    Posted 07 Oct 2011 Link to this post

    Hi,

    Can anyone please suggest a solution.

    Thanks

    SurfRat.
  3. UI for ASP.NET Ajax is Ready for VS 2017
  4. Iana Tsolova
    Admin
    Iana Tsolova avatar
    3388 posts

    Posted 10 Oct 2011 Link to this post

    Hello Surf,

    In order to achieve your goal, you can try altering the ReadOnly property of the columns depending on which edit form is open. Or you can define your own FormTemplate and hide the controls in it based on the edited item.

    Find the below article for more information on accessing RadTreeList controls:
    http://www.telerik.com/help/aspnet-ajax/treelist-accessing-items.html

    Give it a try and let me know if any questions or issues arise.

    Greetings,
    Iana Tsolova
    the Telerik team
    If you want to get updates on new releases, tips and tricks and sneak peeks at our product labs directly from the developers working on the RadControls for ASP.NET AJAX, subscribe to their blog feed now
  5. Surf
    Surf avatar
    9 posts
    Member since:
    Sep 2011

    Posted 10 Oct 2011 Link to this post

    Hi Iana,

    I tried 'ReadOnly' on the columns but this does not remove the editor row. It only makes it 'ReadOnly'. Even setting the column Visible = False does not remove the editor.

    How can I get to the rows that are a part of the editor. I have been able to find the the editor rows in the TreeListEditFormItem but they are not publicly available. See the attached screenshot. If I could delete or make these items Visible = false then I will have achieved my goal.

    Thanks

    Surf.
  6. Surf
    Surf avatar
    9 posts
    Member since:
    Sep 2011

    Posted 11 Oct 2011 Link to this post

    Hi,

    Can you please respond to my query. I wish to get this finished as soon as possible. I created a custom editor but this did not help.

    Thanks

    Surf.
  7. Iana Tsolova
    Admin
    Iana Tsolova avatar
    3388 posts

    Posted 11 Oct 2011 Link to this post

    Hi Surf,

    The ReadOnly property is working with the last version of RadTreeList for ASP.NET AJAX as shown in this demo. However I prepared a demo for you illustrating how you can set it conditionally.

    Kind regards,
    Iana Tsolova
    the Telerik team
    If you want to get updates on new releases, tips and tricks and sneak peeks at our product labs directly from the developers working on the RadControls for ASP.NET AJAX, subscribe to their blog feed now
  8. Surf
    Surf avatar
    9 posts
    Member since:
    Sep 2011

    Posted 13 Oct 2011 Link to this post

    Hi Iana,

    Thanks very much for the help. I have it all working now. To help others who might have the same problem here are some snippets of my code:

    .aspx
    <telerik:RadTreeList ID="m_settingsTreeList" runat="server" EnableAJAX="True" CssClass="contentList"
        OnNeedDataSource="OnSettingsTreeListNeedDataSource" OnItemDataBound="OnSettingsTreeListItemDataBound"
        OnCreateColumnEditor="OnSettingsTreeListCreateColumnEditor" OnUpdateCommand="OnSettingsTreeListUpdateCommand"
        OnDeleteCommand="OnSettingsTreeListDeleteCommand" OnInsertCommand="OnSettingsTreeListInsertCommand"
        OnItemCommand="OnSettingsTreeListItemCommand"
        AutoGenerateColumns="false" ParentDataKeyNames="ParentId" DataKeyNames="Id" AllowPaging="true"
        PageSize="20" AllowSorting="true" NoRecordsText="There are no Brand Attributes">
        <Columns>
            <telerik:TreeListBoundColumn DataField="ParentId" HeaderText="ParentId" UniqueName="ParentId"
                ReadOnly="true" Visible="False" />
            <telerik:TreeListBoundColumn DataField="Id" HeaderText="Id" UniqueName="Id" ReadOnly="true"
                Visible="False" />
            <telerik:TreeListBoundColumn DataField="Name" HeaderText="Name" UniqueName="Name" />
            <telerik:TreeListBoundColumn DataField="BrandAttribute" HeaderText="Brand Attribute"
                UniqueName="BrandAttribute" />
            <telerik:TreeListEditCommandColumn HeaderText="" UniqueName="Edit" HeaderStyle-Width="80px"
                AddRecordText="Add New" />
            <telerik:TreeListTemplateColumn HeaderStyle-Width="50px" UniqueName="DeleteTemplateColumn">
                <ItemTemplate>
                    <asp:LinkButton ID="m_deleteButton" runat="server" CommandName="Delete" Text="Delete"
                        OnClientClick="if (!confirm('Are you sure you wish to delete this Brand Attribute?')) return false;" />
                </ItemTemplate>
            </telerik:TreeListTemplateColumn>
        </Columns>
        <ClientSettings>
        </ClientSettings>
    </telerik:RadTreeList>

    .cs
    #region Property SettingsTreeListDataTable

    private DataTable m_settingsTreeListDataTable;

    /// <summary>
    ///
    /// </summary>
    public DataTable SettingsTreeListDataTable
    {
        get
        {
            if (m_settingsTreeListDataTable == null)
            {
                PropertyType brandPropertyType = PropertyType.GetPropertyType(typeof (Brand));
                m_settingsTreeListDataTable = brandPropertyType.GetSettingsAsTreeListDataTable();
            }
            return m_settingsTreeListDataTable;
        }
    }

    #endregion

    protected void OnSettingsTreeListNeedDataSource(object sender, EventArgs e)
    {
        m_settingsTreeList.DataSource = SettingsTreeListDataTable;
    }

    protected void OnSettingsTreeListItemDataBound(object sender, TreeListItemDataBoundEventArgs e)
    {
        if (e.Item is TreeListDataItem)
        {
            // Hide Add Row button for all.
            TreeListDataItem treeListDataItem = (TreeListDataItem) e.Item;
            LinkButton addRecordButton = (LinkButton) treeListDataItem["Edit"].Controls[0];
            addRecordButton.Visible = false;
            if (treeListDataItem.ParentItem != null)
            {
                // Hide Delete button for child rows.
                LinkButton control = (LinkButton) treeListDataItem["DeleteTemplateColumn"].Controls[1];
                control.Visible = false;
            }
            if (treeListDataItem["Name"].Text == "Default")
            {
                treeListDataItem["Name"].BackColor = Color.LightSkyBlue;
                treeListDataItem["BrandAttribute"].BackColor = Color.LightSkyBlue;
            }
            if (treeListDataItem["BrandAttribute"].Text == "**Default**")
            {
                treeListDataItem["BrandAttribute"].BackColor = Color.Tomato;
            }
        }
    }

    protected void OnSettingsTreeListCreateColumnEditor(object sender, TreeListCreateColumnEditorEventArgs e)
    {
        TreeListTextBoxColumnEditor editor = e.DefaultEditor as TreeListTextBoxColumnEditor;
        if (editor != null)
        {
            string columnDataField = e.Column.DataField;
            if (columnDataField == "Name")
            {
                SetupNameEditor(editor);
            }
            else if (columnDataField == "BrandAttribute")
            {
                SetupBrandAttributeEditor(editor);
            }
        }
    }

    private void SetupNameEditor(TreeListTextBoxColumnEditor editor)
    {
        if (editor.Column.UniqueName == "Name")
        {
            editor.TextBoxControl.Width = 650;
            editor.TextBoxControl.ReadOnly = false;
            editor.TextBoxControl.Enabled = true;
        }
    }

    private void SetupBrandAttributeEditor(TreeListTextBoxColumnEditor editor)
    {
        if (editor.Column.UniqueName == "BrandAttribute")
        {
            editor.TextBoxControl.Width = 650;
            editor.TextBoxControl.ReadOnly = false;
            editor.TextBoxControl.Enabled = true;
            editor.TextBoxControl.TextMode = TextBoxMode.MultiLine;
            editor.TextBoxControl.Rows = 10;
        }
    }

    protected void OnSettingsTreeListDeleteCommand(object sender, TreeListCommandEventArgs e)
    {
        TreeListDataItem treeListDataItem = e.Item as TreeListDataItem;
        TableRow tableRow = e.Item as TableRow;
        if (treeListDataItem != null && tableRow != null)
        {
            string name = tableRow.Cells[3].Text;
            PropertyType.GetPropertyType(typeof (Brand)).RemoveSetting(name);
            m_settingsTreeList.Rebind();
        }
    }

    protected void OnSettingsTreeListInsertCommand(object sender, TreeListCommandEventArgs e)
    {
        Hashtable insertedValues = new Hashtable();
        TreeListEditableItem newItem = e.Item as TreeListEditableItem;
        e.Item.OwnerTreeList.ExtractValuesFromItem(insertedValues, newItem, false);
        string settingName = (string) insertedValues["Name"];
        if (!string.IsNullOrEmpty(settingName))
        {
            PropertyType.GetPropertyType(typeof (Brand)).InsertTreeListSetting(settingName);
            m_settingsTreeList.Rebind();
        }
    }

    protected void OnSettingsTreeListUpdateCommand(object sender, TreeListCommandEventArgs e)
    {
        TreeListEditFormItem treeListEditFormItem = (e.Item as TreeListEditFormItem);
        if (treeListEditFormItem != null)
        {
            string id = treeListEditFormItem.ParentItem.GetDataKeyValue("Id").ToString();
            DataRow[] settings = SettingsTreeListDataTable.Select(string.Format("Id='{0}'", id));
            DataRow setting = null;
            if (settings.Length > 0)
            {
                setting = settings[0];
                string name = (string) setting.ItemArray[2];
                // Edit the Name.
                if (setting.ItemArray[0] == DBNull.Value)
                {
                    TreeListTextBoxColumnEditor nameTreeListTextBoxColumnEditor =
                        treeListEditFormItem.GetColumnEditor("Name") as TreeListTextBoxColumnEditor;
                    if (nameTreeListTextBoxColumnEditor != null)
                    {
                        string newName = nameTreeListTextBoxColumnEditor.TextBoxControl.Text;
                        PropertyType.GetPropertyType(typeof (Brand)).UpdateTreeListSetting(newName, name);
                    }
                }
                // Edit the BrandAttribute.
                else
                {
                    string parentId = (string) setting.ItemArray[0];
                    DataRow[] parents = SettingsTreeListDataTable.Select(string.Format("Id = '{0}'", parentId));
                    if (parents.Length > 0)
                    {
                        DataRow parent = parents[0];
                        string parentName = (string) parent.ItemArray[2];
                        TreeListTextBoxColumnEditor brandAttributeTreeListTextBoxColumnEditor =
                            treeListEditFormItem.GetColumnEditor("BrandAttribute") as TreeListTextBoxColumnEditor;
                        if (brandAttributeTreeListTextBoxColumnEditor != null)
                        {
                            string newValue = brandAttributeTreeListTextBoxColumnEditor.TextBoxControl.Text;
                            PropertyType.GetPropertyType(typeof (Brand)).UpdateTreeListSetting(parentName, name,
                                                                                               newValue);
                        }
                    }
                }
            }
            m_settingsTreeListDataTable = null;
        }
    }

    protected void OnSettingsTreeListItemCommand(object sender, TreeListCommandEventArgs e)
    {
        if (e.CommandName == RadTreeList.EditCommandName)
        {
            m_settingsTreeList.InsertIndexes.Clear();
            TreeListDataItem treeListDataItem = e.Item as TreeListDataItem;
            if (treeListDataItem != null)
            {
                if (treeListDataItem.ParentItem == null)
                {
                    HideColumnsForNameEditor();
                }
                else
                {
                    HideColumnsForBrandAttributeEditor();
                }
            }
        }
        if (e.CommandName == RadTreeList.InitInsertCommandName)
        {
            m_settingsTreeList.InsertIndexes.Clear();
            HideColumnsForNameEditor();
        }

    }

    private void HideColumnsForNameEditor()
    {
        TreeListBoundColumn nameColumn = m_settingsTreeList.GetColumnSafe("Name") as TreeListBoundColumn;
        if (nameColumn != null)
        {
            nameColumn.ReadOnly = false;
        }
        TreeListBoundColumn brandAttributeBoundColumn = m_settingsTreeList.GetColumnSafe("BrandAttribute") as TreeListBoundColumn;
        if (brandAttributeBoundColumn != null)
        {
            brandAttributeBoundColumn.ReadOnly = true;
        }
        TreeListTemplateColumn deleteTemplateColumn =
            m_settingsTreeList.GetColumnSafe("DeleteTemplateColumn") as TreeListTemplateColumn;
        if (deleteTemplateColumn != null)
        {
            deleteTemplateColumn.ReadOnly = true;
        }
    }

    private void HideColumnsForBrandAttributeEditor()
    {
        TreeListBoundColumn nameColumn = m_settingsTreeList.GetColumnSafe("Name") as TreeListBoundColumn;
        if (nameColumn != null)
        {
            nameColumn.ReadOnly = true;
        }
        TreeListBoundColumn brandAttributeBoundColumn = m_settingsTreeList.GetColumnSafe("BrandAttribute") as TreeListBoundColumn;
        if (brandAttributeBoundColumn != null)
        {
            brandAttributeBoundColumn.ReadOnly = false;
        }
        TreeListTemplateColumn deleteTemplateColumn =
            m_settingsTreeList.GetColumnSafe("DeleteTemplateColumn") as TreeListTemplateColumn;
        if (deleteTemplateColumn != null)
        {
            deleteTemplateColumn.ReadOnly = true;
        }
    }


    Cheers

    Surf.
