RadScheduler, Footer with columns

4 posts, 0 answers
  1. Romain
    Romain avatar
    3 posts
    Member since:
    Jun 2013

    Posted 25 Apr 2014 Link to this post

    Hi,
    I am working on a TimeLineView RadScheduler witch have already one resource grouping.
    What I want to do is add a footer table or a row to the RadScheduler witch is aligned to the Scheduler (same number of cells as the number of timeslots).
    What I began to do is create a table dynamically but, I was wondering if I can do the same thing with another RessourceType or with a native functionality of the RadScheduler.
    You can see a screenshot of my Scheduler at me moment.

    Thanks and excuse me for my bad english
    Romain
  2. Ivan Zhekov
    Admin
    Ivan Zhekov avatar
    540 posts

    Posted 28 Apr 2014 Link to this post

    Hi, Romani.

    What you have described as a scenario is currently not possible with the built in functionality of RadScheduler: neither with a footer row / template nor with a special resource row.

    You will have to go with the dynamically created table below RadScheduler.

    Regards,
    Ivan Zhekov
    Telerik


    Check out the Telerik Platform - the only platform that combines a rich set of UI tools with powerful cloud services to develop web, hybrid and native mobile apps.


  3. UI for ASP.NET Ajax is Ready for VS 2017
  4. Romain
    Romain avatar
    3 posts
    Member since:
    Jun 2013

    Posted 23 Jul 2015 in reply to Ivan Zhekov Link to this post

    Hi,

    I need to export in PDF my TimeLineView RadScheduler with my footer, is it still impossible to add custom footer or ​add HTML during the export ?



    Thanks,

    Romain



  5. Ivan Zhekov
    Admin
    Ivan Zhekov avatar
    540 posts

    Posted 28 Jul 2015 Link to this post

    Hello, Romain.

    With the ClientExportManager (http://demos.telerik.com/aspnet-ajax/client-export-manager/overview/defaultcs.aspx) you could.

    What you need to do is to put RadScheduler and the desired custom footer in a common container and then export that element.

    It could be as easy as the following:

    <div>
        <span id="btn-export">Export pdf</span>
    </div>


    <hr />


    <div id="export-container">
        <div>SCHEDULER GOES HERE</div>
        <div>FOOTER GOES HERE </div>
    </div>


    <telerik:RadClientExportManager runat="server" ID="exportManager" />


    <script type="text/javascript">
    Sys.Application.add_load(function() {

        var $ = $telerik.$;
        var manager = $find( "<%= exportManager.ClientID %>" );

        $("#btn-export").click(function() {
            manager.exportPDF( "#export-container" );
        });
    });
    </script>


    (assuming you already have a script manager on the page)

    Regards,
    Ivan Zhekov
    Telerik
