asked on 06 Mar 2010, 09:50 AM
Hello
I attch my layout picture for describing my problem. (VB2008)
Base form is Radform and I attach 2 radpanels for locating my function buttons.
I used dock property for locating two panels and one activex(dark panel.)
I draw color square lines what I want to located my 2 panels and 1 active x panel.
And I also want to sizable windows. ofcourse I want to 3 items docking in the dialog like my layout picture.
I just used dock property for my layout...
Do I have any method for making my layout?
If I have, please let me know..;;
P.S app_layout_1.jpg is my goal.
P.S But Now my app is like app_layout_2.jpg
Active x panel(3) is fill with all dialog, and (2),(3) radpanel covered with active x panel.
I attch my layout picture for describing my problem. (VB2008)
Base form is Radform and I attach 2 radpanels for locating my function buttons.
I used dock property for locating two panels and one activex(dark panel.)
I draw color square lines what I want to located my 2 panels and 1 active x panel.
And I also want to sizable windows. ofcourse I want to 3 items docking in the dialog like my layout picture.
I just used dock property for my layout...
Do I have any method for making my layout?
If I have, please let me know..;;
P.S app_layout_1.jpg is my goal.
P.S But Now my app is like app_layout_2.jpg
Active x panel(3) is fill with all dialog, and (2),(3) radpanel covered with active x panel.
1 Answer, 1 is accepted
0
Hi JANG KYUNG SEOC,
You need to change the ZOrder of the docked panels in order to get the desired layout. For additional information, please refer to the following knowledge base article: Docking controls on a form in a Windows Forms application.
If you want to resize the docked panels by a drag and drop operation, you need RadSplitContainer control. For additional information, refer to this article.
