ConfiguratorPanel

12 posts, 0 answers
  1. Bill
    Bill avatar
    94 posts
    Member since:
    Aug 2006

    Posted 28 Jan 2010 Link to this post

    Does anyone know where to get or how to make the ConfiguratorPanel that is shown on many of the demo pages of the telerik controls? Is this a control that is available? Or something we can get? I need something EXACTLY like it! (A sliding/expanding panel?)

    See "Configure Rotator Type":
    http://demos.telerik.com/aspnet-ajax/rotator/examples/rotatortypes/defaultcs.aspx
    http://demos.telerik.com/aspnet-ajax/rotator/examples/default/defaultcs.aspx

    See "Configurator"
    http://demos.telerik.com/aspnet-ajax/calendar/examples/functionality/mainareacustomization/defaultcs.aspx

    Thanks,
    ~bg
  2. Steve
    Steve avatar
    1851 posts
    Member since:
    Dec 2008

    Posted 28 Jan 2010 Link to this post

    Have a peek in your LiveDemos install directory, it all lives under ~/Common
    <%@ Register TagPrefix="qsf" TagName="Header" Src="~/Common/Header.ascx" %>
    <%@ Register TagPrefix="qsf" TagName="HeadTag" Src="~/Common/HeadTag.ascx" %>
    <%@ Register TagPrefix="qsf" TagName="Footer" Src="~/Common/Footer.ascx" %>
    <%@ Register TagPrefix="qsf" Namespace="Telerik.QuickStart" %>


    There's all the qsf stuff there.

    However if all you need is just a simple slide up/down you could throw in a quick one node RadPanelBar, or use a single jQuery line on your div.

    <script type="text/javascript>
        $telerik.$('#yourDivID').slideToggle();
    </script>
    (make sure to enable the jQuery though if you don't have a control that uses it)
    <telerik:RadScriptManager runat="server" ID="RadScriptManager1" >
        <Scripts>
            <asp:ScriptReference Assembly="Telerik.Web.UI" Name="Telerik.Web.UI.Common.Core.js" />
            <asp:ScriptReference Assembly="Telerik.Web.UI" Name="Telerik.Web.UI.Common.jQuery.js" />
        </Scripts>
    </telerik:RadScriptManager>


    I think one of the telerik admins here at one point said that demos page uses some older controls...there's certainly a ton of stuff in that qsf package which you dont need for a simple slide up/down

    If you go the jQuery route you should try and avoid padding on the slide element (in favour of margins)...it seems to "pop" using padding.
  3. UI for ASP.NET Ajax is Ready for VS 2017
  4. Bill
    Bill avatar
    94 posts
    Member since:
    Aug 2006

    Posted 29 Jan 2010 Link to this post

    Hey, thanks Steve for the reply  and information!
    I'm using the very latest Rad controls and I guess they dont include that anymore? I could not find it in my local demo directories.
    Anyway, after what you mentioned, sounds like I sould go with the jQuery stuff, but that unfortunately is new to me.
    I tried your example, but there must be more to it than that. Mine didnt work.
    Thanks
  5. Sebastian
    Admin
    Sebastian avatar
    9934 posts

    Posted 29 Jan 2010 Link to this post

    Hello Bill,

    The ConfiguratorPanel is designed to be used in the RadControls QSF only and it is not a real server control that can be skinned or updated with ajax. You may consider using our RadPanelBar control with a single root item and templated nested item(s) along with expand animation to achive the same result:

    http://demos.telerik.com/aspnet-ajax/panelbar/examples/functionality/expandanimation/defaultcs.aspx

    Best regards,
    Sebastian
    the Telerik team

    Instantly find answers to your questions on the new Telerik Support Portal.
    Watch a video on how to optimize your support resource searches and check out more tips on the blogs.
  6. Daniel Aquere
    Daniel Aquere avatar
    85 posts
    Member since:
    Mar 2011

    Posted 19 Apr 2011 Link to this post

    Hi everyone,

    Your component "configuratorpanel" seems to be what I need for my applicatives. I'd really like to use it on a tool I'm actualy developing.

    Yet, I did not figure out how to isolate it from the examples.

    Can you provide me some help, in order to get this issue solved?

    I appreciate your help in advance

    Regards

    Daniel
  7. Daniel Aquere
    Daniel Aquere avatar
    85 posts
    Member since:
    Mar 2011

    Posted 09 May 2011 Link to this post

    Hi everyone,

    Please, some light over this issue.

    I´m trying to use RadPanelBar, but what I really need is a simple line to open the panel.

    Thanks, best

    Daniel
  8. Bill
    Bill avatar
    94 posts
    Member since:
    Aug 2006

    Posted 09 May 2011 Link to this post

    This should work for you. I could not attach the actual code file but I did attach the images I use (I created). Put the image files in your image directory and modify the style to the path of the 2 images.
    Everything is in the one aspx page. Just create you a new web form and use this code.
    Let me know if this helps you.
    ~bg
    <%@ Page Language="VB" AutoEventWireup="false" CodeFile="Example.aspx.vb" Inherits="Example" %>

    <!DOCTYPE html PUBLIC "-//W3C//DTD XHTML 1.0 Transitional//EN" "http://www.w3.org/TR/xhtml1/DTD/xhtml1-transitional.dtd">

    <head runat="server">
        <title></title>
     <style type="text/css">

            #panel {

                height: 100px;
                display: none;
            }

            .btn-slide {
                background: url(./images/btnDN.gif) no-repeat;
                width: 18px;
                height: 18px;
                display: block;

            }
            .active {
                background: url(./images/btnUP.gif) no-repeat;
            }

        </style>

    </head>
    <body  style="font-family: sans-serif, Arial, Helvetica">
        <form id="form1" runat="server">

       <telerik:RadScriptManager ID="ScriptManager1" runat="server" EnableTheming="True">
        <Scripts>
                <asp:ScriptReference Assembly="Telerik.Web.UI" Name="Telerik.Web.UI.Common.Core.js" />
                <asp:ScriptReference Assembly="Telerik.Web.UI" Name="Telerik.Web.UI.Common.jQuery.js" />
            </Scripts>
        </telerik:RadScriptManager>

        <script type="text/javascript">


            (function ($) {
                $(document).ready(function () {

                    $(".btn-slide").click(function () {
                        $("#panel").slideToggle("slow");
                        $(this).toggleClass("active"); return false;
                    });
                });
            })($telerik.$);
        </script>

         <table cellpadding="0" cellspacing="3" >
                                    <tr>
                                        <td>
                                        Click the button for more advanced features (You can put the button anywhere) >
                                            </td>
                                        <td>
                                             <a href="#" class="btn-slide" title="Advanced Search"></a>
                                        </td>
                                    </tr>
                                </table>

                                <br />
                                <br />

       <div id="panel" >
                     <asp:Label ID="Label4" runat="server" Text="Advanced Information: "
                         ForeColor="#006600"></asp:Label>
                                           <br />
                                <table cellpadding="0" cellspacing="3" width="100%"
                         style="color: #006600;">
                                    <tr >
                                        <td style="border-width: 1px; border-color: #C0C0C0; border-top-style: dashed; border-bottom-style: dashed; padding-top: 10px; padding-bottom: 15px;">
                                            <asp:Literal ID="Literal6" runat="server" Text="Any controls here:"></asp:Literal>
                                            <br />
                                            <asp:TextBox ID="txt1" runat="server" Width="98%"></asp:TextBox>
                                        </td>
                                        <td style="border-width: 1px; border-color: #C0C0C0; border-top-style: dashed; border-bottom-style: dashed; padding-top: 10px; padding-bottom: 15px;">
                                            <asp:Literal ID="Literal7" runat="server" Text="More controls here:"></asp:Literal>
                                            <br />
                                            <asp:TextBox ID="txt2" runat="server" Width="98%"></asp:TextBox>
                                        </td>
                                        <td style="border-width: 1px; border-color: #C0C0C0; border-top-style: dashed; border-bottom-style: dashed; padding-top: 10px; padding-bottom: 15px;">
                                            <asp:Literal ID="Literal8" runat="server" Text="Whatever controls here:"></asp:Literal>
                                            <br />
                                            <asp:TextBox ID="txt3" runat="server" Width="98%"></asp:TextBox>
                                        </td>
                                    </tr>
                                </table>

                    </div>
                <hr />
        </form>
    </body>
    </html>
  9. Daniel Aquere
    Daniel Aquere avatar
    85 posts
    Member since:
    Mar 2011

    Posted 09 May 2011 Link to this post

    Hi Bill,

    Bingo!!!!!!

    Wonderful, congrats. Thank you very much.
    It´s the exactly what I needed.

    Now, I ´m working to show the image buttons, for some reason then don´t appears. (I changed the path of files)

    Best, abraço

    Daniel
  10. Bill
    Bill avatar
    94 posts
    Member since:
    Aug 2006

    Posted 09 May 2011 Link to this post

    check in the style....
    try "/Images"
    or "../Images"
    etc.
    Play with the "dots" before your path.
    ~bg
  11. Daniel Aquere
    Daniel Aquere avatar
    85 posts
    Member since:
    Mar 2011

    Posted 09 May 2011 Link to this post

    Hey Bill,

    When the file is uploading in Telerik site, the name changes... hahaha, this was the problem.

    Sorry for my stupid mistake.

    Hug (abraço in portuguese)

    Daniel
  12. Grill
    Grill avatar
    1 posts
    Member since:
    Dec 2012

    Posted 27 Dec 2012 Link to this post

    Hello Bill,

    thank you for your solution, it's great.
    But i have a problem with 2 RadComboBoxes (for item transfer), the first box with the buttons is not shown correct (see attachments).
    Maybe the Telerik support or you can hel me.

    Thanks.
  13. Maria Ilieva
    Admin
    Maria Ilieva avatar
    4017 posts

    Posted 02 Jan 2013 Link to this post

    Hi Grill,

    Could I kindly ask you to open a separate ticket for the described RadComboBox issue? Thus we will be able to easily track the problem and concentrate on the provided resources to isolate the issue on our site.

    Kind regards,
    Maria Ilieva
    the Telerik team
    If you want to get updates on new releases, tips and tricks and sneak peeks at our product labs directly from the developers working on the RadControls for ASP.NET AJAX, subscribe to their blog feed now.
