Special Char like( Û , ê ,...

Thread is closed for posting
5 posts, 0 answers
  1. Saed
    Saed avatar
    6 posts
    Member since:
    Mar 2013

    Posted 15 Jun 2014 Link to this post

    Dear Support Team

    Hello To All

    I how Question regarding special characters like ( Û ,  ê  ,...)   when the chart element contain these characters the chart show something like the attachment  1

    i include two snapshot one with these characters (1.png)  and one without (2.png) , i can solve my problem by remove any characters like these before creating

    chart (it will recrudesce speed and performance) also iam not happay with outputs , so anysugesstion...


  2. Danail Vasilev
    Admin
    Danail Vasilev avatar
    1490 posts

    Posted 18 Jun 2014 Link to this post

    Hi Saed,

    I have tried to reproduce the mentioned issue but to no avail - the chart is rendered properly in FireFox, IE and Chrome after placing special symbols in title and series names. Could you please try to reproduce the issue with the code below and then tell us what changes you have made, so that I can make an investigation locally:

    ASPX:
    <telerik:RadScriptManager ID="RadScriptManager1" runat="server"></telerik:RadScriptManager>
    <telerik:RadHtmlChart runat="server" ID="PieChart1" Transitions="true" Width="450px" Height="400px">
        <PlotArea>
            <Series>
                <telerik:PieSeries StartAngle="90">
                    <LabelsAppearance Position="OutsideEnd" DataFormatString="{0} %" />
                    <TooltipsAppearance DataFormatString="{0} %" />
                    <SeriesItems>
                        <telerik:PieSeriesItem BackgroundColor="Purple" Exploded="true" Name="Û ê Internet Explorer" Y="18.3" />
                        <telerik:PieSeriesItem BackgroundColor="Orange" Exploded="false" Name="Û ê Firefox" Y="35.8" />
                        <telerik:PieSeriesItem BackgroundColor="Green" Exploded="false" Name="Û ê Chrome" Y="38.3" />
                        <telerik:PieSeriesItem BackgroundColor="Blue" Exploded="false" Name="Safari" Y="4.5" />
                        <telerik:PieSeriesItem BackgroundColor="Red" Exploded="false" Name="Opera" Y="2.3" />
                    </SeriesItems>
                </telerik:PieSeries>
            </Series>
        </PlotArea>
        <ChartTitle Text="Û ê  Browser Usage for April 2012">
        </ChartTitle>
    </telerik:RadHtmlChart>



    Regards,
    Danail Vasilev
    Telerik


    Check out the Telerik Platform - the only platform that combines a rich set of UI tools with powerful cloud services to develop web, hybrid and native mobile apps.


  3. UI for ASP.NET Ajax is Ready for VS 2017
  4. Saed
    Saed avatar
    6 posts
    Member since:
    Mar 2013

    Posted 18 Jun 2014 in reply to Danail Vasilev Link to this post

    hello Danail

    try single qutation character ' , then  problem comming


  5. Saed
    Saed avatar
    6 posts
    Member since:
    Mar 2013

    Posted 18 Jun 2014 in reply to Danail Vasilev Link to this post

    <%@ Page Language="VB" AutoEventWireup="false" CodeFile="Default2.aspx.vb" Inherits="Default2" %>
    <%@ Register assembly="Telerik.Web.UI" namespace="Telerik.Web.UI" tagprefix="telerik" %>



    <!DOCTYPE html PUBLIC "-//W3C//DTD XHTML 1.0 Transitional//EN" "http://www.w3.org/TR/xhtml1/DTD/xhtml1-transitional.dtd">

    <head runat="server">
        <title></title>
    </head>
    <body>
        <form id="form1" runat="server">
        <div>

    <telerik:RadScriptManager ID="RadScriptManager1" runat="server"></telerik:RadScriptManager>

    <telerik:RadHtmlChart runat="server" ID="PieChart1" Width="450px" Height="400px">
        <PlotArea>
            <Series>

                <telerik:DonutSeries Name="Series 1" StartAngle="90">
                    <Items>
                        <telerik:SeriesItem BackgroundColor="Blue" Name="'saed" YValue="2" />
                        <telerik:SeriesItem BackgroundColor="Black" Name="ali'" YValue="5" />
                    </Items>
                </telerik:DonutSeries>

            </Series>
        </PlotArea>
        <ChartTitle Text="Û ê  Browser Usage for April 2012">
    <Appearance>
    <TextStyle FontSize="16px"></TextStyle>
    </Appearance>
        </ChartTitle>
    </telerik:RadHtmlChart>
        </div>
        </form>
    </body>
    </html>


    try the above code
  6. Danail Vasilev
    Admin
    Danail Vasilev avatar
    1490 posts

    Posted 20 Jun 2014 Link to this post

    Hi Saed,

    You must use HTML entities for the quotes in labels. For example:
    <telerik:RadHtmlChart runat="server" ID="PieChart1" Width="450px" Height="400px">
        <PlotArea>
            <Series>
                <telerik:DonutSeries Name="Series 1" StartAngle="90">
                    <Items>
                        <telerik:SeriesItem BackgroundColor="Blue" Name="&#8217;saed" YValue="2" />
                        <telerik:SeriesItem BackgroundColor="Black" Name="ali&#8217;" YValue="5" />
                    </Items>
                </telerik:DonutSeries>
            </Series>
        </PlotArea>
        <ChartTitle Text="Û ê  Browser Usage for April 2012">
            <Appearance>
                <TextStyle FontSize="16px"></TextStyle>
            </Appearance>
        </ChartTitle>
    </telerik:RadHtmlChart>

    More information is available in Handling Special Symbols help article.
