ComboBox - DropDownButton - DataTemplate

[Palmsenser]

Hallo,

I would like to customize the icon of the "ComboBox - DropDownButton"

Is there any "DataTemplate" for "ComboBox - DropDownButton"? Or any other solution?

I understand that I can customize the style in "RadComboBox.DropDownButtonStyle", but I need the customize the icon of the button

[Didi]

Hi Paim,

You can customize the drop down button using the DropDownButtonStyle.

If you want to change the icon, then use the Text property, also you have to set the FontFamily property.

Example:

ComboBox definition in xaml:

<telerik:RadComboBox ItemsSource="{Binding Items}"
                                 SearchTextPath="Name"
                                 DisplayMemberPath="Name"
                                 DropDownButtonStyle="{StaticResource DropDownButtonStyle}">
                <telerik:RadComboBox.BindingContext>
                    <local:ViewModel/>
                </telerik:RadComboBox.BindingContext>
</telerik:RadComboBox>



DropDownButtonStyle defined in the page's resource:

<ResourceDictionary>
    <Style TargetType="telerik:RadButton" x:Key="DropDownButtonStyle">
        <Setter Property="FontSize" Value="14"/>
        <Setter Property="HorizontalOptions" Value="Center"/>
        <Setter Property="VerticalOptions" Value="Center"/>
        <Setter Property="WidthRequest" Value="30"/>
        <Setter Property="HeightRequest" Value="30"/>
        <Setter Property="Padding" Value="0"/>
        <Setter Property="Text" Value="&#xe809;"/>
        <Setter Property="FontFamily" Value="TelerikFontExamples"/>
        <Setter Property="BackgroundColor" Value="Transparent"/>
        <Setter Property="TextColor" Value="Blue"/>
        <Setter Property="Padding" Value="{OnPlatform Android='8, 2, 4, 2', iOS='4, 2, 12, 2', MacCatalyst='4, 0, 8, 0', WinUI='6, 0, 10, 0'}"/>
    </Style>
</ResourceDictionary>

And the final result:



Regards,
Didi
Progress Telerik

[Palmsenser]

Hallo,

I use "telerik:RadComboBox.SelectionBoxTemplate" to customize "text beside DropDownButton". It display the item correctly when the control loaded, however, if I change the selection, new selected item is not showed, ("text beside DropDownButton" is just empty).

Is there any demo example for how to use  "telerik:RadComboBox.SelectionBoxTemplate" proplerly?

[Didi]

Hi Palm,

Could you please send us a sample repro project with the exact implementation you have for the ComboBox control and the SelectionboxTemplate. In this way we can test on our side the exact behavior with the SelectionBoxTemplate. Also you can attach an image what is the desired result you want to achieve and how the control looks now.
