Cyrillic after deserialization

1 Answer 59 Views
Diagram
This is a migrated thread and some comments may be shown as answers.
Svyatoslav
Top achievements
Rank 1
Svyatoslav asked on 07 Mar 2017, 12:11 PM

After deserialization Cyrillic is displayed as unknown characters, could you suggest how to fix it?

public void diagram_ShapeDeserialized(object sender, Telerik.Windows.Controls.Diagrams.ShapeSerializationRoutedEventArgs e)
        {
            try
            {
                if (e.Shape is FunctionShape)
                {
                    FunctionShape shape = e.Shape as FunctionShape;

                    if (e.SerializationInfo["DisplayName"] != null)
                        shape.DisplayName = e.SerializationInfo["DisplayName"].ToString();

                  }

             }
        }



For example, this function



<FunctionItem>
      <DisplayName>ИЛИ</DisplayName>
      <FunctionName>OR</FunctionName>
      <InputCount>2</InputCount>
      <OutputCount>1</OutputCount>
      <Code>//OR Gate
IN(data0)
OR(data1)
OUT(out0)
</Code>
      <FunctionType>Logic</FunctionType>
      <LeftEdge>0</LeftEdge>
      <RightEdge>1</RightEdge>
      <Data>M 281,290L 319,290C 319.552,290 320,289.552 320,289L 320,251C 320,250.448 319.552,250 319,250L 281,250C 280.448,250 280,250.448 280,251L 280,289C 280,289.552 280.448,290 281,290 Z M 280,260L 270,260M 280,280L 270,280M 320,270L 330,270M 302.569,264.156L 307.476,262.656M 302.493,277.666L 312.288,277.666M 307.455,277.385L 307.455,262.228M 287.814,277.664L 296.856,277.664M 287.731,275.747L 296.819,271.106M 287.814,266.164L 296.788,271.278</Data>
      <Width>60</Width>
      <Height>40</Height>
      <Stroke>#FF000000</Stroke>
      <Fill>#FFFF7D00</Fill>
      <StrokeThickness>1</StrokeThickness>
      <Connectors>
        <FunctionItemConnector>
<PinNomber>1</PinNomber>
          <X>0</X>
          <Y>0.25</Y>
          <Direction>Input</Direction>
        </FunctionItemConnector>
        <FunctionItemConnector>
<PinNomber>2</PinNomber>
          <X>0</X>
          <Y>0.75</Y>
          <Direction>Input</Direction>
        </FunctionItemConnector>
        <FunctionItemConnector>
<PinNomber>1</PinNomber>
          <X>1</X>
          <Y>0.5</Y>
          <Direction>Output</Direction>
        </FunctionItemConnector>
      </Connectors>
      <Index>3</Index>
    </FunctionItem>

1 Answer, 1 is accepted

Sort by
0
Martin Ivanov
Telerik team
answered on 09 Mar 2017, 04:15 PM
Hello Svyatoslav,

I tested the reported scenario and it seems that this is an issue with the diagram serialization process. I logged it in our feedback portal where you can track its status and vote for an implementation. I also updated your Telerik points.

If you share what exactly you are doing to achieve the reported issue also in the toolbox I can think of a possible workaround. You can share some runnable code snippets.

Regards,
Martin
