Customizing Outlookbar (remove ContentElement, ItemPresenter)

3 posts, 0 answers
  1. Christian Muggli
    Christian Muggli avatar
    7 posts
    Member since:
    Jul 2009

    Posted 11 May 2010 Link to this post

    I want to customize the RadOutlookBar Control. I know i can create a ControlTemplate, that's what i did in the past, but this had the 'side-effect' that everytime, when there's a new release of the telerik controls, i had to remove and recreate the control template otherwise the designer (VS.NET 2010 and Blend3/4RC) did not render the controls correctly.

    What i want is a RadOutlookBar without the ContentPresenter (ContentElement) and without the HorizontalSplitter. in other words, i need the RadOutlookBar ContentPresenter to have the same Content (a RadTreeView) 'independently' of the selected OutlookBarItem / Button. How can i accomplish this?

    help's appreciated

  2. Kiril Stanoev
    Kiril Stanoev avatar
    1508 posts

    Posted 13 May 2010 Link to this post

    Hello Christian,

    I am not sure what you are trying to achieve, but besides editing the ControlTemplate of RadOutlookBar, another way to remove/hide the horizontal splitter and the content element is by using VisualTreeHelper:

    private void HideHorizontalSplitter_Click(object sender, RoutedEventArgs e)
        Panel root = VisualTreeHelper.GetChild(this.outlookBar1, 0) as Panel;
        Thumb horizontalSplitter = root.FindName("HorizontalSplitter") as Thumb;
        horizontalSplitter.Visibility = Visibility.Collapsed;
    private void HideContentElement_Click(object sender, RoutedEventArgs e)
        Panel root = VisualTreeHelper.GetChild(this.outlookBar1, 0) as Panel;
        ContentPresenter contentElement = root.FindName("ContentElement") as ContentPresenter;
        contentElement.Visibility = Visibility.Collapsed;

    Does this information help? If not, could you please elaborate a little bit more on the scenario you try to achieve. I'd be glad to further assist you.

    Best wishes,
    Kiril Stanoev
    the Telerik team

    Do you want to have your say when we set our development plans? Do you want to know when a feature you care about is added or when a bug fixed? Explore the Telerik Public Issue Tracking system and vote to affect the priority of the items.
  3. DevCraft R3 2016 release webinar banner
  4. Dennys
    Dennys avatar
    6 posts
    Member since:
    Nov 2010

    Posted 08 Feb 2011 Link to this post

    Is there a way to hide the HorizontalSplitter with a xaml declaration?


    Just managed to do it ;)

    <Style TargetType="Thumb" x:Key="MyHorizontalSplitterStyle">
        <Setter Property="Visibility" Value="Collapsed"></Setter>
    <telerik:RadOutlookBar HorizontalSplitterStyle="{StaticResource MyHorizontalSplitterStyle}">
