Questions on UI for WinForms Forum

3 answers

131 views

Custom Summary Item wont work after LoadLayout

Hello,

I created a CustomSummaryItem and it work correctly when I add it to summary row with code, but if I save GridView layout and load it the custom summary wont function

this is my CustomSummaryItem:

public class CustomSummaryItem : GridViewSummaryItem
    {
        public CustomSummaryItem(string name,string sourceColumn)
            : base(name, "{0}",GridAggregateFunction.Sum)
        {
            SourceColumn = sourceColumn;
        }
        public string SourceColumn { get; set; }
        public override object Evaluate(IHierarchicalRow row)
        {

            var sum = row.ChildRows.Sum(childRow => (childRow.Cells[this.SourceColumn]?.Value).ToDouble());
            var time = TimeSpan.FromMilliseconds(sum).ToString();
            return time;
        }
    }

GridView

answered on 02 Dec 2017

1 answer

67 views

Controlling the background color or sizing for dead space

I would like the ability to either shrink the to fit the number of rows it has (thereby showing the background color below it) or to control the color of the dead space separately from the background color or alternating row color.

Could I change the background color of the itself and then set each row's individually perhaps to achieve this?

GridView

answered on 01 Dec 2017

1 answer

506 views

PDFViewer from Memory Stream

I just can't seem to get my PDF to load. I amcreating a RadFixedDocument.

If I export it to a file, and load it to the viewer, it works just fine:

using (var stream = File.OpenWrite(resultFile))

{

PdfFormatProvider provider = new PdfFormatProvider();

provider.Export(pdf, stream);

}

pdfXactReport.LoadDocument(resultFile);

Seems like this should work, what am I missing??

using (var saveToMS = new MemoryStream())

{

PdfFormatProvider provider = new PdfFormatProvider();

provider.Export(pdf, saveToMS);

pdfXactReport.LoadDocument(saveToMS);

}

PdfViewer and PdfViewerNavigator

answered on 01 Dec 2017

2 answers

928 views

Unable to create RadGridView component

Hello,

After having Designer issues (i hacked the designer) i removed my UserControl who was the problem; i created a new one wich is the exact (mostly) same UserControl. But when i want to create a new RadGridView i'm getting this error:

Unable to create component 'RadGridView'.

'System.Runtime.InteropServices.COMException (0x8004D45); A reference of 'Telerik.WinControls.GridView already existe in the project.

at VSLangProj.References.Add(String bstrPath)

at Microsoft.VisualStudio.Design.VSTypeResolutionService.PerformReferenceUpdate(List'1 newReferences)

at Microsoft.VisualStudio.Design.VSTypeResolutionService.SystemComponentModel.Design.ITypeResolutionService.ReferenceAssembly

I am using Visual Studio 2013. All my references are present. I tried to create a new Project Telerik ; i'm able to use a RadgridView in the new one.

GridView

answered on 01 Dec 2017

0 answers

88 views

Drag and drop from RadListView to RadGridView

private BindingSource _bindingSource;
 DataTable gridViewDataTable = new DataTable();

 public SocPersonal()
 {
 InitializeComponent(); BaseGridBehavior gridBehavior = this.radGridView2.GridBehavior as BaseGridBehavior; gridBehavior.UnregisterBehavior(typeof(GridViewDataRowInfo)); gridBehavior.RegisterBehavior(typeof(GridViewDataRowInfo), new CustomRowGridBehavior()); RadDragDropService dragDropService = radGridView2.GridViewElement.GetService<RadDragDropService>(); dragDropService.PreviewDragStart += svc_PreviewDragStart; dragDropService.PreviewDragOver += svc_PreviewDragOver; dragDropService.PreviewDragDrop += svc_PreviewDragDrop; gridViewDataTable.Columns.Add("key_socRabotnik", typeof(string)); gridViewDataTable.Columns.Add("[ФИО]", typeof(string)); radListView1.ListViewElement.DragDropService.PreviewDragOver += PreviewDragOver; radListView1.ListViewElement.DragDropService.PreviewDragDrop += PreviewDragDrop; MyRussionRadGridLocalizationProvider.CurrentProvider = new MyRussionRadGridLocalizationProvider(); radGridView1.TableElement.Text = MyRussionRadGridLocalizationProvider.TableElementText; CheckForIllegalCrossThreadCalls = false;
 HandleCreated += Form_HandleCreated;
 }

 #region Drop
 private void svc_PreviewDragStart(object sender, PreviewDragStartEventArgs e)
 {
 e.CanStart = true;
 }

 private void svc_PreviewDragOver(object sender, RadDragOverEventArgs e)
 {
 if (e.DragInstance is GridDataRowElement)
 {
 e.CanDrop = e.HitTarget is DetailListViewDataCellElement ||
 e.HitTarget is DetailListViewElement;
 }
 }

 private void svc_PreviewDragDrop(object sender, RadDropEventArgs e)
 {
 DetailListViewDataCellElement targetCell = e.HitTarget as DetailListViewDataCellElement;
 DetailListViewElement targetElement = e.HitTarget as DetailListViewElement;
 GridDataRowElement draggedRow = e.DragInstance as GridDataRowElement;

 if (draggedRow == null)
 {
 return;
 }
 ListViewDataItem item = new ListViewDataItem();
 DataRow draggedDataBoundItem = ((DataRowView)draggedRow.RowInfo.DataBoundItem).Row;
 if (targetElement != null)
 {
 ((RadListViewElement)targetElement.Parent).Items.Add(item);
 }
 if (targetCell != null)
 {
 BaseListViewVisualItem targetVisualItem = targetCell.RowElement;

 int insertIndex = targetCell.Row.ListView.Items.IndexOf(targetVisualItem.Data);
 if (insertIndex > -1)
 {
 targetCell.Row.ListView.Items.Insert(insertIndex, item);
 }
 }
 item["key_socRabotnik"] = draggedDataBoundItem["key_socRabotnik"];
 item["[ФИО]"] = draggedDataBoundItem["[ФИО]"];

 gridViewDataTable.Rows.Remove(draggedDataBoundItem);
 }

 private void PreviewDragOver(object sender, RadDragOverEventArgs e)
 {
 e.CanDrop = e.HitTarget is GridTableElement ||
 e.HitTarget is GridDataRowElement;
 }

 private void PreviewDragDrop(object sender, RadDropEventArgs e)
 {
 BaseListViewVisualItem draggedItem = e.DragInstance as BaseListViewVisualItem;
 GridDataRowElement rowElement = e.HitTarget as GridDataRowElement;
 GridTableElement tableElement = e.HitTarget as GridTableElement;

 if (rowElement == null && tableElement == null)
 {
 return;
 }
 e.Handled = true;
 DataRow newRow = gridViewDataTable.NewRow();
 newRow["key_socRabotnik"] = draggedItem.Data["key_socRabotnik"];
 newRow["[ФИО]"] = draggedItem.Data["[ФИО]"];
 if (tableElement != null)
 {
 gridViewDataTable.Rows.Add(newRow);
 }

 if (rowElement != null)
 {
 GridViewRowInfo targetRow = rowElement.RowInfo;

 int insertIndex = this.radGridView2.Rows.IndexOf(targetRow);
 if (insertIndex > -1)
 {
 gridViewDataTable.Rows.InsertAt(newRow, insertIndex);
 }
 }


 this.radListView1.Items.Remove(draggedItem.Data);
 } private void fillTheDataGrid()
 {
 var commandServer = new CommandServer();
 try
 {
 radGridView2.Invoke(new MethodInvoker(delegate ()
 {
 _bindingSource = new BindingSource { DataSource = commandServer.GetDataGridSet(@"select key_socRabotnik, fio as [ФИО]
 from socRabotnik
 where statusDel = 0
 order by fio").Tables[0] };
 radGridView2.DataSource = _bindingSource;

 if (radGridView2.Columns.Count > 0)
 {
 radGridView2.Columns[0].IsVisible = false;
 radGridView2.AutoSizeColumnsMode = GridViewAutoSizeColumnsMode.Fill;
 }

 _bindingSource = new BindingSource { DataSource = commandServer.GetDataGridSet(@"select key_socRabotnik, fio as [ФИО]
 from socRabotnik left join spec_soc on key_socRabotnik = fk_socRabotnik
 where fk_socRabotnik is null").Tables[0] };
 radListView1.DataSource = _bindingSource;
 radListView1.DisplayMember = "[ФИО]";
 radListView1.ValueMember = "[ФИО]";
 radListView1.Columns[0].Visible = false;
 }));
 }
 catch (Exception ex)
 {
 CommandClient commandClient = new CommandClient();
 commandClient.WriteFileError(ex, null);
 }
 }

ListView to GridView: It is dragged, deleted, but not in the grid.
GridView to ListView: error image

ListView

asked on 30 Nov 2017

1 answer

149 views

Listview IconView Image Performance

Dear, I need to load 03 listview simultaneously and these same handle many records in the iconview, what would be the best way to load and streamline this task by saving the path of the image and then assigning it by using the itemdatabound property or saving the image in arraybyte and then assigning it in the customvisualitem creation.

Thank you for your attention.

regards

ListView

answered on 30 Nov 2017

0 answers

85 views

Column chooser item formatting (height)

Hi,

I found the was to left-align the name of the column using the following code :

private void radGrid_ColumnChooserItemElementCreating(object sender, ColumnChooserItemElementCreatingEventArgs e)
{
e.ItemElement.TextAlignment = ContentAlignment.MiddleLeft;
}

But I did found how to set the height of the elements in the list of columns (see screenshot attached).

Is there any way to do it ?

Thank you.

GridView

asked on 29 Nov 2017

1 answer

661 views

Remove rows from grid

Hi. I am trying to remove rows and I get "formatException".

I've try to remove the rows like that:

grid.GridElement.BeginUpdate();

foreach (GridViewDataRowInfo row in grid.Rows)
{
if (row.Cells[1].Value.ToString() == "False")
{
grid.Rows.Remove(row);
}
}

grid.GridElement.EndUpdate();

AND like that:

grid.GridElement.BeginUpdate();

IEnumerable<GridViewDataRowInfo> uncheckedRows = grid.Rows.Where<GridViewDataRowInfo>(row => row.Cells[1].Value.ToString() == "False");

foreach (GridViewDataRowInfo uncheckedRow in uncheckedRows)
grid.Rows.Remove(uncheckedRow);

grid.GridElement.EndUpdate();

BOTH WAYS DON'T WORK...

GridView

answered on 28 Nov 2017

5 answers

356 views

RadDropDownList and ToolTipText

Hi,

Any reason for the ListElement of RadDropDownList showing the ToolTip when we have the RadDropDownList.ShowItemToolTips = False?

Another thing how we can access to the RadDropDownList control from the ListElement control? Imagine we catch the MouseHover event from ListElement and want to access to the parent control (the RadDropDownList control)?

Thank You

DropDownList
