    Dear All,

    I have a prism region in may parent page defined as follows :

    <





    ItemsControl x:Name="detailsviewcontainer" prism:RegionManager.RegionName="DetailsRegion"/>
    when I load a usercontrol contains RadTileView, it doesn't fill the content, how can I do so ...

    Best regards
    Waleed

  2. Kiril Stanoev
    Admin
    Kiril Stanoev avatar
    1512 posts

    Posted 01 Mar 2011 Link to this post

    Hi Waleed,

    Could you please send us a sample application clearly demonstrating the issue. This way we will be better able to assist you.

    Kind regards,
    Kiril Stanoev
    the Telerik team
    Registration for Q1 2011 What’s New Webinar Week is now open. Mark your calendar for the week starting March 21st and book your seat for a walk through all the exciting stuff we ship with the new release!
  3. DevCraft banner
  4. Waleed Seada
    Waleed Seada avatar
    241 posts
    Member since:
    May 2006

    Posted 01 Mar 2011 Link to this post

    Dear Kiril,

    It's gona be hard to split this in a stand-alone project as it contains a lot of data handling and stuff like that, but I will try to explain in details.

    I have a treeview displayed on the leftview and it's siblings displayed on the rightview using Tileview. It is displayed as in the attachment image and you can see yourself. I tried to replace the Tile with grid and it is filling the rightview area not like Tileview.

    Also you will notice that in the normal state the left items are not shown as they should ....

    I need to fix both the fill layout of the Tileview and the display of the items on the left side of the normal state.

    Also I would like to know If in normal view I can display an edit form for data element and do the save, new & delete actions.

    Thanks and best regards
    Waleed
  5. Waleed Seada
    Waleed Seada avatar
    241 posts
    Member since:
    May 2006

    Posted 01 Mar 2011 Link to this post

    Thank you all guys, I have found some answers to my requirements.

    First to have the minimized items doesn't looks as the image attached I have to edit the ItemTemplete as follows:
    <telerik:RadTileView.ItemContainerStyle>
                    <Style TargetType="telerik:RadTileViewItem">
                        <Setter Property="MinimizedHeight" Value="155" />
                    </Style>
                </telerik:RadTileView.ItemContainerStyle>

    I will try to use this approach editing my business objects ...any help will be much welcome.
    Regards
    Waleed
  6. Petar Mladenov
    Admin
    Petar Mladenov avatar
    2891 posts

    Posted 04 Mar 2011 Link to this post

    Hello Waleed Seada,

    Do you mean you wish to set different Minimizedheight of your Business Objects? If so, you can expose a double property in your business object/viewmodel and bind it to the RadTileViewitems via ContainerBindings. You can find more info on how to use them here. Feel free to ask if you need further assistance.

    Regards,
    Petar Mladenov
    the Telerik team
