Narrow range not respected after upgrading from 2015.2.826 to 2016.3.914.45

4 posts, 0 answers
  1. Joel
    Joel avatar
    166 posts
    Member since:
    Oct 2006

    Posted 23 Sep Link to this post

    I have a box and whisker plot (boxplotseries)

    I have a server version and a local version of the same project.

    The only difference between the projects is that I upgraded my local project from 2015.2 to 2016.3.914 this morning.

    I have NarrowRange="true" set both in the front side and in the code behind for this graph.  2015.2 shows a non-zero based chart in production, and local shows zero based regardless of range.

    Is there a different way to define narrowrange in the latest release, or is this a bug?



    I have reverted back to 2015.2 via the VS/Telerik upgrade wizard and have resolved my issue for now.

    <telerik:RadHtmlChart runat="server" ID="rcBP" Width="250px" Height="300px">
              <Legend>
                  <Appearance Visible="True" BackgroundColor="Yellow"></Appearance>
              </Legend>
              <PlotArea>
                  <XAxis></XAxis>
                  <Series  >
                  <telerik:BoxPlotSeries>
                      <TooltipsAppearance Color="White" BackgroundColor="#4f99d2" >
                          <ClientTemplate >
                              Avg: #=kendo.format(\'{0:N2}\',dataItem.Avg)# <br />
                                P10:  #=kendo.format(\'{0:N0}\',dataItem.D10)# <br />
                               P25:   #=kendo.format(\'{0:N0}\',dataItem.D25)# <br />
                              P50: #=kendo.format(\'{0:N0}\',dataItem.P50)# <br />
                              P75: #=kendo.format(\'{0:N2}\',dataItem.P75)# <br />
                              P90: #=kendo.format(\'{0:N2}\',dataItem.P90)#
                          </ClientTemplate>
                      </TooltipsAppearance>
                      <Appearance FillStyle-BackgroundColor="#4f99d2" ></Appearance>
                  </telerik:BoxPlotSeries>
              </Series>
              <XAxis Visible="False" >
                  <Items >
                      <telerik:AxisItem LabelText="" />
                  </Items>
                  <MajorGridLines Visible="False" />
                  <MinorGridLines Visible="False" />
              </XAxis>
                  <YAxis MinorTickType="None" MajorTickType="None" NarrowRange="true" >
                      <MinorGridLines Visible="False" />
                      <MajorGridLines Visible="False" />
                      <LabelsAppearance DataFormatString="{0:C2}">
                      </LabelsAppearance>
                  </YAxis>
          </PlotArea>
      </telerik:RadHtmlChart>



  2. Slav
    Admin
    Slav avatar
    1356 posts

    Posted 28 Sep Link to this post

    Hello Joel,

    The narrow range appears to be applied on my end with the latest version of UI for ASP.NET (2016.3.914). You can find attached a sample that looks as shown in the following screen capture: http://screencast.com/t/HnIE4Gv3

    Please check it and compare it with your project in order to determine the differences that lead to the issue at hand. Then you can change the attached sample until the problem can be reproduced and send it so that I can debug it locally.

    Regards,
    Slav
    Telerik by Progress
    Do you need help with upgrading your ASP.NET AJAX, WPF or WinForms projects? Check the Telerik API Analyzer and share your thoughts.
  3. UI for ASP.NET Ajax is Ready for VS 2017
  4. Joel
    Joel avatar
    166 posts
    Member since:
    Oct 2006

    Posted 28 Sep in reply to Slav Link to this post

    Attached is a trimmed out example with screen shots.  Only difference between the two is using the Telerik Upgrade wizard to switch between the 2 versions.

    aspx and aspx.cs available here  http://www.bubblergps.com/bpg.zip







  5. Slav
    Admin
    Slav avatar
    1356 posts

    Posted 03 Oct Link to this post

    Hi Joel,

    Indeed, the issue is reproducible with the data from your example. I have logged a bug item, which you can use to track its status: http://feedback.telerik.com/Project/108/Feedback/Details/202426

    It also contains a workaround, which you can use for the time being.

    I updated your points as a small token of gratitude for reporting this issue.

    Regards,
    Slav
