RadTabControl without Content Area

[Jozef Prídavok]

Hello,

i would like to have RadTabControl with empty TabItem. I tried to set empty border but there is still 2pixel weight horizontal lines - see attached image. Here is my style:

        <Style x:Key="RoundPanel-View" TargetType="tlrNavigation:RadTabControl">
            <Setter Property="VerticalAlignment" Value="Bottom" />
            <Setter Property="DropDownDisplayMode" Value="Visible" />
            <Setter Property="ScrollMode" Value="Viewport" />
            <Setter Property="BackgroundVisibility" Value="Collapsed" />
            <Setter Property="BorderThickness" Value="0" />
            <Setter Property="BorderBrush" Value="Transparent" />
        </Style>

TabItem i created programmaticaly without any content:

            RadTabItem ti = new RadTabItem() {
                Padding = new Thickness(4, 1, 4, 1),
                DropDownContent = view.ToString(),
                Header = new TextBlock() {
                    Text = view.ToString(),
                    Margin = new Thickness(19, 2, 19, 0)
                },
                BorderThickness = new Thickness(0),
                Tag = view
            };
            views.Items.Add(ti);

Is it possible to have totally collapsed Content Are? Thanks for any advices.

Jozef

[Jozef Prídavok]

No advices?

[Dimitrina]

Hello Jozef ,

Please find attached an example.

If you have further more questions please do not hesitate to ask us
I hope this will help you.

Sincerely yours,
Dimitrina
the Telerik team

Instantly find answers to your questions on the new Telerik Support Portal.
Watch a video on how to optimize your support resource searches and check out more tips on the blogs.

[Jozef Prídavok]

Thank you very much!

I used trick with Margin-Bottom=-2 in general style (not directly to "Content Area" control). So new style looks like:

        <Style x:Key="RoundPanel-View" TargetType="tlrNavigation:RadTabControl">
            <Setter Property="VerticalAlignment" Value="Bottom" />
            <Setter Property="DropDownDisplayMode" Value="Visible" />
            <Setter Property="ScrollMode" Value="Viewport" />
            <Setter Property="BackgroundVisibility" Value="Collapsed" />
            <Setter Property="BorderThickness" Value="0" />
            <Setter Property="BorderBrush" Value="Transparent" />
            <Setter Property="Background" Value="Transparent" />
            <Setter Property="Margin" Value="0,0,0,-2" />
        </Style>

Thank You again, You inspireted me! It will be fine to have new attribute (e.g. ContentAreaVisibility="Collapsed") - it would be perfect solution.

Regards

Jozef

[Kiril Stanoev]

Hello Jozef,

Thank you for the suggestion. We would definitely take it into consideration for the future versions of RadTabControl.

Regards,
Kiril Stanoev
the Telerik team
