" "); command.Destroy().Text(" "); }).Width(150);
                                  })
                                  .ToolBar(toolbar =>
                                  {
                                      toolbar.Template(@<text>
                                <a class='k-button k-button-icontext k-grid-excel' href='#'><span class='k-icon k-i-excel'></span>Export Excel</a>
                                <a class='k-button k-button-icontext k-grid-pdf' href='#'><span class='k-icon k-i-pdf'></span>Export PDF</a>
                                <a class='k-button k-button-icontext k-grid-add' href='#'><span class='k-icon k-i-add'></span>Add</a>
                                <a class="k-button k-button-icontext" onclick="addMultiHotels()" style="width:200px;"><span class='k-icon k-i-add'></span>Add multi</a>
                                    </text>);
                                  })
                                  .Editable(editing =>
                                  {
                                      editing.Mode(GridEditMode.PopUp).TemplateName("PopupEditors/PopupTravelPreference")
                                          .Window(w => w.Title("Management preferred hotels").AutoFocus(true));
                                      editing.DisplayDeleteConfirmation("Are you sure ?");
                                  })
                                  .Filterable(ftb => ftb.Mode(GridFilterMode.Row))
                                  .Pageable(pageable => pageable
                                               .Refresh(true)
                                               .PageSizes(false)
                                               .ButtonCount(10))
                                  .Excel(excel => excel.FileName("HotelExcel.xlsx")
                                                       .Filterable(true)
                                                       .AllPages(true)
                                                       .ProxyURL(Url.Action("ExcelExport", "TravelPreference")))
                                  .Pdf(pdf => pdf.AllPages()
                                                 .AvoidLinks()
                                                 .PaperSize("A4")
                                                 .Scale(0.8)
                                                 .Margin("2cm", "1cm", "1cm", "1cm")
                                                 .Landscape()
                                                 .RepeatHeaders()
                                                 .TemplateId("pdf-template")
                                                 .FileName("HotelPdf.pdf")
                                                 .ProxyURL(Url.Action("PdfExport", "TravelPreference")))
                                  .Scrollable()
                                  .Selectable(selectable => selectable.Mode(GridSelectionMode.Multiple)
                                                                      .Type(GridSelectionType.Cell))
                                  .Navigatable()
                                  .AllowCopy(true)
                                  .Resizable(resize => resize.Columns(true))
                                  .Reorderable(reorder => reorder.Columns(true))
                                  .NoRecords(n => n.Template("Il n'y a pas des hôtels préféré pour cette compagnie."))
                                  .HtmlAttributes(new { style = "height:650px;" })
                                  .Events(events => events.Edit("onKendoGridEdit"))
                                  .DataSource(dataSource => dataSource
                                      .Ajax()
                                      .PageSize(100)
                                      .ServerOperation(true)
                                      .Events(events => events.Error("KendoGridErrorHandler").RequestStart("onRequestStart").RequestEnd("onRequestEnd"))
                                      .Model(model =>
                                      {
                                          model.Id(p => p.TPF_ID);
                                          model.Field(p => p.TPF_ID).Editable(false);
                                          model.Field(p => p.HOTEL).Editable(false);
                                      })
                                      .Create(update => update.Action("Create", "TravelPreference"))
                                      .Read(read => read.Action("Read", "TravelPreference").Data("additionalInfo"))
                                      .Update(update => update.Action("Update", "TravelPreference"))
                                      .Destroy(update => update.Action("Destroy", "TravelPreference"))
                                  ))
                        </div>

    My controller

       [HttpPost]

            public ActionResult ExcelExport(string contentType, string base64, string fileName)
            {
                var fileContents = Convert.FromBase64String(base64);
                return File(fileContents, contentType, fileName);
            }



    My js

    function additionalInfo() {
        return {
            companyId: CmpId
        }
    }

  2. Olivier
    Olivier avatar
    3 posts
    Member since:
    Jul 2017

    Posted 25 Jul 2017 in reply to Olivier Link to this post

    I forgot my read action and i think the problem is when i use server pagination with a read action with addionaldata

    [OutputCache(NoStore = true, Duration = 0, VaryByParam = "*")]
            public ActionResult Read([DataSourceRequest]DataSourceRequest request, int companyId)
            {
                List<TravelPreferenceVM> lstVM = new List<TravelPreferenceVM>();
                if (companyId > 0)
                    lstVM = travelPreferenceService.GetByCompany(companyId);
                return Json(lstVM.ToDataSourceResult(request));
            }

  3. Stefan
    Admin
    Stefan avatar
    3076 posts

    Posted 27 Jul 2017 Link to this post

    Hello Olivier,

    Thank you for providing the code.

    After inspecting it, it looks good and it should work as expected. Still, in order to determine what may be causing the issue, please share with us what is happening when the Excel export button is clicked? For example, is there any JavaScript error in the console, or if the ExcelExport action is hit in the controller.

    Also, providing a fully runnable example will be very helpful as it will allow us to inspect the application and provide a suggestion best suited for it.

    Regards,
    Stefan
    Progress Telerik
    Try our brand new, jQuery-free Angular 2 components built from ground-up which deliver the business app essential building blocks - a grid component, data visualization (charts) and form elements.
  4. Olivier
    Olivier avatar
    3 posts
    Member since:
    Jul 2017

    Posted 27 Jul 2017 in reply to Stefan Link to this post

    Hello Stephan,

    Thank you for your reply but i forgot to post the solution. The problem was from the length of JSON sended to the grid for serialisation, I delete the field from my object (ViewModel) and it works. But i have a question, How we handle long Json-String?

  5. Stefan
    Admin
    Stefan avatar
    3076 posts

    Posted 31 Jul 2017 Link to this post

    Hello Olivier,

    Thank you for the clarification.

    If the JSON length is too large, I can assume that there is an error on the server.

    I can suggest checking the following questions on StackOverflow as they demonstrate how to change the JSON max length and provide more information on the different JSON length limitations that can be hit:

    https://stackoverflow.com/questions/1151987/can-i-set-an-unlimited-length-for-maxjsonlength-in-web-config/1151993#1151993

    https://stackoverflow.com/questions/1262376/is-there-a-limit-on-how-much-json-can-hold

    Regards,
    Stefan
