Simple project with a DataGrid on the MainPage.

After updating VS 2022 to 17.3 Preview 2.0, an error occurs when trying to debug the project.

If running the Windows platform, I get an error which prevents the project from running (see image). PRI175 "Duplicate Entry"

If running the Android platform, the project runs, but there's an error (FileNotFoundException: Telerik.Maui.Core.resources) during start up and the DataGrid does not render.

If I comment out the DataGrid in the XAML, the project loads without error.

I am using the latest Telerik for Maui (1.0.1)





Lance | Manager Technical Support
Telerik team
 answered on 17 Jun 2022
0 answers
1 view

I've struggled on and off getting the DataGrid to behave the way I expect. I've gone through this forum and made several changes based on related questions, but I still have some issues.

The biggest one I have now is the visibility of items when navigating around the App.

I whittled down the "HomePage" to just the DataGrid and some buttons. In the App I normally refresh this DataGrid when the page is navigated to. For simplicity's sake, I do it manually in this example. Because the HomePage is on the Navigation stack, I expect the Page and the ViewModel to remain valid and thus the items in the DataGrid to still be there, even if I don't refresh the data source. when I return to the page. See the images below and attached video example.

For additional context, I am using NavigationPages and Dependency Injection (for the Pages and ViewModels) to navigate (not AppShell).

    <Grid RowDefinitions="*,100">

        <telerik:RadDataGrid x:Name="grdRegisters"
                             RowHeight="50"
                             Style="{StaticResource ReadOnlyGridStyle}"
                             ItemsSource="{Binding Registers}"
                             SelectionStyle="{StaticResource SelectedRowBackgroundStyle}"
                             RowBackgroundStyle="{StaticResource RowBackgroundStyle}"
                             AlternateRowBackgroundStyle="{StaticResource AltRowBackgroundStyle}"
                             SelectedItem="{Binding SelectedRegister, Mode=TwoWay}">
            <telerik:RadDataGrid.Columns>
                <telerik:DataGridTemplateColumn HeaderText=""
                                                SizeMode="Fixed"
                                                Width="50">
                    <telerik:DataGridTemplateColumn.CellContentTemplate>
                        <DataTemplate x:DataType="RegisterModel">
                            <Label FontFamily="FASolid"
                                   HorizontalOptions="Center"
                                   VerticalOptions="Center"
                                   Text="&#xf005;"
                                   IsVisible="{Binding IsCurrentRegister, Mode=OneTime}"/>
                        </DataTemplate>
                    </telerik:DataGridTemplateColumn.CellContentTemplate>
                </telerik:DataGridTemplateColumn>

                <telerik:DataGridTemplateColumn HeaderText="Shift Date">
                    <telerik:DataGridTemplateColumn.CellContentTemplate>
                        <DataTemplate x:DataType="RegisterModel">
                            <Label Style="{StaticResource GridCellLabelStyle}"
                                   Text="{Binding Date, Converter={StaticResource ToLocalTimeConverter}, StringFormat='{}{0:d}'}"/>
                        </DataTemplate>
                    </telerik:DataGridTemplateColumn.CellContentTemplate>
                </telerik:DataGridTemplateColumn>

                <telerik:DataGridTemplateColumn HeaderText="Shift Name">
                    <telerik:DataGridTemplateColumn.CellContentTemplate>
                        <DataTemplate x:DataType="RegisterModel">
                            <Label Style="{StaticResource GridCellLabelStyle}"
                                   Text="{Binding Shift.Name}"/>
                        </DataTemplate>
                    </telerik:DataGridTemplateColumn.CellContentTemplate>
                </telerik:DataGridTemplateColumn>

                <telerik:DataGridTemplateColumn HeaderText="Start Time">
                    <telerik:DataGridTemplateColumn.CellContentTemplate>
                        <DataTemplate x:DataType="RegisterModel">
                            <Label Style="{StaticResource GridCellLabelStyle}"
                                   Text="{Binding StartTime, Converter={StaticResource ToLocalTimeConverter}, StringFormat='{}{0:t}'}"/>
                        </DataTemplate>
                    </telerik:DataGridTemplateColumn.CellContentTemplate>
                </telerik:DataGridTemplateColumn>

                <telerik:DataGridTemplateColumn HeaderText="End Time">
                    <telerik:DataGridTemplateColumn.CellContentTemplate>
                        <DataTemplate x:DataType="RegisterModel">
                            <Label Style="{StaticResource GridCellLabelStyle}"
                                   Text="{Binding EndTime, Converter={StaticResource ToLocalTimeConverter}, StringFormat='{}{0:t}'}"/>
                        </DataTemplate>
                    </telerik:DataGridTemplateColumn.CellContentTemplate>
                </telerik:DataGridTemplateColumn>


            </telerik:RadDataGrid.Columns>
        </telerik:RadDataGrid>

        <HorizontalStackLayout Grid.Row="1">
            <Button Text="Resume"
                    IsEnabled="{Binding SelectedRegister, Converter={StaticResource IsNotNullConverter}}"
                    Command="{Binding ResumeShiftCommand}"/>

            <Button Text="Refresh"
                    Command="{Binding RefreshCommand}"/>

        </HorizontalStackLayout>

    </Grid>




On initial Refresh, all items are visible in the DataGrid

I navigate forward and then back (PopToRoot), the DataGrid appears empty, although the vertical scroll appears like there are items.

If I tap Refresh, items become visible, but only above the first fold.

If i resize the window vertically, items will appear and disappear depending on the height of the window. (see attached video)



Derrick
Top achievements
Rank 1
 asked on 15 Aug 2022
0 answers
6 views

  Hi teams:

       When using the DataGrid control, when we use the DataGridTextColumn column property to generate a column and publish it to the ios real machine iphone test, a flashback operation will occur, but when we change the DataGridTemplateColumn column property to generate a column, the flashback operation will not occur.

       So we want to ask is it not possible to use this DataGridTextColumn to generate columns on the iphone? Or is there some other setting we missed?

       The code please refer to image,image1 will flash back,and image2 will not flash back.

        Thanks.

ward
Top achievements
Rank 1
 asked on 11 Aug 2022
1 answer
14 views

Hi Telerik Team,

I noticed that there is no more "Telerik UI for .NET MAUI pkg & MAUI Workload Mismatch Issue" like below in the latest version 2.3.0, my understanding is: Telerik UI for .NET MAUI pkg still has the dependency on MAUI Workload, but it did a good job on compatibility.

It will be perfect if you guys can share more insight or details about this improvement.

WINAPPSDKGENERATEPROJECTPRIFILE : error : PRI175: 0x80073b0f - Processing Resources failed with error: Duplicate Entry.
WINAPPSDKGENERATEPROJECTPRIFILE : error : PRI222: 0x80073b0f - Unspecified error occurred.



Note: version 2.3.0/version 2.2.0 worked with MAUI 419/449 and no matter what combination.



Antoan
Telerik team
 answered on 10 Aug 2022
2 answers
89 views

Hey Team,

I got a error when we added Telerik.UI.for.MAUI.Trial 1.0.1 reference into my MAUI class libraries, It said Project XXX is not compatible with net6.0 (.NETCoreApp,Version=v6.0). Project XXX supports: net6.0-windows10.0.19041 (.NETCoreApp,Version=v6.0)

For right now we created Unit Test for ClassLibrary and it is related Net 6.0. ClassLibrary needs other projects&amp;amp;nbsp;reference which include telerik, you can see my below screenshot.

Repro steps:

1. Create a MAUI class Library A and add Telerik.UI.for.MAUI.Trial 1.0.1 reference into library A.

2. Create a MAUI ClassLibrary B and add ClassLibraryA reference into B.

Is there a way to fix this issue?



Thanks

Allen





Lance | Manager Technical Support
Telerik team
 answered on 05 Aug 2022
1 answer
11 views

I want to enlarge the font size in the option, but there is no fontsize attribute in this control. How can I enlarge the font of this option。

The code is as follows:


 <telerikInput:RadSegmentedControl Grid.Row="8" Grid.Column="1" Style="{StaticResource NormalSegmentControl}" ItemsSource="{Binding YesNoList}" SelectedIndex="{Binding CodeIndex, Mode=TwoWay}"/>





Antoan
Telerik team
 answered on 04 Aug 2022
1 answer
11 views

Hey Team,

I have a question for how to implement zebra striping of RadListView?

Do you have a in-built feature to do that?



For right now I know we can use DataTemplateSelector or Converter,  do we have a better in-built feature to do that?



Thanks

Allen

Antoan
Telerik team
 answered on 02 Aug 2022
0 answers
9 views

Hey Team,

I was wondering if it is a problem, when I used RadListView in a Grid, Grid has ColumnSpacing,

for example:

 <Grid ...
RowSpacing="1"
      ColumnSpacing="1"
      WidthRequest="305"
      HeightRequest="303"
      BackgroundColor="#FF454545">
    <Grid.RowDefinitions>
        <RowDefinition Height="36"/>
        <RowDefinition Height="28"/>
        <RowDefinition Height="82"/>
        <RowDefinition Height="50"/>
        <RowDefinition Height="50"/>
        <RowDefinition Height="50"/>
    </Grid.RowDefinitions>
    <Grid.ColumnDefinitions>
        <ColumnDefinition Width="152"/>
        <ColumnDefinition Width="152"/>
    </Grid.ColumnDefinitions>

    <telerik:RadListView x:Name="listView" Grid.Row="5" Grid.ColumnSpan="2" WidthRequest="305">
        <telerik:RadListView.ItemTemplate>
            <DataTemplate>
                <telerik:ListViewTemplateCell>
                    <telerik:ListViewTemplateCell.View>
                        <Grid BackgroundColor="Gray">
                            <Label Margin="10" Text="{Binding Name}" />
                        </Grid>
                    </telerik:ListViewTemplateCell.View>
                </telerik:ListViewTemplateCell>
            </DataTemplate>
        </telerik:RadListView.ItemTemplate>
    </telerik:RadListView>
.
.
.
</Grid>

I found the RadListView.Width is 304(ColumnDefinition plus), not 305.

I want RadListView to fill all row space, but I failed because of ColumnSpacing. This issue is only existing on Windows.

Allen
Top achievements
Rank 1
Iron
Iron
 asked on 01 Aug 2022
1 answer
10 views
When using the Telerik for MAUI libraries and trying to compile for a Windows device, the error occurs:

Error XFC0000 Cannot resolve type "http://schemas.telerik.com/2022/xaml/maui:telerik:RadComboBox".

The same Android app compiles and works.

Thanks.
Antoan
Telerik team
 answered on 01 Aug 2022
1 answer
29 views

Using the RadDataGrid MAUI control does not seem to be formatting as the normal windows WPF GridView control.

example:


it does not seem to be seeing the carriage returns within the cells values.

Is this a bug or is there some thing I have to set in the control?

Thanks.

Deasun

[edited by Telerik support to occlude information in screenshots]

Lance | Manager Technical Support
Telerik team
 updated question on 29 Jul 2022
